OPERATION AND MAINTENANCE MANUAL
615
EcoG
un
Automatic Air Spraying Gun
II 2 G
T
.
he equipmenT is designed To professional use only
C
arefully read and undersTood This manual before iTs
.i
Commissioning
mproper operaTion of The spraying gun may
/
resulT in severe injury of The operaTor and
or damage of
.
The equipmenT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Durr EcoGun 615
Summary of Contents for Durr EcoGun 615
- Page 1 OPERATION AND MAINTENANCE MANUAL EcoG Automatic Air Spraying Gun II 2 G he equipmenT is designed To professional use only arefully read and undersTood This manual before iTs Commissioning mproper operaTion of The spraying gun may resulT in severe injury of The operaTor and or damage of The equipmenT...
-
Page 3: Table Of Contents
Cleaning and Maintenance Principles Important Notes for Trouble-Free Operation PRODUCT TESTING PRODUCT PACKING DISPOSAL WARRANTY TERMS The warranty does no apply as follows ECOGUN 615 COMPONENT SPECIFICATION ILLUSTRATIONS OF ECOGUN 615 GUN COMPONENTS NOZZLE SYSTEM TABLE WIRING DIAGRAM DIMENSIONAL SKETCH... -
Page 4: Safety Principles For Operation Of Equipment
EcoGun 615 SAFETY PRINCIPLES FOR OPERATION OF EQUIP- MENT FOR SPRAYING OF LIQUIDS Earthing of the equipment (for combustible applied materials) Under certain circumstances, high flow rates of the liquid and high spraying pressure can results in generation of the electrostatic change on the equipment. -
Page 5: Equipment Description
EQUIPMENT DESCRIPTION The EcoGun 615 automatic spraying gun is designed to applications of liquids by pressure supply of the coating material (hereinafter referred to as NH), glue etc. The gun consists of two functional parts: »... -
Page 6: Use
The EcoGun 615 automatic spraying gun is designed to the surface treatment of the product by air spraying. The nozzle system is designed to pressure supply of the applied material. It is suitable... -
Page 7: Technical Parameters
EcoGun 615 TECHNICAL PARAMETERS Air consumption for atomizing ......145-640 l.min Power (acc. to nozzle system) ......50-1500 g.min Effective atomizing air range ........max. 6 bars Recommended control air pressure ........4 bars Air quality (atomizing) .............. - Max. dew point ..........+3°C - Max. -
Page 8: Commissioning
EcoGun 615 COMMISSIONING Before commissioning the gun must be cleaned to remove all preserving agents by suitable degreaser. Connect the control air and atomizing air hoses. Connect the NH hose, tighten the sleeve nut to the NH fitting. Control air is closed via the three-way solenoid valve of approx. -
Page 9: Hose Installation
EcoGun 615 relation to type of the NH, it is possible for fit the pin seal from PTFE or from graphite for particularly abrasive materials. » Advance: set the pin length in the piston to create clearance approx. 1.5 mm between the piston and the pin nut face and secure with the locking nut. -
Page 10: Maintenance And Cleaning
EcoGun 615 MAINTENANCE AND CLEANING leAnIng And AIntenAnCe rInCIPles 1. Prevent drying of the applied material in the gun and on the surface. Clean always by applicable solvent recommended by the manufacturer of the material. 2. Do not clean the holes in the nozzle system by metal objects. -
Page 11: Product Testing
EcoGun 615 PRODUCT TESTING » Each equipment is subject to the functional and pressure test at the production plant. PRODUCT PACKING » Acc. to individual delivery items. DISPOSAL » After expiration of operation life of the components, resp. automatic gun, they can be submitted to the sorted waste after cleaning. -
Page 12: Ecogun 615 Component Specification
EcoGun 615 ECOGUN 615 COMPONENT SPECIFICATION No. of Position Name Identification No. pieces Gun body Not delivered as spare part Nozzle assembly Acc. o the nozzle combination table Packing 832 577 „O“-ring 105 028 „O“-ring 105 129 Piston 806 045... -
Page 13: Illustrations Of Ecogun 615 Gun Components
EcoGun 615 ILLUSTRATIONS OF ECOGUN 615 GUN COMPO- NENTS... -
Page 14: Nozzle System Table
EcoGun 615 NOZZLE SYSTEM TABLE Air hose Nozzle assembly Type Identification No. Type Identification No. 14 S 906 056 Enamels and 904 889 18 S 906 057 glazes 22 S 906 058 12 Z 906 059 904 887 14 Z... -
Page 15: Wiring Diagram
EcoGun 615 WIRING DIAGRAM Ecogun 615 Legend: 1. Pressure medium source (transfer pump, pressure tank, resp. central distribution system) 2. Pressure air source (pressure air supply) 3. Solenoid valve 3/2 (for control air) - min. flow rate 150 l.min 4. Air pressure controls... -
Page 16: Dimensional Sketch
EcoGun 615 DIMENSIONAL SKETCH ~ 220 38,5 ~ 175... - Page 17 EcoGun 615...
- Page 18 EcoGun 615...
- Page 19 EcoGun 615...
- Page 20 . d u r r - c z . c z N02.030 GB Dürr Systems Czech Republic a.s. rev: 02 Podolí 1237 | 584 01 Ledeč nad Sázavou | Czech Republic 2014/10 Tel.: +420 569 726 094 | Fax: +420 569 726 096 | E-mail: info.cz@durr.com...
