  • Page 1 INVERTER MULTI AIR CONDITIONER FLOOR type (50Hz) Indoor unit Outdoor unit RGF09LAC ROM-30LA4 RGF12LAC RGF14LAC CONTENTS ....1 SPECIFICATIONS ..3 OUTLINE AND DIMENSIONS .

  • Page 2: Specifications

    SPECIFICATIONS INDOOR UNIT ELECTRICAL DATA Cooling & heating inverter TYPE RGF09LAC RGF12LAC RGF14LAC MODEL NAME 0.7 L/hr 1.1 L/hr 1.5 L/hr MOISTURE REMOVAL Cooling 530 m3/hr 600 m3/hr 650 m3/hr AIR CIRCULATION HIGH Heating 530 m3/hr 600 m3/hr 650 m3/hr...

  • Page 3: Outdoor Unit

    OUTDOOR UNIT ELECTRICAL SPECIFICATIONS Cooling & heating multi TYPE MODEL NAME ROM-30LA4 COOLING CAPACITY 8.0 kW HEATING CAPACITY 9.6 kW (220) - 230 - (240) V POWER SUPPLY FREQUENCY 50 Hz Cooling 9.7 A RUNNING CURRENT Heating 10.5 A Cooling 2.22 kW INPUT Heating...
  • Page 4 DIMENSIONS INDOOR UNIT (unit : mm) 2008.01.25...
  • Page 5 OUTDOOR UNIT (Unit : mm) Air Flow 2008.01.25...

  • Page 6: Refrigerant System Diagram

    REFRIGERANT SYSTEM DIAGRAM OUTDOOR UNIT CAPILLARY TUBE THERMISTOR (DISCHARGE.) HEAT EXCHANGER RECEIVER TANK OIL BACK CAPILLARY HEAT EXCHANGER PRESSURE SWITCH(A) STRAINER PRESSURE SWITCH(B) DISTRIBUTOR EXPANSION EXPANSION EXPANSION EXPANSION VALVE VALVE VALVE VALVE THERMISTOR THERMISTOR THERMISTOR THERMISTOR PIPE (A-2WV) PIPE (B-2WV) PIPE (C-2WV) PIPE (D-2WV) STRAINER...
  • Page 7 CIRCUIT DIAGRAM INDOOR UNIT INDICATOR PCB ASSY CN203 CN202 BLACK WHITE WHITE FAN MOTOR YELLOW WHITE ( UPPER ) BLUE WHITE WHITE WHITE WHITE WHITE BLACK WHITE WHITE FAN MOTOR YELLOW ( LOWER ) BLUE BLUE GRAY PIPE THERMISTOR PINK STEP MOTOR GRAY YELLOW...
  • Page 8 OUTDOOR UNIT 4-WAY VALVE CONSTRUCTION CHECK SWITCH SW150 CN30 CN37 PRESSURE SWITCH 1 DC COMPRESSOR WHITE DC FAN MOTOR CURRENT WHITE CN36 PRESSURE SWITCH 2 CHANGE WHITE WHITE 3 2 1 BROWN BLUE EXPANSION CN27 ORANGE VALVE A YELLOW WHITE VALVE THERMISTOR A, B F4 FUSE BLACK...

  • Page 9: Indoor Pcb Circuit Diagram

    INDOOR PCB CIRCUIT DIAGRAM CONTROL UNIT RGF09LAC : EZ-0070CHSE RGF12LAC : EZ-0070DHSE RGF14LAC : EZ-0070EHSE OUTDOOR UNIT TERMINAL THERMAL FUSE 102 BLACK WHITE INDICATOR PCB ASSEMBLY SERIAL K06DD-0700HSE-F0 CN203 JB20-06HG B05B-XASK 22007 22007 22007 CN202 CN6-1 JB20-06HG REMOTE CONTROL CN6-2...
  • Page 10 INDOOR UNIT CONTROLLER PCB ASSEMBLY ( MAIN PCB ) RGF09LAC : K06CS-0703HSE-C1 RGF12LAC : K06CS-0704HSE-C1 RGF14LAC : K06CS-0705HSE-C1 H I C FOR SERIAL COMMUNICATIONS 340V JUMPER SWITCH MY064 C10 0.01 D12 RF201L2S R110 - R114 <ECQE> D9 RF101L2S D10 RF101L2S I C 2 6 10K <1/10W>...
  • Page 11 INDOOR UNIT INDICATOR PCB ASSEMBLY K06DD-0700HSE-F0 CN20 109 PAP / JB20 CN202 CN203 1061 L550 06 JB20 / JB20 06 JB20 / JB20 5V 5V D201 SLR-343DCT32 (red) 1061 L60 1061 L60 D202 SLR-343MCT31P,Q (green) D203 SLR-343MCT31P,Q (green) R201 <1/4W> SW201 C201 KSHG0611BT...

  • Page 12: Outdoor Pcb Circuit Diagram

    OUTDOOR PCB CIRCUIT DIAGRAM INVERTER ASSEMBLY EZ-004HHUE CHOKE COIL L=0.3mH 30A TERMINAL 3P HP-T3061-3-3P UL1015 UL1015 AWG14 AWG14 F201 BLACK BLACK UL1015 UL1015 UL1015 TLC 25A-250V, B AWG14 AWG14 AC230V AWG14 <250V 25A> WHITE BROWN 50Hz WHITE UL1015 TERMINAL 12P AWG20 UL1015 UL1015 AWG14 YELLOW...
  • Page 13 OUTDOOR UNIT CONTROLLER PCB ASSEMBLY ( MAIN PCB ) K04AW-0404HUE-C1 MAIN CURRENT R200 YELLOW R201 C201 C202 C203 C116 ZPR0RCH400 R370, R371, R373, R374 220K 600/ 600/ 600/ D101 R375, R376, R378, R379 <2W> 450V 450V 450V <HCP> 195K <RN - 1/2W> x 6 D25XB60 0.03 <2W>...
  • Page 14 OUTDOOR UNIT POWER SUPPLY PCB ASSEMBLY K04BA-0402HUE-P0 TM100 N200500K1D7C RCH3818-022PF07 RCH3818-022PF07 BLACK TM101 VA101 C104 BLACK 470V 0.015 C107 C111 C101 <TNR> <YE> POWER SOURCE VA102 C105 230V <LE> <LE> <LE> 470V 0.015 50Hz <TNR> <YE> TM102 WHITE C106 WHITE SA100 <LE>...
  • Page 15 PARTS INDOOR UNIT Description Parts number Intake Grille Assy 9316418035 Rope Assy 9316458017 Panel (Front) L 9316187016 Panel (Front) R 9316186019 Air Filter 9316189010 Air Clean Filter Assy 9312152018 Panel (Front) 9316185012 Bracket Panel 9316272019 Remote Control 9316397019 Remote Control Holder 9305642045 2008.01.25...
  • Page 16 INDOOR UNIT Description Parts number Description Parts number Motor Cushion NR 9313168018 Display PCB Assy 9707571028 Fan Motor, MFD-34ROM 9602109029 Display Cover 9316191013 Motor Cushion N 9312979011 Thermistor Holder 9316192010 Crossflow Fan Assy 9312004034 Room Thermistor 9700801108 Bearing C Assy 9306628017 Motor Holder 9316195011...
  • Page 17 INDOOR UNIT Description Parts number Evaporator Holder 9316199019 Evaporator Total Assy (09, 12) 9316091016 Evaporator Total Assy (14) 9316091023 Water Seal 9316271012 U Pipe AA Assy 9316095014 2008.01.25...
  • Page 18 INDOOR UNIT Description Parts number Top Cover 9316207011 R and L Louver U 9316208018 Fan Guard 9316211018 Casing 9316204010 Bushing B 9312156016 Bushing A 9303529010 Gear Case 9316213012 Gear A 9309994003 Motor Step (up / down) 9900384043 Louver U 9316205017 Louver Z 9316206014 REF (Casing)
  • Page 19 INDOOR UNIT Description Parts number 59 Motor Step (Damper) 9900384050 Switch Micro 9900424015 Motor Step (Damper Lock Left) 9900384067 Drain Cap 9316177017 Drain Pan U 9316214019 Drain Hose Assy 9314147029 Motor Step (Damper Lock Right) 9900384074 Bushing B 9312156016 Bushing A 9303529010 Damper 9316216013...
  • Page 20 OUTDOOR UNIT Ref. Description Part number Top Panel Sub Assy 9374417025 Front Panel 9374094066 Fan Guard 9374330010 Grip Side 9374173013 Service Panel Assy 9374415038 Right Panel M 9374599028 Valve Cover Sub Assy 9374827015 Grip 9374172016 2008.01.25...
  • Page 21 OUTDOOR UNIT Ref. Description Part number Motor Bracket Sub Assy 9374418053 Propeller Fan Assy 9366378020 Fan Motor 9601882015 Condenser A Assy 9374433056 Separate Wall Assy 9374629022 Base Assy 9374166084 Cap Foot 9374345014 2008.01.25...
  • Page 22 OUTDOOR UNIT (Connector :RED) (Connector :WHITE) Ref. Description Part number Ref. Description Part number 3-Way Valve Assy (3/8") 9372205044 Compressor Assy 9377946010 4-Way Valve Assy 9374425044 2-Way Valve Assy 9372204054 Inlet Pipe (Cond) A Assy 9373461067 Coil (Expansion Valve)(A=Red) 9900057084 Outlet Pipe (Cond) A Assy 9374266067 Coil (Expansion Valve)(B=White)
  • Page 23 OUTDOOR UNIT Compressor Ref. Description Part number Compressor Assy 9377946010 Rubber Seat (For Comp) 9377951014 Terminal Packing 9377948014 Holder 9377952011 Terminal Cover (Comp) 9377947017 Washer (Rubber) 9377949011 Frange Nut 9377950017 2008.01.25...
  • Page 24 OUTDOOR UNIT Inverter assy Connector : BLACK GREEN BLUE YELLOW Ref. Description Part number Ref. Description Part number Inverter Box A 9374603015 Fuse (Small) 0600376116 Inverter Box B Assy 9374625017 Terminal 9701971015 Inverter Box C 9374605019 ACTPM 9703457012 Inverter Box Duct 9374609017 Power Supply PCB Assy 9705647039...

  • Page 25: Standard Accessories

    STANDARD ACCESSORIES INDOOR UNIT Name and Shape Q'ty Part number Bracket panel For indoor unit installation 9316272019 Remote control AR-RAC1E Use for air conditioner 9316397019 operation Battery (penlight) For remote control 0600185527 Cloth tape For indoor unit installation 9310519004 Remote control holder Hold a remote control 9305642045 Tpping screw (big)
  • Page 26 OUTDOOR UNIT Name and Shape Q'ty Part number Drain pipe For outdoor unit drain piping work 9303029015 Drain cap 313166024302 Adapter assy For use when connecting models 9-12 to outdoor port A 12.7 mm 9.52 mm 9370244007 (1/2 in.) (3/8 in.) 2008.01.25...
  • Page 27 0801G3370...
