- Page 1 MIFARE & ISO14443A&B CONTACTLESS IC CARD READER MODULE JMY609C IC Card Reader User’s manual (Revision 3.50) Jinmuyu Electronics Co. LTD 2012/3/2 Please read this manual carefully before using. If any problem, please mail to: Jinmuyu@vip.sina.com...
-
Page 2: Table Of Contents
Parameter downloads ......................12 Device working ........................13 Reset the configuration parameter ..................14 Application sample ..........................14 Mifare S50/S70 data output ....................15 SRI4K data output ......................... 17 Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 1/19... -
Page 3: Product Introduction
1 Product introduction JMY609C contactless IC card reader module use USB interface (HID standard). In the systems of Windows, Linux and other PC systems support USB keyboard, the reader module simulate the USB keyboard to output the card data. We supply a configuration software. Under the software, user could configure complex read card method to implement many type of uses. -
Page 4: Physical Parameter And Pin Outs
Mifare & ISO14443A&ISO14443B&ISO7816 http://www.jinmuyu.com 3 Physical parameter and pin outs 3.1 Photo Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 3/19... -
Page 5: Dimension
Mifare & ISO14443A&ISO14443B&ISO7816 http://www.jinmuyu.com 3.2 Dimension 3.3 Cards supported 3.3.1 ISO14443A Mifare One S50 -4 (T=CL) TYPE A dual interface CPU Card (UID) Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 4/19... -
Page 6: Iso14443B
3.5.2 Card operating type A: PCD is RC522, support ISO14443A and Mifare Class C: PCD is RC523, support ISO14443A, ISO14443B and Mifare Class 3.5.3 Communication port U: USB(HID Standards) Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 5/19... -
Page 7: Dip Switch Configuration
The reader module interface is USB HID class. The driver installation wills automatic process by OS. User need not do anything except connect the reader. Then check the attributes of “USB Human Interface Device”: Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 6/19... -
Page 8: Software Connects To The Device
Open the configuration tool. Then click the “Connect” button. Successfully connect as following: The dialog box will prompt the supported card types. Note: MR761 and JMY609 have the same "Configuration Software". Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 7/19... -
Page 9: Data Output Configuration Instruction
Taking ISO14443A tag as an example, set the output card number and card data. As the picture, the supported card is ISO14443A, and output select is Card SNR, Card Data Mifare S50/S70 and UltraLight Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 8/19... -
Page 10: Card Snr Output Configuration
Set the letter of card number in Caps or lower case Extra key set: After card number output, select output key assignments (4 optional keys: Tab, Enter, Down Arrow and Page Down) and typing numbers. Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 9/19... -
Page 11: Card Data Output Configuration
5.5.2 Continuous mode Name the start byte of the start block, then output, till to the end byte of the named end block, as the chart: If set the following parameters: Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 10/19... -
Page 12: Array Mode
CapsLk setting: Set CapsLk to configure the output of part of card number letter in Upper-case or Lower-case format. Extra key setting: Set the key in two positions (Every block end and Data End) after the card number Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 11/19... -
Page 13: Parameter Downloads
If download success, and then click “Reset” to restart the device. After restart, the computer and device disconnect. Then the computer will re-identify the device and turn to the reading card mode, as following: Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 12/19... -
Page 14: Device Working
Once the computer re-identifies the device, it will only identify one device. As following: Then according to the set parameter, the device will output the data after read success. Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 13/19... -
Page 15: Reset The Configuration Parameter
When parameter download finishes, pull the DIP switch SW1 to ON, then click “Reset” and restart the device, the device will turn into working mode. Setting steps: 6 Application sample Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 14/19... -
Page 16: Mifare S50/S70 Data Output
Not select Card SNR, not output the card number Select Card data and Mifare S50/S70 Set the Mifare S50/S70 as following: Select Mode 1, and set the continuous output mode Set: Start sector=01 Start block=00 Start byte=07 Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 15/19... - Page 17 Set Data End, the Key of Data End is Enter, Num is 1. Key=Enter Num=1 As the above setting, the reader will output the Red data in the chart. Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 16/19...
-
Page 18: Sri4K Data Output
Not select Card SNR, not output the card number Select ISO14443B, Card data and SRI512/2K/4K/X4K Card Set the SRI512/2K/4K/X4K Card as following: Select Mode 1 Set: Start Block=04 End Block=06 Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 17/19... - Page 19 Set Data End, the Key of Data end is Enter, Num is 1. Key=Enter Num=1 As the above setting, the reader will output the Red data in the chart. Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 18/19...
