Manual Title:
Print Date:
Revision/Date:
This supplement contains information necessary to ensure the accuracy of
the above manual.
© 2014-2015 Fluke Corporation. All rights reserved.
Manual Supplement
BT520 Users
May 2014
Supplement Issue:
Issue Date:
Page Count:
2
3/15
7
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Fluke BT520
Summary of Contents for Fluke BT520
- Page 1 Manual Supplement Manual Title: BT520 Users Supplement Issue: Print Date: May 2014 Issue Date: 3/15 Revision/Date: Page Count: This supplement contains information necessary to ensure the accuracy of the above manual. © 2014-2015 Fluke Corporation. All rights reserved. ...
-
Page 2: Make Measurements
BT520 Users Manual Supplement Change #1 On page 1-3, remove item 5 from the Standard Equipment table. On page 1-4, remove item 5 from the Standard Equipment figure. On page 4-5, following Figure 4-3, add: Note Probe tips are not covered under Warranty. - Page 3 Manual Supplement BT520 Users To test battery internal resistance and voltage or strap resistance, turn the rotary switch to mΩ. See Figure 3-1. Internal Resistance and Voltage Strap Resistance hsz018.eps Figure 3-1. Test Battery Internal Resistance and Voltage or Strap Resistance...
- Page 4 BT520 Users Manual Supplement Battery Test Probes To connect test probes to the battery pole: 1. Use the inner tip of the test probe to touch the target surface. 2. Push the test lead to set-back the inner tip, until both the inner tip and the outer tip are fully connected to the target surface.
- Page 5 Manual Supplement BT520 Users View Test Readings on the Screen This is a typical display of battery test in Meter mode. This is a typical display of battery test in Sequence mode: Battery number: Indicates the number of the battery that has been tested.
- Page 6 T520 Users Manual Supple ement et Measurem ment Range attery resista ance or Stra ap resistance e only has m manual range es. The defa ault range for r battery esistance or Strap resista ance measu urement is 30 0 mΩ. You c can push to cycle th hrough differ...
- Page 7 Manual Supplement BT520 Users Set Measurement Thresholds The Product lets you define upper and lower measurement thresholds or tolerance ranges. These defined threshold values are then compared to the measured values to automatically identify and prompt the user with a PASS, FAIL or WARN indicator of battery out of tolerance conditions.
- Page 8 BT520 Users Manual Supplement On the measurement screen, push the Threshold softkey to open the Select Threshold menu. The value of No. is already highlighted. Use to set No. to ---. Push the Confirm softkey. The T-X icon no longer shows on the display.
