OPERATOR'S MANUAL
CAUTION
BEFORE INSTALLING AND
USING THIS AIR CONDITIONER,
IT IS IMPORTANT THAT THIS
MANUAL BE READ AND
UNDERSTOOD THOROUGHLY
900-031-00
Keep This Manual
With Air Conditioner

AIR CONDITIONER

P24 SERIES
P28 SERIES
P36 SERIES
Find additional information on this
model at kooltronic.com, or use the
Technical
Documents
below.
Technical
Documents
KOOLTRONIC, INC.
30 Pennington-Hopewell Road
Pennington, NJ 08534
609 • 466-3400
FAX: 609 • 466-1114
www.kooltronic.com
QR
code

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P24 SERIES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kooltronic P24 SERIES

Summary of Contents for Kooltronic P24 SERIES

  • Page 1: Air Conditioner

    P24 SERIES P28 SERIES P36 SERIES Find additional information on this Keep This Manual model at kooltronic.com, or use the Technical Documents code below. With Air Conditioner Technical Documents AIR CONDITIONER OPERATOR'S MANUAL CAUTION KOOLTRONIC, INC. 30 Pennington-Hopewell Road BEFORE INSTALLING AND...

  • Page 2: Table Of Contents

    Warranty I. Introduction Kooltronic Air Conditioners are designed to provide a cool, dehumidified environment for your electronic components. There are models to fit virtually all sizes and shapes of electronics enclosures, in capacities ranging from 1,000 to 30,000 BTU/H. Our "closed-loop"...

  • Page 3: Incoming Inspection

    Manual. See section VI PRE-INSTALLATION TESTING. 2) Before operating the Kooltronic Air Conditioner be certain that it is placed in its correct mounting position. All Air Conditioners containing an MM, NM, P, or V as part of the model number are designed to operate in a vertical position only.
  • Page 4 IV. Product Identification and Labels Each Kooltronic Air Conditioner includes an identification label. This label provides: Œ Model Number  Serial Number Ž Electrical power characteristics  Maximum and minimum ambient operating temperatures  Cooling capacity ‘ Type and amount of refrigerant required for recharging ’...

  • Page 5: Principles Of Operation

    V. Principles of Operation Kooltronic Air Conditioners are required when the equipment operating temperature must be kept near or lower than the ambient room temperature, and/or the cabinet must be sealed from dust, fumes, oil, corrosives and other contaminants. This Air Conditioner utilizes a “Closed-Loop Cooling System” to ensure optimum performance of the installed components.

  • Page 6: Pre-Installation Testing

    14. If any cover plug is removed to adjust the unit, make certain to put it back in place to maintain the integrity of the closed-loop airflow system. NOTE: Before shipment all Kooltronic, Inc. Air Conditioners are subjected to a performance test.

  • Page 7: Specific Model Data

    6015-00-129 Evaporator Blower Motor 0261-13 0261-13 0261-13 0261-08 Evaporator Blower Motor Capacitor N/A 0452-03 Evaporator Blower Assembly 5417-00-25 8009-00-38 5417-00-25 5417-00-35 Filter 8751F 8751F 8751F 12251F NOTE: Part Numbers shown are for 115v/60Hz/1Ø. For 230v/60Hz/1Ø and all 50Hz consult Kooltronic.

  • Page 8: Drawings And Dimensions

    Drawings and Dimensions P24 SERIES MOUNTING PLAN POWER CORD .312 DIA. HOLES THERMOSTAT ADJUSTMENT DRAIN FILTER TYP. P28 & P36 SERIES POWER CORD .312 DIA. HOLES 1.50 DIA. POWER CORD HOLE FILTER TYP. THERMOSTAT ADJUSTMENT DRAIN TYP. Œ  ...

  • Page 9: Technical Data

    Technical Data Approx. " " Weight Series Ambient Height BTU/H Temp. °F Running (lbs.) 24 28 36 Model Rating Max./Min. Volts Amps KA4C1P_ _L 1000 120/50 115/100 60/50 14.2 KA4C1P_ _L56 1000 120/50 50/60* 14.2 K2A4C1P_ _L 1000 125/50 230/200 60/50 K2A4C1P_ _L5 1000...

  • Page 10: Wiring Schematics

    (OPTIONAL) COMPRESSOR FOR KA4C1-4P24 ONLY RELAY NOTES: 1) ADDITIONAL OPTIONS ARE WIRED TO AN INDIVIDUAL 3 POSITION TERMINAL BLOCK SHOWN ABOVE. 2) 50Hz: CONTACT KOOLTRONIC P24 SERIES P28 & P36 SERIES, 2000-4000 BTU/H WD-176 REV. C ON/OFF EVAP SWITCH BLOWER...

  • Page 11: Maintenance

    3) The filters may be sprayed with Kooltronic A-16 Filter Recoating Adhesive to trap fine airborne contaminants, or they may simply be dried and reinstalled as strainer type filters.
  • Page 12 Refer to the data on the unit name plate which specifies the type of refrigerant and the amount of charge in ounces. E. Relocation If your Kooltronic Air Conditioner has to be moved to another location by truck, the following precautions should be taken: De-mount Air Conditioner from equipment, controller or enclosure.

  • Page 13: Trouble Shooting

    IX. Trouble-Shooting Each Kooltronic Air Conditioner is engineered for performance and built for reliability. They are designed to require no routine maintenance other than the cleaning of ambient air filters. If your air conditioner should require service, we have compiled a trouble-shooting chart to assist your service personnel.

  • Page 14: X. Accessories

    Not available due to design C Standard on P24 K Available on NP59 configuration D Not available on P24 series CONDENSATE EVAPORATOR KIT: This device LOW TEMPERATURE CONTROL: Recommended in attaches to bottom of Air Conditioner. Condensate is col- situations of extremely low ambient temperatures and/or lected, vaporized and discharged to ambient.
  • Page 15 THIS WARRANTY CONSTITUTES THE ENTIRE WARRANTY WITH RESPECT TO THE PRODUCT AND IS IN LIEU OF ALL OTHERS, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY AND WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND IN NO EVENT IS KOOLTRONIC RESPONSIBLE FOR ANY CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER.
