Convergent Design Odyssey7Q Setup Manual page 13

Configure Odyssey7Q Recording Uncom-
5
Format SSDs
MENU » ODYSSEY » SSD'S » FORMAT BOTH
second SSD drive installed.)
6
Connect to Camera and Verify Status Input
Connect C500 3G-SDI output to Odyssey7Q SDIA input
Note: Use only 3G-SDI rated cables from C500 to Odyssey 7Q. Using a 1.5G
SDI cable in not recommended and may cause issues.
The status on your Odyssey7Q will display your camera's output.
Example:
Note: The recorded file will be 1920x1080 @ 23.98/25/29.97 fps.
i
Notes
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ (720) 221-3861 | FAX: ++ (720) 227-9296 | Office Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: CDSupport@Convergent-Design.com | WEBSITE: www.Convergent-Design.com
1080p29.97 422 PRORES
CANON HQ
(or FORMAT SSD1 if you do not have a
