ISO14443A, ISO14443B, ISO15693 CONTACTLESS, ISO7816 IC CARD READER
JMY6801H IC Card Reader
User's manual
(Revision 3.50)
Jinmuyu Electronics Co. LTD
2012/3/2
Please read this manual carefully before using. If any problem, please mail to: Jinmuyu@vip.sina.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JMY6801H IC and is the answer not in the manual?

Questions and answers

Related Manuals for Jinmuyu Electronics JMY6801H IC

Summary of Contents for Jinmuyu Electronics JMY6801H IC

  • Page 1 ISO14443A, ISO14443B, ISO15693 CONTACTLESS, ISO7816 IC CARD READER JMY6801H IC Card Reader User’s manual (Revision 3.50) Jinmuyu Electronics Co. LTD 2012/3/2 Please read this manual carefully before using. If any problem, please mail to: Jinmuyu@vip.sina.com...
  • Page 2 Pin configurations and Pin outs ....................4 Model available ........................4 Model rule ..........................5 3.5.1 Model format ........................5 3.5.2 Card operating type ......................5 3.5.3 Communication port ......................5 Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved.
  • Page 3 UART/IIC: 3.3V (TTL level; 5V tolerance)  Power consumption: 150mA  Operating distance: 80mm (depending on card and antenna design)  Dimension: 70mm*50mm*16.5mm  Weight: About 120g  ISP: Supported Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved.
  • Page 4 Mifare & ISO14443A & ISO14443B & ISO15693 & ISO7816 Module http://www.jinmuyu.com  Operating temperature: -25 to +85° C  Storage temperature: -40 to +125° C  RoHS: Compliant 3 Physical parameter and pin outs 3.1 Photo Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved.

  • Page 5: Model Available

    RS232C RXD / UART RXD / IIC SCL/ USB D- Power Power 3.4 Model available  JMY6801HI IIC interface  JMY6801HT UART interface, TTL level  JMY6801HS RS232C (UART interface, RS232 level)  JMY6801HU USB to UART Bridge Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved.

  • Page 6: Model Format

    E: PCD is RC531, support ISO14443AB and Mifare Class with 511 bytes communication buffer F: PCD is RC632, support ISO15693, ISO14443A, ISO14443B and Mifare Class with 511 bytes communication buffer 3.5.3 Communication port I: IIC T: UART S: RS232C U: USB Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved.
