Table of contents

1.0 Regulatory information .................................2
2.0 Technical data ................................................2
3.0 Safety ............................................................. 6
4.0 Installation ................................................... 6
5.0 Daily use ....................................................... 17
6.0 Servicing .......................................................19
7.0 Maintenance ............................................... 20
8.0 Optional Equipment ................................... 20
9.0 Recycling ...................................................... 20
10.0 Warranty ...................................................... 20
On all our products there is a label
Product:
Jøtul
indicating the serial number and
Room heater fired by solid fuel
year. Write this number in the
Standard :
Minimum distance to adjacent combustible materials:
place indicated in the installation
Minimum distance to adjacent combustible materials:
Emission of CO in combustion products :
Flue gas temperature :
instructions.
Nominal heat output :
Efficiency :
Operation range
:
Fuel type :
Operational type :
The appliance can be used in a shared flue.
Always quote this serial number when
Country Classification Certificate/ Approved by contacting your retailer or Jøtul.
standard
Norway Klasse II
SP Sveriges Provnings- och
SP
Sweden OGC
Forskningsinstitut AB
SP Swedish National
Testing and Research
EUR Intermittent EN
Institute
Follow user`s instructions. Use only recommended fuels.
Montage- und Bedienungsanleitung beachten.
Verwenden Sie nur empfohlenen Brennstoffen.
Respectez les consignes d'utilisation. Utilisez uniquement
les combustibles recommandés.
Serial no: Y-xxxx, Year: 200x
Manufacturer: 221546
Jøtul AS
POB 1441
N-1602 Fredrikstad
Norway
2
Serial no.

1.0 Regulatory information

Installation of a fireplace must be according to local codes and
regulations in each country.
All local regulations, including those that refer to national and
European standards, shall be complied with when installing the
product.
Both an installation manual with technical data and a general
user and maintenance manual accompany the product. The
installation can only be taken into use after it has been checked
by a qualified inspector.
An approval label made of heat resistant material is located
on the heat shield at the back of the product. This contains
information about identification and documentation for the
product.

2.0 Technical data

Material:
Finish:
Type of fuel:
Max. log length:
Smoke outlet:
Flue pipe dimension:
Outside air connector:
2 connectors for
hot air outlet:
Weight:
Optional extras:
Product dimensions, distances:
Technical data in accordance with
Nominal heat output:
Flue gas flow rate:
Recommended chimney draught:
Efficiency:
CO emissions (13% O2):
OGC emissions (13% O2)
Dust emissions
Flue gas temperature:
Operation:
Intermittent operation means normal use of a fireplace. This
means that to refuel the fire, you add more wood as soon as the
previous load of wood has burned down to embers.
Cast iron
Black paint
Wood
50 cm
Top
Ø 150 mm/177 cm2 cross
section
Flexible aluminium pipe
Ø80 mm/Ø100 mm
Flexible aluminium pipe Ø
150 mm
Approx. 136 kg
Frame wide, Fan, outside
air connection kit Ø 100
mm, Adaptorfor flue pipe.
See Fig. 1
13229
7.0 kW
5.9 g/s
12 Pa
78%@7.0 kW
0.06%
32 mg/Nm3
5 mg/Nm3
295°C
Intermittent
