Summary of Contents for promethean ActivSound 75
- Page 2 ActivSound 75 Operating Controls (1) Power switch Turns the power on/off. (2) Power indicator Lights "green" when the power is turned ON. (3) Infrared Microphone Volume Control [Teacher 1 and 2] This control is used to adjust the level of the infrared microphones.
- Page 3 ActivSound 100 Operating Controls (1)Power switch. Turns the power on/off. (2) Power indicator. Lights "green" when the power is turned ON. (3) Infrared Microphone Volume Control [Teacher 1 and 2]. This control is used to adjust the level of the infrared microphones. (4) Infrared Signal Indicator T eacher 1 and ［...
- Page 4 ActivSound 200 Operating Controls Front Panel (1) Power switch Turns the power on/off. (2) Power indicator Lights "green" when the power is turned ON. (3) Infrared Microphone Volume Control [Teacher 1 and 2] This control is used to ad- just the level of the infrared microphones. (4) Infrared Signal Indicator T eacher 1 and 2 Lights "green"...
- Page 5 ActivSound 300 Operating Controls Front Panel (1) Power switch Turns the power on/off. (2) Power indicator Lights "green" when the power is turned ON. (3) Infrared Microphone Volume Control [Teacher 1 to 4] This control is used to adjust the level of the infrared microphones. (4) Infrared Signal Indicator T eacher 1 to 4 ［...
- Page 6 STUDENT MICROPHONE Operating Controls (1A) Momentary power switch– Push to Talk. (1B) Continuous power switch– Slide up to lock on and then talk. (2) Power indicator –lights "green" when the power is turned either momentary or continuous. (3) Microphone (audio pickup) - speak into this part of the microphone.
- Page 7 TEACHER MICROPHONE Operating Controls Front View Rear View (1) Power/Mute switch: Turns the power on/off. Press and hold to turn on/off. Press momentary to mute. (2) Power indicator—Lights green when the power is turned ON. (3) Microphone (audio pickup) - Speak into this part of the microphone. (4) Infrared signal emitter The infrared signals are broadcast from multiple IR signal emitters.
-
Page 8: Charging The Battery
Charging the Battery 1. Connect power cord (1) to the AC mains. 2. Turn “off” the power switch (2). Check that the power indicator (2) has gone out. 3. Connect the charging plug(s) (3) to the microphone(s) 4. The red Charging LED (4) should start flashing. It will stop flashing and remain on when charging is completed. - Page 9 ActivSound ONE Operating Controls (1) Power switch. Turns the power on/off. (2) Power Indicator. Lights “amber” when the power is turned ON. (3) Infrared Microphone Volume Control [Teacher 1 and 2]. These controls are used to adjust the level of the Teacher/Student microphones. (4) Infrared Signal Indicator [Teacher 1 and 2].
- Page 10 Teacher’s Check List TURN on the transmitter (green LED will indicate power, red LED indicates that batteries need to be recharged). POWER on the amplifier (red LED will indicate power; green LED by teacher volume control indicates receipt of IR signal). TRANSMITTER/MICROPHONE needs to be worn in a way as to have a clear path to the receiving sensors.
-
Page 11: Troubleshooting
– Free the transmitter from any obstructions. – Contact Promethean . – Contact Promethean for assistance. – Have your batteries been charged overnight? – Are your batteries over 1 year old? – Try a new set of batteries. If the problem persists contact Promethean . - Page 12 – Charge the batteries overnight. – Will other items power up in that outlet? – If available try another outlet. If the problem persists contact Promethean . – Contact the school – Plug in the amplifier/receiver to the wall outlet.
