  • Page 1 Installation and User Guide SoundBar TP1866...
  • Page 2 Copyright Information TP1866 Issue 01 © 2014 Promethean Limited. All rights reserved. Promethean is owner of a number of trademarks in several jurisdictions across the world. The Promethean products documented in this guide include aspects which are protected under their respective patent, copyright, design copyright, registered design and trademark laws.
  • Page 3: Table Of Contents

    Contents Welcome Safety Information Environmental Considerations Features Box Contents You Will Need Installation Installation A - Attach ActivSoundBar to ActivBoard Touch Installation B - Attach ActivSoundBar to Wall Setup Activating the Remote Control Replacing the Battery Connections...
  • Page 4 Contents Controls and Indicators Back Panel Front Panel Remote Control Cleaning Cleaning the Bezel and Remote Control Troubleshooting More Information Technical Support Promethean Planet Compliance Statements United States of America Canada...
  • Page 5: Welcome

    Thank you for purchasing an ActivSoundBar from Promethean. The ActivSoundBar provides a powerful, high-quality sound solution for most classrooms. It is offered as an option for the Promethean ActivBoard Touch and can either be wall-mounted, or affixed directly to the top edge of the board.
  • Page 6 SoundBar Safety Information The installation of this product should be completed by a Promethean Certified Installer. Use of components not supplied by Promethean or not meeting minimum specifications may impact performance and affect warranty. Contact your Promethean partner or visit www.prometheankb.com for more information.
  • Page 7 • ventilation slots of the ActivSoundBar. Always use accessories recommended by • Do not place any objects on the top of Promethean to ensure compatibility. • the product. It could short circuit parts When moving the ActivSoundBar from • causing a fire or electric shock. Never an area of low temperature to an area spill liquids on the ActivSoundBar.
  • Page 8 SoundBar Safety Information The wall socket should be installed near use in this case may result in fire or • the equipment and should be easily electric shock. accessible. Do not use the product if any • Only the marked power source can be abnormality occurs.
  • Page 9 Safety Information Warning! Chemical Burn Hazard This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just two hours and can lead to death. Insert the coin/button cell battery into the remote control in accordance with the instructions in this guide.
  • Page 10: Environmental Considerations

    SoundBar Environmental Considerations Temperature: Relative Humidity (non condensing): Operating: 5°C to +35°C Operating and Storage: 40% ~50% • • Storage: 0°C to +60°C • Features Built-in high-performance class D amplifier • 3D surround sound effect • Can be directly connected to your TV, DVD or other audio device •...
  • Page 11 Box Contents DR-6061034 SC-8x1/2” DR-6061039 SC-6/32x1/2-UTS 5m (16 ft) 3m (9.8 ft) 3.5 mm - RCA UK, US, EU ActivSoundBar Installation and User Guide...
  • Page 12: You Will Need

    Lancashire #02-33 TeleTech Park Alpharetta GA 30004 电话: +86 (0) 75529832988 ©2014 Promethean Ltd. All Rights Reserved. Products are subject to availability by country. BB1 5TH Singapore 117674 T: +1 888 652 2848 T: +44 (0) 1254 298598 T: +65 6873 6030 www.PrometheanWorld.com...
  • Page 13: Installation A - Attach Activsoundbar To Activboard Touch

    Installation TP1867 Ø = 2.5mm ” x 4 SC-8x1/2 DR-6061034 x2 ActivSoundBar Installation and User Guide...
  • Page 14 SoundBar Installation TP1865 ActivBoard Touch Installation and User Guide ActivSoundBar Installation and User Guide...
  • Page 15: Installation B - Attach Activsoundbar To Wall

    Installation 22kg/48.5lbs DR-6061039 x2 x 2 SC-6/32x1/2-UTS ActivSoundBar Installation and User Guide...
  • Page 16 SoundBar Installation TP1867 640mm DR-6061039 x2 Ø = ActivSoundBar Installation and User Guide...
  • Page 17: Setup

    Setup Please read the Safety Information at the start of this guide before you begin. Also note: Inserting the battery incorrectly may result in cracking or leakage that may pose a • fire risk or lead to personal injury. If the remote control is not used for a long time, remove the battery. •...
  • Page 18: Replacing The Battery

    SoundBar Setup Replacing the Batter y Open battery compartment and remove battery. 2. Insert one CR2025 lithium battery into the compartment. Make sure that you match the (+) and (-) symbols on the battery with the (+) and (-) symbols inside the battery compartment. 3.
  • Page 19: Controls And Indicators

    Setup iPhone/Tablet/Smartphone Subwoofer (not included) (cable not included) TV/DVD/CD Power Cable Controls and Indicators Back Panel POWER POWER RCA INPUT RCA INPUT SUBWOOFER SUBWOOFER OUTPUT OUTPUT 220~240V AC 220~240V AC 50/60Hz 0.1A 50/60Hz 0.1A Aux Input Power Switch RCA Input Power Connector Subwoofer Output ActivSoundBar Installation and User Guide...
  • Page 20: Front Panel

    SoundBar Controls and Indicators Front Panel Standby/Power On Increase Volume Decrease Volume SOURCE Select Sound Source 3D Surround Indicator Operation Short press to power on/off ActivSoundBar. Short press to increase volume. Long press to increase volume continuously. Short press to decrease volume. Long press to decrease volume continuously.
  • Page 21: Remote Control

    Controls and Indicators Remote Control Operation Short press to power SOURCE on/off ActivSoundBar. Short press to switch SOURCE audio source. Short press to increase volume. Long press to increase volume continuously. Short press to decrease volume. Long press to decrease volume continuously.
  • Page 22: Troubleshooting

    SoundBar Cleaning Unplug the power cable from the socket before cleaning the ActivSoundBar. Cleaning the Bezel and Remote Control Do not use volatile solvents (such as alcohol, rosin, and toluene) to clean the ActivSoundBar. These types of chemicals might damage the housing. Use a 100% cotton cloth or micro-fiber cloth for cleaning.
  • Page 23 Troubleshooting Problems Solutions Remote Control does not work Make sure the battery is correctly inserted. • Take the battery out, press the buttons • once or twice, then reinsert the battery and try again. If reinserting the battery has no effect, •...
  • Page 24: Technical Support

    For online support, self-help solutions and further support contact information, please visit the Promethean Knowledgebase at: www.PrometheanKB.com Promethean Planet Promethean Planet is the fastest growing online community for interactive whiteboard users. Download over 80,000 FREE lesson resources. • Download the latest ActivInspire software.
  • Page 25: Compliance Statements

    Consult the dealer or an experienced radio/TV technician for help. • Changes and Modifications not expressly approved by Promethean can void your authority to operate this equipment under Federal Communications Commissions rules. Canada This Class B digital apparatus complies with Canadian ICES-003.
  • Page 26 Products with the CE marking comply with both the EMC Directive (2004/108/EC) and the Low Voltage Directive (2006/95 EC) issued by the Commission of the European Community. Please contact Promethean for a full copy of the EU Declaration of Conformity. Waste Electrical and Electronic Equipment (WEEE)
  • Page 27 ActivSoundBar Installation and User Guide...
  • Page 28 SoundBar ActivSoundBar Installation and User Guide TP1866 02/14 v1.0 ©2014 Promethean Ltd. All Rights Reserved. Products are subject to availability by country. Product Specifications are subject to change without notice.
