NP59 and TP59 SERIES Keep This Manual With Air Conditioner AIR CONDITIONER OPERATOR'S MANUAL CAUTION KOOLTRONIC, INC. 30 Pennington-Hopewell Road BEFORE INSTALLING AND Pennington, NJ 08534 USING THIS AIR CONDITIONER, 609 • 466-3400 IT IS IMPORTANT THAT THIS MANUAL BE READ AND FAX: 609 •... -
Page 2: Table Of Contents
Warranty I. Introduction Kooltronic Air Conditioners are designed to provide a cool, dehumidified environment for your electronic components. There are models to fit virtually all sizes and shapes of electronics enclosures, in capacities ranging from 1,000 to 30,000 BTU/H. Our "closed-loop"... -
Page 3: Incoming Inspection
Manual. See section VI PRE-INSTALLATION TESTING. 2) Before operating the Kooltronic Air Conditioner be certain that it is placed in its correct mounting position. All Air Conditioners containing an MM, NM, P, or V as part of the model number are designed to operate in a vertical position only. - Page 4 IV. Product Identification and Labels Each Kooltronic Air Conditioner includes an identification label. This label provides: Œ Model Number Serial Number Ž Electrical power characteristics Maximum and minimum ambient operating temperatures Cooling capacity ‘ Type and amount of refrigerant required for recharging ’...
-
Page 5: Principles Of Operation
V. Principles of Operation Kooltronic Air Conditioners are required when the equipment operating temperature must be kept near or lower than the ambient room temperature, and/or the cabinet must be sealed from dust, fumes, oil, corrosives and other contaminants. This Air Conditioner utilizes a “Closed-Loop Cooling System” to ensure optimum performance of the installed components. -
Page 6: Pre-Installation Testing
14. If any cover plug is removed to adjust the unit, make certain to put back in place to maintain the integrity of the closed-loop airflow system. NOTE: Before shipment all Kooltronic, Inc. Air Conditioners are subjected to a performance test. -
Page 7: Specific Model Data
Dimensions (inches) are for reference only and are subject to change. Kooltronic Air Conditioners have been engineered to be installed easily. To avoid damaging your Air Conditioner, please read the following information before installation: 1. Remove and save the four screws holding the Mounting Template and Assembly Bracket (M/TAB) to the unit. -
Page 8: Drawings And Dimensions
DIMENSIONS (inches) Model NP59 Series TP59 Series * Other drain outlets are available - contact KOOLTRONIC Dimensions (inches) are for reference only and are subject to change. -
Page 9: Technical Data
0452-06 Evaporator Blower Assembly 6015-00-130 6015-00-130 Filter 20001F 20001F NOTE: Part Numbers shown are for 60Hz/1Ø. For 50Hz consult Kooltronic. Standard Features Built-in Condensate Evaporator M/TAB Mounting System EMI/RFI Suppressor NEMA 12 Rating Maintained (UL50) Low-ODP Refrigerant Reversible Condenser Outlet Blower... -
Page 10: Wiring Schematic
Wiring Schematic EVAPORATOR BLOWER MOTOR CAP. SUPPRESSOR LOW AIR FLOW DETECTOR CONDENSATE CONDENSATE EVAPORATORS BK-N.0. EXHAUST FAN TO CUSTOMER WE-COM ALARM SYSTEM RD-N.C. CRANKCASE HEATER TERMINAL OPTION THERMAL THERMOSTAT BLOCK CUT OUT SET 55F HEATER HEATER RELAY OPTIONAL SHORT CYCLE TIMER TERMINAL BLOCK... -
Page 11: Maintenance
3) The filters may be sprayed with Kooltronic A-16 Filter Recoating Adhesive to trap fine airborne contaminants, or they may simply be dried and reinstalled as strainer type filters. - Page 12 Refer to the data on the unit name plate which specifies the type of refrigerant and the amount of charge in ounces. E. Relocation If your Kooltronic Air Conditioner has to be moved to another location by truck, the following precautions should be taken: De-mount Air Conditioner from equipment, controller or enclosure.
-
Page 13: Trouble Shooting
IX. Trouble-Shooting Each Kooltronic Air Conditioner is engineered for performance and built for reliability. They are designed to require no routine maintenance other than the cleaning of ambient air filters. If your air conditioner should require service, we have compiled a trouble-shooting chart to assist your service personnel. -
Page 14: X. Accessories
X. Accessories Air Cooled Water Panel Mounted Cooled Mini NP33 Horizontal Accessories and Options NP36 Rack Panel NP47 Mounted Mounted Mounted NP17 P59* NP59 (H & V) (HT) (WP) Adapter Plate for Rack Mounting • Air Deflectors • • • •... - Page 15 THIS WARRANTY CONSTITUTES THE ENTIRE WARRANTY WITH RESPECT TO THE PRODUCT AND IS IN LIEU OF ALL OTHERS, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY AND WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND IN NO EVENT IS KOOLTRONIC RESPONSIBLE FOR ANY CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER.
- Page 16 Free comprehensive Design required position Guide / Catalog to assist in Visit us online at: ● Rugged construction selecting the proper Air www.kooltronic.com ● Precision ball-bearing motors Conditioner, Heat Exchanger, E-Mail: sales@kooltronic.com ● Blower or Fan. Accessories and options available...
