Summary of Contents for Lochinvar ER(N
-
Page 1: Replacement Parts List
ERP-RP-02 Replacement Parts List PARTS & SERVICE DEPARTMENT Nashville, Tennessee 615-889-8900 • Fax: 615-547-1000 www.Lochinvar.com Residential Pool Heaters ER(N, L) 152-402... - Page 2 HEAT EXCHANGER ASSEMBLIES ASME NON-ASME GAS TRAIN ASSY ERP-RP-02 2 of 4...
- Page 3 ITEM PART NO. BNR3417 MAIN BURNER BNR3416 BURNER W/ PRESSURE TAP ORF2406 ORIFICE NATURAL ORF2051 ORIFICE LPG VAL3412 IGNITION / GAS VALVE NATURAL VAL3413 IGNITION / GAS VALVE LPG PRS2004 SWITCH, GAS PRESSURE PRS3406 SWITCH, WATER PRESSURE PRS3428 SWITCH, AIR PRESSURE HLC2910 HIGH LIMIT 175 DEGREE TST2052...
- Page 4 ITEM PART NO. JKD6964 FRAME RUNNERS (2 PER HEX) JKD6965 FRAME RUNNERS (2 PER HEX) JKD6966 FRAME RUNNERS (2 PER HEX) JKD6967 FRAME RUNNERS (2 PER HEX) JKD6968 FRAME RUNNERS (2 PER HEX) DRV2400 DRAIN COCK GKT2412 GASKET, HEADER GKT2150 GASKET, HEADER FAN3040 COMBUSTION FAN...
