COMPONENTS AND PARTS

1) Temperature Control and Display (Left
Zone)
2) Circulation Fan
3) Interior Light
4) Cabinet
5) Temperature Control and Display (Right Zone)
6) Drip Pan
7) Sculptured Vinyl Shelf
8) Flat Chrome Shelf (
SPECIFICATIONS -
Product Description
Model No.
Unit Dimensions
( inches )
Net Weight ( lbs)
Width, Depth, Height
(Wine Storage)
Beverage Storage)
Model LBWC-42SD
24" Stainless Steel Built-In Wine & Beverage Center
Width
23 1/2"
Built-in requirements
Width
24"
Note: The control panels (Item no.
1 & 5) are on the front of the unit.
LBWC-42SD
Height
34"
104 lbs
Height
34 ½"
Depth
23 1/4"
Depth
24"
13
