14 : Setup MenuS
PARAMETER
TEMPO EXIT COUNT
(1-6)
LOOPER MODE/TRUE
BYPASS
(TAP/HOLD, HOLD/TAP)
LOOPER LOCATION
NOISEGATE OFFSET
(+/- 40.00 dB)
GLOBAL DETECTOR
(IN 1 PRE, IN 2 POST)
DEFAULT SCENE
(1-8)
GLOBAL: OUT PRE/OUT POST PAGES
Two separate pages each provide a 10-band global graphic EQ, plus a master GAIN adjustment control for
OUT PRE and OUT POST. Use these to make global adjustments to the tone or level of ALL presets. This
is convenient when you need to compensate for a different backline, or if a particular performance space
seems overly bright or boomy. The master GAIN fader should be used with care as it impacts unity gain and
signal-to-noise ratio, and can cause clipping.

Reminder: You do not need to STORE settings in the SETUP menu. EXIT returns to Stompbox Mode.
GLOBAL: CUSTOM SCALES PAGE
The Custom Scales ("
SCALES
found in the Pitch Shifter block.

Reminder: You do not need to STORE settings in the SETUP menu. EXIT returns to Stompbox Mode.
PARAMETER
CUSTOM SCALE NUMBER
(1–32)
___ SHIFT (+/- 24)
Description
Determines how long it takes to return to Stompbox Mode after you tap
the tempo footswitch. 1 is the shortest, 6 the longest.
Selects between one of the two following options:
TAP/HOLD - Tap the footswitch to activate Looper Mode.
ƒ
PRESS & HOLD it to activate True Bypass.
(Tap again to exit True Bypass).
HOLD/TAP - PRESS & HOLD the footswitch to activate Looper Mode.
ƒ
TAP it on or off to activate True Bypass.
Determines the global default looper location (see
Globally raises or lower the THRESHOLD of the Noise Gate. Note that if the
THRESHOLD for a given preset is set to "OFF" the Global Offset will have no
page 45
effect. See for more on the Noise Gate.
Sets whether IN 1 [PRE] or IN 2 [POST] is used as the global detector for
pitch and level functions (tuner, envelope, ADSR, Harmonizer, etc.). If your
rig is POST ONLY, set this to IN 2 POST. Otherwise, don't make changes.
Sets the default scene for ALL presets and is provided for those players who
want SCENE 5, (bottom row, far left) to be selected by default.
") page of the GLOBAL menu is used to configure scales for the CUSTOM type
Description
Selects from among the 32 global custom scales available to edit using the
12 parameters which follow.
These 12 parameters are used to set the shift amount for each of the 12
steps of the chromatic scale. Range is +/- 24 semitones (+/- two octaves).
To set up a custom scale, select its number in the field above and then set
each of the 12 pitch values as desired. Changes take effect immediately,
with no need to STORE.
63
page 59).
