▶Fuel and lubrication system

- Do not allow the fluid and engine oil to make contact with the body paintwork and hoses.
- If work on the fluid system such as fuel and oil, working area should be well ventilated and
smoking should be prohibited.
- Gasket or seal on the fuel/lubrication system should be replaced with new ones and bolts and
nuts should be tightened as specified.
- After removal/installation works, be sure to check whether there is leak on the connecting
section.
1. If fine dust or foreign material enters into DI engine's fuel system, there can be serious
damages between HP pump and injectors. So, be sure to cover removed fuel system
components with cap and protect removed parts not to be contaminated with dirt. (Refer to
cleanness in this manual while working on DI engine fuel system)
2. When working on the fuel line between priming pump and injector (including return line),
always plug the openings with caps to prevent foreign materials or dust from entering to the
openings and connections.
3.
The HP fuel supply pipe (HP pump to fuel rail) and HP fuel pipe (Fuel rail to injector) should
be replaced with new ones when removed.

▶Electrical equipment

Electric devices should be handled more carefully.
Currently, the engine has a lot of electric devices. There could be poor engine performance,
incomplete combustion and other abnormal symptoms due to short circuit or poor contact.
- Before work on engine and electrical equipment, be sure to disconnect battery negative (-)
terminal.
- When replacing the electric device, use only genuine part and check the conditions of
connections and grounds. Loosened connection or ground makes cause a fire and personal
injury.
