LST 55100-908 Specification Sheet

Manual Call Point
55100-908
• ADM loop technology with
Apollo/Discovery protocol
• Activation by pressing in the pane of
plastic
• Two-coloured LED indicates activation
and fault
• Integrated dual-isolator
• Operating instructions by means of
standardised symbols
Description
The Manual Call Point 55100-908 complies with the
standard EN 54-11/A and is designed for use in ADM
loops with Apollo/Discovery protocol.
The detector is activated by pressing in the pane of
plastic. By means of a special key, the pane can be
put back to the idle position, thereby resetting the de-
tector.
The two-coloured status LED indicates the activation of
the detector in red colour and the fault condition in yel-
Specifi cations
Operating voltage
Current consumption
Ambient temperature
Relative humidity
Protection class
Dimensions W × H × D
with surface mount box
installation on fl ush-mount installation box
Colour
Weight
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
low colour. The detector address is selected by means
of a DIL switch. A dual-isolator, which is integrated into
the detector, disconnects the adjacent loop elements
fast and safely in case of a short circuit.
The detector is fi tted into a plastic case and can be
mounted on a 60mm fl ush-mount installation box. By
means of the supplied case, surface mounting on a wall
is also possible.
Supply through loop voltage
100µA (quiescent)
-20°C to +60°C (no condensation or icing)
max. 95% (no condenstation)
IP24
89 × 93 × 59 (mm)
89 × 93 × 28 (mm)
fl ame red, RAL 3000
160g
245015
Manual Call Point/Red/XP95/ISM/Flexi 55100-908
A
