If you wish to mount the Extension Box outdoors, you must put it inside the
Waterproof Box.
Adjust the Sun Shield (Optional)
The Sun Shield can be mounted in several positions depending on your needs.
If you extend forward the Sun Shield, it can reduce glare from the sun as well
as keeping the lens glass dry in light rain or snow. On the other hand,
reflections of IR light from the underside of the Sun Shield would make the
entire picture appear foggy, so for maximum night vision range you would
either move the Sun Shield all the way back or remove it entirely.
8
Outdoor
Waterproof Box
Extension Box mount outdoors
PHYLINK PLC-336PW Quick Install Guide
Indoor
Building wall
DC Power Cable
Network Cable
A roughly 1/4 inch diameter hole
will be required for either a CAT-5
network cable or the DC plug on
the power cable to pass through.
