LST Serial Interface Module SIM06-1 Specifications

Serial Interface Module
SIM06-1
• Extends fi re detection control panels
Series BC06 by an RS232C interface
• Transfer rate 1200, 2400, or
4800Baud
• Galvanic separation
Description
The Serial Interface Module SIM06-1 provides fi re de-
tection control panels Series BC06 with a galvanically
separated RS232C interface. A protocol printer or a PC
Specifi cations
Current consumption at 24V
Interface
Signal lines
Connection type
Ambient temperature
Dimensions L × W × H
Weight
Part No.
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
with terminal function can be connected to the fi re de-
tection control panel by means of the componentry. The
transfer rate can be set to 1200, 2400, or 4800Baud.
typ. 15mA
RS232C, galvanically isolated, up to 4800Baud
RxD, TxD
D-SUB plug, 9-pin
-5°C to +50°C
86 × 36 × 17 (mm)
30g
210215
Serial Interface Module SIM06-1
A
SIM06-1_DBL_LST_EN_0804.PDF • PAGE 1
