IS205
Thank you very much for purchasing a Fostex product.
This manual provides instructions for basic use of the unit.
Read this before using the unit for the first time.
Owner's Manual
© FOSTEX COMPANY All Rights Reserved
8588135000
(594370)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IS205 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fostex IS205

  • Page 1 8588135000 (594370) Owner's Manual Line selector IS205 Thank you very much for purchasing a Fostex product. This manual provides instructions for basic use of the unit. Read this before using the unit for the first time. © FOSTEX COMPANY All Rights Reserved...
  • Page 2: Important Safety Instructions

    „ WARNINGS and PRECAUTIONS „ • WARNING: Do not install this equipment in a confined space such as a book • CAUTION: The symbol To prevent electric shock hazard, do not connect to case or similar unit. mains power supply while grille is removed. • WARNING: Mains plug is used as disconnect device and it should remain • WARNING: An apparatus with CLASS I construction shall be connected to a readily operable during intended use.
  • Page 3 Introduction „ Features of the IS205 „ • IS205 is an audio line selector with 2 inputs and 5 outputs. • You can switch between several active speakers and 2 types of music source. • Equipped with a volume knob to control the source volume. • You can adjust the DIP switch settings to automatically switch between speakers. • Equipped with highly reliable push switches. • One of the 5 outputs is designed to be connected to a subwoofer or similar, and can be turned on and off independently. „ Accessories „ Supplied accessories are listed below. Confirm that these accessories are present after purchase. • AC adaptor × 1 • Owner’s manual (this manual) × 1...
  • Page 4: Part Names And Functions

    Part names and functions Top panel Rear panel ③ O U T P U T I N P U T 1 P O W E R DC IN POWER INPUT VOLUME O U T P U T INPUT 12V 1.5A MODE INPUT1 OUTPUT...
  • Page 5: Automatic Switching

    Settings „ Enabling and disabling outputs „ 1 Turn off the power. 2 Turn on the power while holding down the [OUTPUT] switches (from 1 to 5) you want to enable. The enabled switches light in green. The unit memorizes which switches are enabled/disabled and will keep these settings the next time the device is turned on. „ Configuring DIP switch settings „ Switch position guide DIP switch (default settings) Automatic switching Automatic switching enables the unit to switch automatically between outputs 1 to 4. You can turn the function on and off using DIP switches 1 to 3. You can set the switching interval between 5 seconds and 35 seconds in 5 second increments. The following table shows how to configure the DIP switches for each switching interval length. Set interval length 1 (5 seconds) 2 (10 seconds) 3 (20 seconds) (seconds) The function is turned off • Automatic switching cannot be used with OUTPUT5.
  • Page 6: Automatic Standby

    Automatic standby When DIP switch no. 4 is on, if no OUTPUT is selected for approximately 4 hours, the unit automatically goes into standby. In standby, all LED turn off and power consumption is reduced to 0.5 W or below. Automatic standby is canceled when you press either an [INPUT] or [OUTPUT] switch, or turn the power switch on or off. The unit does not enter automatic standby when the DIP switch is off. Setting time (seconds) Auto standby is off Auto standby is on • When automatic switching is turned on, the unit does not enter automatic standby regardless of the DIP switch setting. Block diagram VOLUME INPUT1 OUTPUT1 (RCA) OUTPUT2 INPUT2 (MINI-JACK) OUTPUT3 OUTPUT4 OUTPUT5...
  • Page 7: Dimensional Drawings

    Dimensional drawings OUTPUT INPUT1 POWER 12V 1.5A INPUT VOLUME OUTPUT INPUT INPUT2 Specifications [INPUT 1] terminal Connector RCA pin jack [INPUT 2] terminal Connector Φ3.5 mm stereo mini jack [OUTPUT] 1 - 5 terminals Connector RCA pin jack Power 12 V DC Power consumption 2.4 W maximum (automatic standby mode: 0.5 W or below) External dimensions (mm) 185 (width) × 40 (height, including rubber feet) × 96 (depth) Weight 470 g...
  • Page 8: Declaration Of Ec Directive

    The Affect of Immunity on This Equipment The affect of the European Specification EN61000-6-1 (coexistence of electromagnetic waves - common immunity specification) on this equipment are as shown below. In the electrical fast transient/burst requirements, surge, conducted disturbances by radio-frequency fields, power frequency magnetic field, radiate electromagnetic field requirements and static electricity discharging environment, this could be affected by generation of noise in some cases. FOSTEX DISTRIBUTORS LIST IN EUROPE * Including non-EU countries (as of Oct. 2014) Austria Hungary Spain & Portugal NAME: Mega Audio GmbH NAME: Mega Audio GmbH NAME: ATCONSUMER (Consumer, Hi-Fi system & Speaker Components) ADD: Stromberger Str.
