EXTERIOR/INTERIOR TRIM
14.INSTRUMENT PANEL
• LHD MODEL
(2)
(15)
(4)
(5)
(1)
Pad & frame
(2)
Center compartment
(3)
Grille cover
(4)
Lower cover
(5)
Coin box
(6)
Meter visor
General Description
(14)
(3)
(6)
(8)
(7)
A
(10)
(11)
(7)
Center panel
(8)
Air vent grille
(9)
Cup holder
(10)
Glove box panel
(11)
Glove box lid
(12)
Steering beam
(12)
(1)
(9)
EI-12
A
(16)
(13)
(13)
Grille cover
(14)
Air vent grille (Defroster)
(15)
Switch panel
(16)
Passenger's airbag module
EI-00793
