Lochinvar POWER-FIN PB/PF 1500 Replacement Parts List

2:1 boilers/water heaters
Hide thumbs
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual
PFR-07

Replacement Parts List

Power-Fin
2:1
®
PARTS AND SERVICE DEPARTMENT
Nashville, Tennessee
Boilers/Water Heaters
615-889-8900 • Fax: 615-547-1000
PB/PF 1500, 1700, 2000
www.Lochinvar.com
Up to serial #F05H0176841
2
30
31
10
4
32
12
11
4
11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWER-FIN PB/PF 1500 and is the answer not in the manual?

Questions and answers

Related Manuals for Lochinvar POWER-FIN PB/PF 1500

Summary of Contents for Lochinvar POWER-FIN PB/PF 1500

  • Page 1: Replacement Parts List

    PFR-07 Replacement Parts List Power-Fin ® PARTS AND SERVICE DEPARTMENT Nashville, Tennessee Boilers/Water Heaters 615-889-8900 • Fax: 615-547-1000 PB/PF 1500, 1700, 2000 www.Lochinvar.com Up to serial #F05H0176841...
  • Page 2 HEAT EXCHANGER ASSEMBLY PFR-07 2 of 4...
  • Page 3 ITEM PART FAN3009 FAN REPLACEMENT ASSEMBLY FAN3010 FAN REPLACEMENT ASSEMBLY FAN3011 FAN REPLACEMENT ASSEMBLY KIT3002 SWITCH, PRESSURE RLY3021 MOTOR DRIVE, VARIABLE FREQUENCY (VFD) RLY2724 BOARD, DISPLAY RLY2402 MODULE, IGNITION RLY3723 BOARD, CONTROL RLY3724 BOARD, CONTROL RLY3028 BOARD, CONTROL, I/O RESET RLY2706 RELAY, PUMP TRF2005...
  • Page 4 ITEM PART BNR3419 MAIN BURNER ASSEMBLY BNR3420 MAIN BURNER ASSEMBLY BNR3421 MAIN BURNER ASSEMBLY MSC2731 SIGHT GLASS, 1/2" PLT3400 IGNITOR, HOT SURFACE GKT2012 GASKET, IGNITOR GKT2103 GASKET, BLOWER VAL3004 ACTUATOR KIT VAL2710 VALVE, GAS 1-1/2" VAL2711 VALVE, GAS 2" VAL2044 VALVE, GAS 1-1/2"...

This manual is also suitable for:

Power-fin pb1500Power-fin pb1700Power-fin pb2000Power-fin pf1500Power-fin pf1700Power-fin pf2000
