- Page 1 MIFARE & ISO14443A & ISO14443B & ISO7816 DESKTOP IC CARD READER MR801 Series Desktop IC Card Reader User’s Manual (Revision 4.01) Jinmuyu Electronics Co. LTD May 6, 2015 Please read this manual carefully before using. If any problem, please mail to: jinmuyu@vip.sina.com...
-
Page 2: Table Of Contents
MR801 Series Standard PC/SC Desktop IC Card Reader User’s Manual http://www.jinmuyu.com Contents Overview ..............................2 Main Characteristics ..........................2 Technical parameters ..........................2 Cards supported ............................3 Model of the reader ..........................4 Model format ........................... 4 Model description ........................4 5.2.1... -
Page 3: Overview
MR801 Series Standard PC/SC Desktop IC Card Reader User’s Manual http://www.jinmuyu.com 1 Overview MR801 series desktop contactless IC card reader is based on NXP series RF chip with high performance ARM7 MCU. The communication is according to USB PC/SC standard. The reader fully supports the IC card according to ISO14443 standard, especially completely supports ISO14443-4 contactless CPU card. -
Page 4: Cards Supported
MR801 Series Standard PC/SC Desktop IC Card Reader User’s Manual http://www.jinmuyu.com • ISP: Support • RoHS: Compliant 4 Cards supported MR801UC MF RC531 ● MIFARE 1K ● MIFARE 4K ● MIFARE Mini ● MIFARE Ultra Light ● MIFARE Ultra Light EV1 ●... -
Page 5: Model Of The Reader
MR801 Series Standard PC/SC Desktop IC Card Reader User’s Manual http://www.jinmuyu.com 5 Model of the reader 5.1 Model format This is the model format of Master Reader series contactless card reader/writer: -XXX 1: Product code; 2: Device class; 3: Communication port; 4: Supported card type;... -
Page 6: Communication Port
MR801 Series Standard PC/SC Desktop IC Card Reader User’s Manual http://www.jinmuyu.com 5.2.3 Communication port S: RS232C interface, power supply from USB R: RS485 interface, power supply by wire connection U: USB interface E: Ethernet interface, power supply by AC adaptor 5.2.4 Supported card type... -
Page 7: About Pc Software And Api
MR801 Series Standard PC/SC Desktop IC Card Reader User’s Manual http://www.jinmuyu.com 7 About PC Software and API The PC software is PCSC Communication Tool. This is software based on PC/SC API. The software supports most function of IC cards. Please download the operation manual and API manual from our website: http://www.jinmuyu.com, or contact us with jinmuyu@vip.sina.com.
