- Page 2 Thank you for choosing THE WALL from Legacy Pro Audio THE WALL is a full range loudspeaker system utilizing the present state of the art in driver, crossover, amplifier and acoustic radiation control technologies. The system is designed, assembled and tested in Springfield, IL by a dedicated group of engineers, craftsmen and music lovers.
- Page 3 CONNECTIONS: To Processor Input 1 From preamp left output Input 2 From preamp right output Input 3 N/A with THE WALL. Can be used for center channel Input 4 You can input low frequency effects from the “.1” subwoofer channel It will be mixed into the subwoofer section of the left and right WALL speakers.
-
Page 4: Connections Diagram
CONNECTIONS Diagram:... - Page 5 Routing Matrix in Wavelaunch Processor This can be controlled with XConsole Software. Click here to download the software and to watch a brief instructional video.
- Page 6 Dimensional Line Drawings (inches):...
