Special Configurations - Logic Controls KB5000 User Manual

SPECIAL CONFIGURATIONS

The KB5000 can be set up with many different programming options. To
activate the configuration menu screen the KB5 program must first be placed
into the extended menu (Ctrl, Alt, F4). Press F3 to open the configuration
screen. By depressing the highlighted letter in each option the program
will enable or disable that option. The default settings are shown in the
graphic below.
Send Break-codes for scan-codes
Enable beep while a key pressed
No beep if a key is undefined
Translate to code-set #2 for AT
Emulating XT keyboard always
Use ALT+num to generate ASCII
Enable Typematic for scan codes
Enable Typematic for ASCII codes
Emulating Link Terminal
InterCharacter Delay (+/-):
Enable RS232 Output
Baud Rate:
Parity:
Length of Data:
Press a High-light Letter to select
Esc ==> Quit from this menu
Yes
Yes
Yes
Yes
No
No
No
No
No
2 mS
No
9600
NONE
8 -bits
17
