Summary of Contents for Kiturami KF
- Page 1 HEATING – AIR CONDITIONING KF WOOD BOILERS FOR HEATING AND HOT WATER INSTALLATION AND OPERATION MANUAL Oil and natural gas Boilers...
-
Page 2: Table Of Contents
Thank you for selecting the KF Kiturami wood boiler . Please read carefully the instruction manual for proper installation of the boiler and keep it for future use. CONTENTS SAFETY WARNINGS page 3 DESCRIPTON OF KF BOILER page 4 INSTALLATION OF KF BOILER... -
Page 3: Safety Warnings
SAFETY WARNINGS It indicates points to remember with symbols in order to make the use of the boiler easier. In this way you can see and avoid accidents. Because your safety and the safety of others is very important, please look at the symbols below carefully and understand them absolutely before proceeding to read the manual. -
Page 4: Descripton Of Kf Boiler
DESCRIPTION OF KF BOILER SAFETY WARNINGS Boiler cleaning locker Door for checking the flame Wood supplying door Setting the input of air Boiler control Power supply Red and white: thermostat connection Green wires: circulator connection Chimney Cold domestic water inlet... -
Page 5: Installation Of Kf Boiler
KF BOILER INSTALLATION The boiler must be placed in an area with sufficient comfort – spaciousness so you can control it and maintain it easily. How to place the boiler: • Place it on unburned - non-combustible materials, such as concrete which can withstand much weight. -
Page 6: Hydraulic Installation Of Kf Boiler
HYDRAULIC INSTALLATION OF KF BOILER Install the KF KITURAMI wood boiler according to the following drawing: Place the open expansion tank at least 1 meter above the rest Plumber Heating. Φ The diameter of the discharge and filling pipe shall be at least... -
Page 7: Chimney Installation
CHIMNEY INSTALLATION The installation of the chimney to the wood boiler plays important role and should be done very carefully. Place the chimney according to the following drawings: Connect the horizontal and vertical part of the chimney with a cleaning T. The vertical part of the chimney, should be at least 3m. -
Page 8: Kf Boiler Control
KF - 3203 B BOILER CONTROL ‘Boiler water temperature indication Ventilator LED Circulator LED Low water level LED Overheating LED Ventilator activation button Power (Reset) button Boiler water temperature indication Shows the water temperature in the boiler and displays trouble codes in case of problems. -
Page 9: Thermostat Ctr - 6080
THERMOSTAT (CTR-6080) Boiler water temperature ON/OFF RESET display button Heating room POWER selection HEATING Boiler water temperature selection Hot domestic WATER water selection Boiler Water Temperature Display - Displays the water temperature in the boiler with numbers. Also displays Trouble Codes in case of malfunction. –... -
Page 10: Kf Boiler Electrical Connection
KF BOILER ELECTRICAL CONNECTION • Connect the circulator with the green wires to the boilers. • Connect the thermostat with the red (+) & white (-) wire to the boiler. • Insert the plug to the mains. KF BOILER IGNITION •... -
Page 11: Circulator & Airvent
Instructions for regulating the wood burning Original factory setting: 1 door open After the boiler is heated, open or close the air damper as the wood boiler works. Close the damper if the wood is burned quickly or open it if the wood is not burned good. Use the settings as in the following illustrations. -
Page 12: General Warnings
GENERAL WARNINGS Use an outlet only for the plug of the boiler. Attention to any electrical leakage! The supplied current should be 230V/60Hz. Ensure the current voltage. Do not clean the boiler with water. Do not store flammable materials near the boiler. •... -
Page 13: General Warnings
GENERAL WARNINGS Is proposed inspection and maintenance of the boiler once a year by qualified personnel. Close manually the air damper if an interruption power occurs and there is wood burning in the boiler. Do not put a lot of wood at once. Placing a lot of wood there is a risk of overheating and the risk of possible burns caused by hot water or steam. -
Page 14: Maintenance
MAINTENANCE • Ensure that the boiler is cold during its maintenance. • Clean the boiler mound of with a brush. • Pick up with a broom the soot from the chamber and the cleaning door. For greater money saving clean the boiler frequently. DAMAGES –... -
Page 15: Technical Specifications
Use a circulation pump proportional to the boiler dynamics and the installation requirements. Install a water drain valve in the installation. TECHNICAL SPECIFICATIONS TYPE KF 35 KF 60 FUEL WOOD POWER (KW) 40,7 69,8 HEATING PERFORMANCE (KW) 23,2-34,9 34,9-45,5 COMBUSTION TYPE... - Page 16 HEATING – AIR CONDITIONING Exclusive Representation Collateral of Egnatia Road P.O. Box 1200 P.C. 57 008 Diavata Interchange, Thessaloniki Tel.: 2310 574 920, 2310 574 803 • Fax.: 2310 574 893 e-mail: info@climacontrol.gr • www.climacontrol.gr...
