- Page 1 Erle-Copter, a smart drone powered by Linux Operation Manual...
-
Page 2: Table Of Contents
........14 A Erle-Brain B ROS C Specification D Resources E License Erle-Copter, a smart drone powered by Linux... -
Page 3: Introducing Erle-Copter
Together with Canonical and the Open Source Robotics Foundation, we are pushing a new mar- ketplace for robot and drone applications. An open platform that attracts innovators and ex- perts to collaborate and compete in the future marketplace of drone and robot applications. More at ubuntu.com/things. Erle-Copter, a smart drone powered by Linux... -
Page 4: Parts
May 21, 2015 2 PARTS Below the parts that Erle-Copter contains are described. Do not hesitate and ask questions in forum. Radio controller The Power Module incorporates both a way to power your autopilot, accessories and report battery voltage and current to Erle-Brain. - Page 5 Provides high gain WIFI connection to Erle-Brain 4 x Electronic speed controller (ESC). 4 x Brushless motors. GPS + Compass Radio communicatios in 2.4Ghz band Telemetry 915MHz or 433MHz Propellers 10×4.5 Propellers 10×4.5 (self-tightening) Erle-Copter, a smart drone powered by Linux...
-
Page 6: Safety And Failsafes
RADIO FAILSAFE Always use the controller as a primary or backup control system when flying. Ensure that the controller is turned on any time Erle-Copter is powered. If this failsafe is enabled it will get triggered under the following circumstances:... - Page 7 (standard - altitude hold mode). Always be prepared to regain manual control of Erle-Copter at any time while flying and choose an unobstructed flying area to im- prove GPS signal strength. When flying a mission, we recommended changing the GPS failsafe behavior to land.
- Page 8 LOW BATTERY When the battery reaches a low state (voltage under certain value), Erle-Copter will land with a quick repeating tone. If Erle-Copter reaches the low battery limit during a mission, it will re- turn to the launch point before landing.
-
Page 9: Learn To Fly
May 21, 2015 4 LEARN TO FLY THROTTLE Erle-Copter, a smart drone powered by Linux... - Page 10 May 21, 2015 Flight Tip When adjusting orientation, move the left stick horizontally without changing its vertical position. Erle-Copter, a smart drone powered by Linux...
- Page 11 Erle-Copter moves according to its orientation. The yellow arms face forward, and the black arms face backward. Before using the right stick, use yaw to keep Erle-Copter fac- ing in outward orientation so that the black arms face towards you and the yellow arms face away from you.
-
Page 12: Flying Modes
Good GPS position, low magnetic interference on the compass and low vibrations are all important in achieving good loiter performance. RTL stands for ”Return to Launch” and when activated, Erle-Copter navigates from its current position to hover above the home position. The home positioned is set as the point where the copter was armed. - Page 13 . Follow Me mode uses dynamic waypoint feature. AUTO In Auto mode Erle-Copter will follow a pre-programmed mission script stored in the brain which is made up of navigation commands (i.e. waypoints) and “do” commands (i.e. commands that do not affect the location of the copter including triggering a camera shutter).
-
Page 14: First Flight
5 FIRST FLIGHT 5.1 ATTACHING PROPELLERS Erle-Copter uses four propellers. Propellers generally come in pairs and there are classified by the color of each central nut. One should turn in clockwise direction and the other in the oppo- site. Clockwise propellers are also known as ”pusher kind” propellers and are marked with an ”R”... - Page 15 fly. • Release the right stick to level. • Lower the left stick below center to descend. After landing, hold the left stick down-left until the motors stop spinning. Disconnect the battery Erle-Copter, a smart drone powered by Linux...
-
Page 16: A Erle-Brain
• RC Input using either PPM-SUM or S.Bus • 1 USB Host, 1 UART, 3 I2C, Buzzer connector, Failsafe connector. The hardware has many more peripherals and we are working hard to bring them out. Erle-Copter, a smart drone powered by Linux... -
Page 17: B Ros
Android phone driving motors. This makes ROS really flexible and adaptable to the needs of the user. ROS is also open source, maintained by many people. More at http://wiki.ros.org/ Gitbook ROS Answers is a crowd-sourced resource for everything ROS. Erle-Copter, a smart drone powered by Linux... -
Page 18: C Specification
15-20 minutes* FRAME 5: FLIGHT TIME Flight time depends on wind conditions, elevation, payload, temperature, humidity, fly- ing mode and pilot skill. D RESOURCES Hardware https://erlerobotics.com/blog/erle-copter/ Store https://erlerobotics.com/blog/tienda Forum forum.erlerobotics.com Online doc Erle-Copter gitbook Erle-Copter, a smart drone powered by Linux... -
Page 19: E License
Creative Commons, 171 Second Street, Suite 300, San Francisco, California, 94105, USA. If you plan on using this material for commercial purposes get in touch with us at contact@erlerobot.com Erle-Copter, a smart drone powered by Linux...
