Lochinvar COPPER-FIN CB-0495 Specifications

WATER
GALLON CAPACITY
HEATING SURFACE (SQ. FT.)
WATER CONNECTIONS
DRAIN
MAX. WATER FLOW RATE (GPM)
HEAD LOSS (FT. OF HD.)
MIN. WATER FLOW RATE (GPM) *
HEAD LOSS (FT. OF HD.) *
MAX. WORKING PRESSURE (PSI)
# OF RELIEF VALVES
RELIEF VALVE SIZE
RELIEF VALVE RATING (MBH)
RELIEF VALVE PRESSURE RATING (PSI)
GAS
INLET CONNECTION
MAX. INLET PRESSURE, NAT
MIN. INLET PRESSURE, NAT
MANIFOLD PRESSURE, NAT
MAX. INLET PRESSURE, LP
MIN. INLET PRESSURE, LP
MANIFOLD PRESSURE, LP
BTU/HR INPUT
BTU/HR OUTPUT
ELECTRICAL
VOLTAGE/HEATER
VOLTAGE/CONTROL
TOTAL AMPS
# OF ELECTRICAL CONNECTIONS
DIMENSIONS
HEIGHT
WIDTH (INCLUDES PUMP)
DEPTH
SERVICE CLEARANCES
FRONT
BACK
RIGHT SIDE
LEFT SIDE (PIPING)
TOP
VENTING
SIZE
VENT CATEGORY
VENT MATERIAL
MAXIMUM DRAFT
MINIMUM DRAFT
* Minimum flow rate and head loss are based on a 40°F temperature rise for CB0495-0745 models and based on a 60°F temperature rise for CB0986-2066 models
Lochinvar Corporation • 300 Maddox Simpson Pkwy • Lebanon, TN 37090 • 615-889-8900 / Fax: 615-547-1000
CB-PS-07 (Replaces CB-PS-06 01/09)
COPPER-FIN
(CB) 495,000 - 2,065,000 BTU/HR
CB-0495 CB-0645 CB-0745
1.7 1.9 2.0
59.0 76.8 88.1
2" 2" 2"
3/4" 3/4" 3/4"
55 55 55
6.5 6.7 6.8
21 21 25
0.7 1.6 2.3
160 160 160
1 1 1
1" 1" 1"
1,352 1,352 1,352
50 50 50
1-1/4" 1-1/4" 1-1/4"
10.5" w.c. 10.5" w.c. 10.5" w.c.
4.0" w.c. 4.0" w.c. 4.0" w.c.
1.8" w.c. 1.8" w.c. 1.8" w.c.
13.0" w.c. 13.0" w.c. 13.0" w.c.
8.0" w.c. 8.0" w.c. 8.0" w.c.
4.6" w.c. 4.6" w.c. 4.6" w.c.
495,000 645,000 745,000
400,950 522,450 603,450
120 120 120
24 24 24
8.0 8.0 8.0
1 1 1
33-14" 33-14" 33-14"
45-1/2" 56-3/4" 64"
22-1/4" 22-1/4" 22-1/4"
24" 24" 24"
3" 3" 3"
3" 3" 3"
24" 24" 24"
3" 3" 3"
6" 8" 8"
I I I
B-VENT B-VENT B-VENT
-0.08" w.c. -0.08" w.c. -0.08" w.c.
-0.01" w.c. -0.01" w.c. -0.01" w.c.
