LST FWI2-1 Specification Sheet

Fire Brigade Interface
FWI2-1/FWZ2-1
• 2 independent relay outputs
• 9 inputs and 8 outputs for control
tasks
• Connection of country-specifi c fi re
brigade control units
• Line monitoring by means of auxiliary
module
Description
The Fire Brigade Interface FWI2-1 by means of dry
contacts allows for the connection of two independent
transmitting devices for the direct interconnection with
a designated alarm respondent (e.g., the fi re brigade)
as well as the connection of a country-specifi c fi re bri-
gade control unit to fi re detection control panels Series
BC216.
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
The parameters of the nine inputs and eight outputs can
also be freely set and thus are available for general con-
trol tasks. Optionally, the Fire Brigade Interface Additio-
nal Board (FWZ2-1) can be attached to the Fire Brigade
Interface. This unit allows for the connection of two
independent, line-monitored transmitting devices. The
surveillance current can be adjusted in three levels.
A
