- Page 1 AVANTGARDE THERMOELECTIRC WINE COOLER Model No: LWC-12B Operation Manual...
-
Page 2: Table Of Contents
Index 1. General Safety Precautions…………......1 2. Technical Data………………………......3 3. Illustrated Structure……………………......4 4. Principle Electric Diagram……………………….….…4 5. Operation ……………………………………………..5 6. Particular Precautions…………………………...….….6 7. Maintenance……………………………………….…..6 8. Troubleshooting………………………………..……..…7... -
Page 3: General Safety Precautions
1.GENERAL SAFETY PRECAUTIONS • After removing the wine cooler from the package, make sure it is in good condition. In case of doubt, do not use it and contact the dealer or an authorized Service Center. • Plastic bags, nails, etc. should be kept out of reach of children. Read the operation manual carefully and check that the rating data on the rating nameplate corresponds to your power supply. -
Page 4: Technical Data
2.TECHNICAL DATA Type LWC-12B Volume (liter) Iron Case Material Door Glass Unit Dimension 260X650X495 (W×H×D)(mm) Packaging Dimension 300X660X535 (W×H×D)(mm) Net Weight (Kg) 12.4 Gross Weight (Kg) 13.4 Power Consumption (KW·h/24h) Fitting ambient temperature ＜25ºC range of working Temperature Range 11º-18º C... -
Page 5: Illustrated Structure
3.ILLUSTRATED STRUCTURE 1 LIGHT SWITCH 2 LED DISPLAY 3 TEMP KEY 4 KEY LIGHT 5 FAN MASK 6 SHELF 7 FEET 8 REAM COVER 9 UP CLIP BOARD 10 INDICATOR LIGHT 11 GLASS DOOR 12 DOWN CLIP BOARD 4.ELECTRIC PRINCIPLE DIAGRAM... -
Page 6: Operation
5.OPERATION he unit’s temperature can be adjusted between 11º-18º C . • • When the power is connected, the cooling system starts to work. The TEMP-ADJ button is set on certain position, which means that if the temperature in the wine cooler reaches the point set, Self-control Temperature System stops cooling system so the temperature in the cabinet rises gradually. -
Page 7: Particular Precautions
6. PARTICULAR PRECAUTIONS • In order to function at its potential, this wine cooler needs to be placed on a level floor, with 2 cm spaces at each side and 10 cm at the back. • Avoid storing the unit in a room with direct sunlight or nay other source. -
Page 8: Troubleshooting
TROUBLESHOOTING Symptoms Possible cause Solutions Not plugged in Plug the unit • • No cooling Low voltage Ensure normal voltage • • Fuse broken Change fuse • • Not cold The refrigerator Keep the refrigerator away from • • enough is placed too sunshine or other heat source;...
