Technical specifications

Audio
Power output
CXR120:
120 watts RMS per channel, 6 ohms
(two channels driven),
100 watts RMS per channel, 8 ohms
(two channels driven),
60 watts RMS per channel, 8 ohms
(all 7 channels driven)
CXR200:
200 watts RMS per channel, 6 ohms
(two channels driven),
170 watts RMS per channel, 8 ohms
(two channels driven),
120 watts RMS per channel, 8 ohms
(all 7 channels driven)
THD
<0.006% @1kHz
Crosstalk
<-80dB
Frequency response
10Hz - 20kHz ±1dB
S/N Ratio
>90dB 'A' weighted
Audio input impedance
47kOhms / 175mV or greater
/Sensitivity
Digital input impedance
75 ohms (Coaxial/S/P DIF)
Tone control
Bass: ±10dB @ 100Hz
Treble: ±10dB @ 10kHz
Tuner FM mode: 87.5-108MHz
AM mode:
UK/EU: 522-1620kHz
CU: 530-1710kHz
HDMI
HDMI 2.0, HDCP 2.2, ARC supported on HDMI
1 output
General
Architecture Cirrus Logic CS49834A 3core 32bit 300MHz
DSP
Panasonic MN864788 HDMI 2.0
Receiver/Switch
Panasonic MN864787 HDMI 2.0
Transmitter/Scaler
Silicon Image SiI1292 MHL/HDMI bridge
CXR120:
Cirrus Logic CS42528 24bit 192kHz DAC
CXR200:
Texas Instruments PCM1795 32bit 192kHz
DAC
(Left and Right channel only)
Cirrus Logic CS42528 24bit 192kHz (other
channels)
Audio Inputs: CXR120:
3 x Analogue, Tuner (FM/AM), 7.1 multi-channel
analogue direct, 2 x digital coaxial, 2 x optical
CXR200:
4 x Analogue, Tuner (FM/AM), 7.1 multi-channel
analogue direct, 2 x digital co-axial, 4 x optical
Video Inputs: CXR120:
6 x HDMI 2.0, 1 x MHL compatible
(HDMI 1.4 - max 1080p)
CXR200:
6 x HDMI 2.0, 2 x MHL compatible
(HDMI 1.4 - max 1080p)
Main Audio Outputs: CXR120:
7 Amplified Speaker Outputs, 2 x subwoofer
outputs
CXR200:
7 Amplified Speaker Outputs, L+R preamp
outs, 2 x subwoofer outputs
Video Output: CXR120:
2 x HDMI 2.0, ARC through HDMI 1
CXR200:
2 x HDMI 2.0, ARC through HDMI 1, Zone 2
through HDMI 2
Other connections: CXR120:
1 x 1/4" / 6.35mm Headphone Output (32 To
600 ohms recommended), IR emitter input, IR
receiver input, 2x IR outputs, 2 x 12V trigger
outputs, 1 RS232C, 1 IEC type mains inlet,
Wi-Fi module, RJ45 Ethernet, BT100 Bluetooth
(not supplied), Spotify Connect
CXR200:
1 x 1/4" / 6.35mm Headphone Output (32 To
600 ohms recommended), IR emitter input, IR
receiver input, 3 x IR outputs, 3 x 12V trigger
outputs, 1 RS232C, 1 IEC type mains inlet,
Wi-Fi module, RJ45 Ethernet, BT100 Bluetooth
(not supplied), Spotify Connect
Standby power <0.5W
consumption
Max power consumption CXR120: 1000W
CXR200: 1800W
Dimensions - H x W x D 165 x 430 x 420mm (6.5 x 16.9 x 16.5'')
Weight CXR120: 13.2kg (29lbs)
CXR200: 15.7kg (34.5lbs)
StreamMagic network streaming module
Streaming protocols RTSP (Real Time Streaming Protocol)
MMS (Microsoft Media Server Protocol)
HTTP (Hyper Text Transfer Protocol)
Compatibility UPnP 16-24 bit, 32-192kHz
USB Media 16-24 bit, 32-192kHz
Audio formats WAV containing uncompressed PCM 16/24-bit
32-192kHz
FLAC containing losslessly compressed
PCM 16/24-bit 32-192kHz
ALAC 16/24-bit 32-192kHz
AIFF containing uncompressed PCM 16-bit
32-48kHz
Microsoft® Windows MediaTM Audio (WMA 9
Standard) 32-320kbps
MP3 (CBR or VBR) 16-320kbps
AAC, HE AAC and AAC+ (CBR or VBR) 16-
320kbps
OGG Vorbis 32-
Playlists ASX (Microsoft® playlist format) M3U, PLS
Wi-Fi IEEE 802.11 b/g or n (2.4GHz connection used
only)
Wi-Fi Encryption WEP, WPA, WPA2
Ethernet IEEE 802.3, 10 Base-T or 100 Base-T
USB USB 2.0 current limited to 1A
File Systems FAT32, NTFS
Zone 2 (CXR200 only)
1 HDMI 2.0 output
1 Analogue audio output
1 amplified speaker output
