Additional components
Power Module
Battery
RC receiver
GPS + COMPASS
The Power Module incorporates
both a way to power your autopilot,
accessories and report battery volt-
age and curret to the PXF.
on-board switching regulator out-
puts 5.3V at a maximum of a 2.25A,
and can be used up to 18 Volts (4S
LIPo) and at a maximum of 90 amps.
It is ready to use with XT-60.
An electric battery is a device con-
sisting of two or more electrochemi-
cal cells that convert stored chemical
energy into electrical energy.
Receives the radio values from Radio
Control and shares it with Erle-Brain
using PPM encoding.
Determines the position of the
copter and its cardinal orientation. It
must be placed in the highest part of
the
connection
ference with Erle-Brain.
ERLE-COPTER DIY UBUNTU CORE DRONE KIT
vehicle for better satellite
and
to avoid
The
inter-
