- Page 1 BookEndz BookEndz Owner’s Manual c2006 OlympicControls Corp.
- Page 2 THANK YOU Thank you for purchasing the BookEndz Dock for ® your MacBook Pro Computer. The purpose of ® the BookEndz Dock is to eliminate the hassles, ® headaches, wear & tear, and delays that arise from having to plug in all of your peripheral cables each time you want to use them.
- Page 3 ® BookEndz Dock - features & Connectors ® Top View BookEndz Dock - features & Ports ® Rear View Audio hookup security for your MacBook Pro and BookEndz Dock ® ® Docking and undocking your BookEndz Dock ® limited warranty...
-
Page 4: Installing Your New Bookendz
InstallIng your new BookEndz dock ® 1. Place the BookEndz Dock on the flat surface on which it will be used and plug all of your external devices into the BookEndz Docking Station (video monitor, network, modem, etc.). 2. Shut down the MacBook Pro and close the LCD screen. - Page 5 the 15” MacBook Pro features & Ports Your 15” MacBook Pro has ten side panel ports and features as shown: Left Side: 3 4 Right Side: 1. MagSafe Power Connector 6. USB 2.0 2. USB 2.0 7. Firewire 400 Port 3. Audio Line Input 8. Ethernet 4. Audio Line Output 9. DVI 5. Security Slot...
- Page 6 & connectors BookEndz ® Top View The connectors shown below mate with those on your MacBook Pro and allow you to easily dock and undock with your external devices. 1. Power 6. Ethernet 2. USB 2.0 7. FireWire 400 3. Audio Line In 8. USB 2.0 4. Headphone Out* 9. Release Handle 5. DVI Out *See page 8 for more details on the Audio Hookup.
- Page 7 6 7 8 9 10 1. USB 2.0 6. RCA Audio Out-Right 2. FireWire 400 7. RCA Audio Out-Left 3. Ethernet 8. USB 2.0 4. DVI* 9. Audio Line In 5. VGA Monitor* 10. Headphone Out * The BookEndz Dock splits the DVI Port of the PowerBook into a DVI and VGA Monitor Port.
-
Page 8: Audio Hookup
The Headphone Out Connector on your BookEndz Dock was designed to allow use of either external speakers or the internal speakers of your MacBook Pro. To use external speakers, move the Headphone Out Connector to engage into the MacBook Pro: To use internal speakers, move the Headphone Out Connector to disengage from the MacBook Pro:... - Page 9 Security Cable. The MacBook Pro has its own security slot on the right side towards the front of the computer, and the BookEndz Dock has a security slot on its left side near the back of the dock. You may wish to secure one or both items while you are away.
- Page 10 MacBook Pro shutdown (not asleep), position the dock on the flat surface you intend to use it on. Place the MacBook Pro on to the BookEndz Dock. Make sure that the ports of the MacBook Pro align with the connectors of the BookEndz Dock.
-
Page 11: Limited Warranty
OlympicControls Corp. unless in writing and signed by an officer of OlympicControls Corp. Apple and MacBook Pro are registered trademarks of Apple Computer Inc. BookEndz is a ®... - Page 12 Toll Free: 888-622-1199 Phone: 847-742-3566 Fax: 847-742-5686 E-mail: Sales@BookEndzdocks.com www.BookEndzdocks.com Pub. No. BE-10266-Rev A BookEndz is protected by US Patent #5,186,646 and produced by OlympicControls Corporation...
