MIFARE & ISO14443A & ISO14443B & ISO15693 KEYBOARD SIMULATOR IC CARD READER
MR7622 Series USB HID
Keyboard Simulator IC
Card Reader
User's Manual
(Revision 4.01)
Jinmuyu Electronics Co. LTD
May 7, 2015
Please read this manual carefully before using. If any problem, please mail to: jinmuyu@vip.sina.com
Advertisement
Table of Contents
Related Manuals for Jinmuyu Electronics MR7622 series
Summary of Contents for Jinmuyu Electronics MR7622 series
- Page 1 MIFARE & ISO14443A & ISO14443B & ISO15693 KEYBOARD SIMULATOR IC CARD READER MR7622 Series USB HID Keyboard Simulator IC Card Reader User’s Manual (Revision 4.01) Jinmuyu Electronics Co. LTD May 7, 2015 Please read this manual carefully before using. If any problem, please mail to: jinmuyu@vip.sina.com...
-
Page 2: Table Of Contents
MR7622 Series USB HID Keyboard Simulator IC Card Reader User’s Manual http://www.jinmuyu.com Contents Overview ..............................2 Main Characteristics ..........................2 Technical parameters ..........................2 Cards supported ............................3 Model of the reader ..........................4 Model format ........................... 4 Model description ........................4 5.2.1... -
Page 3: Overview
MR7622 Series USB HID Keyboard Simulator IC Card Reader User’s Manual http://www.jinmuyu.com 1 Overview MR7622 series desktop contactless IC card reader is based on NXP series RF chip with high performance MCU. The communication is according to USB HID standard. There are 2 USB devices to implement the functions. -
Page 4: Cards Supported
MR7622 Series USB HID Keyboard Simulator IC Card Reader User’s Manual http://www.jinmuyu.com • PC software: no need, direct output to editor • ISP: Support • RoHS: Compliant 4 Cards supported MR7622UC MR7622UG MR7622UH MF RC531 SL RC400 CL RC632 ●... -
Page 5: Model Of The Reader
MR7622 Series USB HID Keyboard Simulator IC Card Reader User’s Manual http://www.jinmuyu.com 5 Model of the reader 5.1 Model format This is the model format of Master Reader series contactless card reader/writer: -XXX 1: Product code; 2: Device class; 3: Communication port; 4: Supported card type;... -
Page 6: Communication Port
MR7622 Series USB HID Keyboard Simulator IC Card Reader User’s Manual http://www.jinmuyu.com 5.2.3 Communication port S: RS232C interface, power supply from USB R: RS485 interface, power supply by wire connection U: USB interface E: Ethernet interface, power supply by AC adaptor 5.2.4 Supported card type... -
Page 7: About Pc Software
MR7622 Series USB HID Keyboard Simulator IC Card Reader User’s Manual http://www.jinmuyu.com 7 About PC Software The PC software is TransConfig. It is use for load configuration file to the reader. Please download TransConfig from our website: http://www.jinmuyu.com, or contact us with jinmuyu@vip.sina.com.
