Elnur CSH12 Installation Instructions And Owner's Manual

R1, R2, R3, R4...Heating elements
RAC............Accelerating resístance
Tc..............Charge control thermostat
Ts..............Safety cut out
Tl...............Temperature limiter
Ta..............Ambient thermostat
IMPORTANT
This equipment is supplied with a main connector. All the wires must be coloured in accordance
with the following code:
Green & Yellow – Earth Blue – Neutral
As part of the policy of continuous product improvement the manufacturer reserves the right to alter specifications without notice.
Wiring diagrams
CE...... Convector element with built in thermal cut out
C........ Switch
PE...... Earth
L.........Phase
N........ Neutral
Brown - Live.
COMBINED STORAGE HEATERS
CSH12 CSH12A
CSH18 CSH18A
CSH24 CSH24A

INSTALLATION INSTRUCTIONS

AND
OWNERS GUIDE
