LST FWI016-1 Specification Sheet

Fire Brigade Interface
FWI016-1
• Relay output with dry changeover
contact
• Line-monitored output with selectable
surveillance current
• 8 inputs and 7 outputs for control
tasks
• Connection of country-specifi c fi re
brigade control units
Description
The Fire Brigade Interface FWI016 allows for the con-
nection of two independent transmitting devices for di-
rect interconnection to a designated alarm respondent
(e.g., the fi re brigade) as well as the connection of a
country specifi c fi re brigade control unit to Fire Detec-
tion Control Panels Series BC016.
Specifi cations
Current consumption at 24V
Contact rating of relay contact
Contact life
Ambient temperature
Dimensions L × W × H
Weight
Part No.
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
A dry contact and a line-monitored output are available
for the connection of the transmitting devices.
The parameters of the eight inputs and seven outputs
can also be freely set and thus are available for general
control tasks.
typ. 4mA
60V/1A/30W
approx. 300,000 switching cycles (at 24VDC/1A)
-5°C to +50°C
130 × 65 × 15 (mm)
70g
210111
Fire Brigade Interface FWI016-1
A
FWI016-1_DBL_LST_EN_0804.PDF • PAGE 1
