Aiwa XR-AVH1200 Service Manual

Aiwa XR-AVH1200 Service Manual

Compact disc stereo system
Hide thumbs Also See for XR-AVH1200:

Advertisement

Quick Links

Download this manual
XR-AVH1200
COMPACT DISC STEREO SYSTEM
•
:
TYPE
HR
SIMPLE MANUAL
CASSETTE
GRAPHIC
TYPE AMPLIFIER
CD PLAYER
SPEAKERS
DECK
EQUALIZER
SX-NAVH1200
HR
MX-SNAVH1200
FX-SNH1100
GE-SNAVH1200
DX-SNH1100
SX-CR677
• Replace this Service Manual with "Revision Publishing" when it is issued.
.
S/M Code No
09–995–411–7T1

Advertisement

loading
Need help?

Need help?

Do you have a question about the XR-AVH1200 and is the answer not in the manual?

Questions and answers

Related Manuals for Aiwa XR-AVH1200

Summary of Contents for Aiwa XR-AVH1200

  • Page 1 XR-AVH1200 COMPACT DISC STEREO SYSTEM • TYPE SIMPLE MANUAL CASSETTE GRAPHIC TYPE AMPLIFIER CD PLAYER SPEAKERS DECK EQUALIZER SX-NAVH1200 MX-SNAVH1200 FX-SNH1100 GE-SNAVH1200 DX-SNH1100 SX-CR677 • Replace this Service Manual with ”Revision Publishing” when it is issued. S/M Code No 09–995–411–7T1...
  • Page 2 ELECTRICAL MAIN PARTS LIST - 1/8 (MX-SNAVH1200) NOTE: The characters in the suffix column indicate the part usage. HSM ....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-071-040 CAP,E 1-50 M 5L SRE A....87-010-192-080 C-CAP,S 0.022-50 F A....87-010-194-080 CAP, CHIP 0.047 A....
  • Page 3 ELECTRICAL MAIN PARTS LIST - 2/8 (MX-SNAVH1200) 87-016-083-080 C-CAP,S 0.15-16 RK A....87-016-669-080 C-CAP,S 0.1-25 K B A....87-016-669-080 C-CAP,S 0.1-25 K B A....87-010-195-080 C-CAP,S 0.068-25 F A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-263-080 CAP, ELECT 100-10V A....87-010-263-080 CAP, ELECT 100-10V A....
  • Page 4 ELECTRICAL MAIN PARTS LIST - 3/8 (MX-SNAVH1200) 87-070-274-080 DIODE,1N4003 SEM A....87-070-274-080 DIODE,1N4003 SEM A....87-A40-468-080 C-DIODE,HSM2836CTR A....87-A40-469-080 C-DIODE,HSM2838CTR A....87-A40-547-090 DIODE,D5SBA20 A....87-020-465-080 DIODE,1SS133 (110MA) A....87-A40-004-080 ZENER,MTZJ16A A....87-A40-345-080 ZENER,MTZJ10C A....87-A40-435-080 ZENER,MTZJ30D A....87-017-447-010 DIODE,GBU4DL A....87-003-223-010 FERRITE BEAD BLO2RN2 A....
  • Page 5 ELECTRICAL MAIN PARTS LIST - 4/8 (MX-SNAVH1200) 87-020-465-080 DIODE,1SS133 (110MA) A....87-020-465-080 DIODE,1SS133 (110MA) A....87-020-465-080 DIODE,1SS133 (110MA) A....87-020-465-080 DIODE,1SS133 (110MA) A....87-020-465-080 DIODE,1SS133 (110MA) A....87-070-136-080 ZENER,MTZJ5.1B A....87-070-136-080 ZENER,MTZJ5.1B A....87-A40-370-090 DIODE,RK46-P20 A....87-A40-370-090 DIODE,RK46-P20 A....87-020-465-080 DIODE,1SS133 (110MA) A....
  • Page 6 ELECTRICAL MAIN PARTS LIST - 5/8 (MX-SNAVH1200) 87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....
  • Page 7 ELECTRICAL MAIN PARTS LIST - 6/8 (MX-SNAVH1200) 87-012-337-080 C-CAP,U 56P-50 CH A....87-010-263-080 CAP, ELECT 100-10V A....87-010-400-080 CAP, ELECT 0.47-50V A....87-010-401-080 CAP, ELECT 1-50V A....87-010-401-080 CAP, ELECT 1-50V A....87-010-404-080 CAP, ELECT 4.7-50V A....87-010-407-080 CAP, ELECT 33-50V A....
  • Page 8 ELECTRICAL MAIN PARTS LIST - 7/8 (MX-SNAVH1200) 87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-401-080 CAP, ELECT 1-50V A....87-010-401-080 CAP, ELECT 1-50V A....87-010-958-080 CHIP -CAP,S 0.01-25BJ A....87-010-958-080 CHIP -CAP,S 0.01-25BJ A....87-010-958-080 CHIP -CAP,S 0.01-25BJ A....87-010-958-080 CHIP -CAP,S 0.01-25BJ A....
  • Page 9 ELECTRICAL MAIN PARTS LIST - 8/8 (MX-SNAVH1200) 87-010-404-080 CAP, ELECT 4.7-50V A....87-010-404-080 CAP, ELECT 4.7-50V A....87-010-405-080 CAP, ELECT 10-50V A....87-010-182-080 C-CAP,S 2200P-50 B A....87-010-260-080 CAP, ELECT 47-25V A....87-010-260-080 CAP, ELECT 47-25V A....87-010-405-080 CAP, ELECT 10-50V A....
  • Page 10 SCHEMATIC DIAGRAM _ 1 (MX-SNAVH1200 : MAIN 1/2)
  • Page 11 SCHEMATIC DIAGRAM _ 2 (MX-SNAVH1200 : MAIN 2/2 PROLOGIC)
  • Page 12 SCHEMATIC DIAGRAM _ 3 (MX-SNAVH1200 : FRONT)
  • Page 13 SCHEMATIC DIAGRAM _ 4 (MX-SNAVH1200 : TUNER)
  • Page 14 SCHEMATIC DIAGRAM _ 5 (MX-SNAVH1200 : PT)
  • Page 15 MECHANICAL PARTS LIST - 1/1 (MX-SNAVH1200) NOTE: The characters in the suffix column indicate the part usage. HSM ....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-B00-002-010 BADGE,AIWA 30 ABS SIL A....8Z-SP1-002-010 CABI,STEEL A....8Z-SP1-017-010 PANEL,SIDE L A....8Z-SP1-018-010 PANEL,SIDE R A....
  • Page 16 ELECTRICAL MAIN PARTS LIST - 1/1 (DX-SNH1100) NOTE: The characters in the suffix column indicate the part usage. YJSM ....XX........A....YSM ....XX........B....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-A90-095-080 SW,TACT EVQ11G04M AB....87-A90-095-080 SW,TACT EVQ11G04M AB....88-SX1-203-210 GUIDE,FL AB....8Z-SX1-202-010 GUIDE,LED OPE AB....
  • Page 17 SCHEMATIC DIAGRAM _ 6 (DX-SNH1100 : MAIN / FRONT)
  • Page 18 MECHANICAL PARTS LIST - 1/1 (DX-SNH1100) NOTE: The characters in the suffix column indicate the part usage. YJSM ....XX........A....YSM ....XX........B....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-B00-002-010 BADGE,AIWA 30 ABS SIL AB....8Z-SX1-001-010 CABI,FR AB....8Z-SX1-010-010 CABI,REAR YLSM ....8Z-SX1-011-010 PANEL,SIDE L AB....
  • Page 19 ELECTRICAL MAIN PARTS LIST - 1/2 (FX-SNH1100) NOTE: The characters in the suffix column indicate the part usage. YJSM ....XX........A....YSM ....XX........B....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8Z-SW1-203-010 GUIDE,LED OPE AB....8Z-SW1-204-010 GUIDE,LED REC AB....8Z-SW1-205-010 GUIDE,LED CASS 1 AB....
  • Page 20 ELECTRICAL MAIN PARTS LIST - 2/2 (FX-SNH1100) 87-010-196-080 CHIP CAPACITOR,0.1-25 AB....87-010-401-080 CAP, ELECT 1-50V AB....87-010-401-080 CAP, ELECT 1-50V AB....87-010-196-080 CHIP CAPACITOR,0.1-25 AB....87-010-175-080 CAP 560P .B....87-010-178-080 CHIP CAP 1000P AB....87-010-183-080 C-CAP,S 2700P-50 B AB....87-010-183-080 C-CAP,S 2700P-50 B AB....
  • Page 21 SCHEMATIC DIAGRAM _ 7 (FX-SNH1100 : MAIN / FRONT)
  • Page 22 MECHANICAL PARTS LIST - 1/1 (FX-SNH1100) NOTE: The characters in the suffix column indicate the part usage. YJSM ....XX........A....YSM ....XX........B....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-B00-002-010 BADGE,AIWA 30 ABS SIL AB....8Z-SW1-001-010 CABI,FR AB....8Z-SW1-002-010 BOX,CASS 1 AB....8Z-SW1-003-010 BOX,CASS 2 AB....
  • Page 23 ELECTRICAL MAIN PARTS LIST - 1/1 (GE-SNAVH1200) NOTE: The characters in the suffix column indicate the part usage. YSM ....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-182-080 C-CAP,S 2200P-50 B A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-197-080 CAP, CHIP 0.01 DM A....
  • Page 24 SCHEMATIC DIAGRAM _ 8 (GE-SNAVH1200 : FRONT)
  • Page 25 MECHANICAL PARTS LIST - 1/1 (GE-SNAVH1200) NOTE: The characters in the suffix column indicate the part usage. YSM ....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-B00-002-010 BADGE,AIWA 30 ABS SIL A....8Z-SU1-002-010 CABI,STEEL A....8Z-SUM-001-010 CABI,FR PRO A....8Z-SUM-003-010 CABI,REAR YJSNM A....
  • Page 26 ACCESSORIES / PACKAGE LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. HSM ....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8Z-SPM-901-010 IB,H(ECA)M A....87-043-095-010 WIRE ANTENNA A....87-043-115-010 ANT,FEEDER FM A....87-A91-017-010 PLUG,CONVERSION JT-0476 A....8Z-NFV-702-010 RC UNIT,RC-ZAS05 A....
  • Page 27 9820543 Tokyo Japan Printed in Singapore...
