- Page 1 BookEndz BookEndz Owner’s Manual c2006 OlympicControls Corp...
- Page 2 Thank you for purchasing the BookEndz your MacBook BookEndz ® headaches, wear & tear, and delays that arise from having to plug in all of your peripheral cables each time you want to use them. Once the cables are plugged into the dock, all you need to do is slide in your BookEndz everything at once.
- Page 3 BookEndz Dock - features & Connectors ® Top View BookEndz Dock - features & Ports ® Rear View Audio hookup security for your MacBook Docking and undocking your BookEndz limited warranty Dock ® and BookEndz ® ® Dock ® Dock...
- Page 4 InstallIng your new BookEndz 1. Place the BookEndz Dock on the flat surface on which it will be used and plug all of your external devices into the BookEndz Docking Station (video monitor, network, modem, etc.). 2. Shut down the MacBook and close the LCD screen.
-
Page 5: Macbook ® - Features & Ports
Your 13” DVI MacBook has nine side panel ports and features as shown: 1. Power 2. Ethernet 3. Mini-DVI port 4. FireWire 5. USB 1 the 13” MacBook features & Ports 6. USB 2 7. Audio In 8. Audio Out 9. - Page 6 BookEndz The connectors shown below mate with those on your MacBook and allow you to easily dock and undock with your external devices. 1. USB 2.0 2. Headphone Out 3. Audio In 4. USB 2.0’s 5. Firewire 400 DOcK fEATUREs & cONNEcTORs ® Top View 6. Mini DVI...
- Page 7 BookEndz Plug all of your peripherals into the ports shown below on the rear of your BookEndz Dock. Be sure all peripherals are turned off prior to connecting them to your BookEndz Dock. 1. Full Size DVI 2. FireWire 400 3.
-
Page 8: Audio Hookup
AUDIO HOOKUP The Headphone Out Connector on your BookEndz Dock was designed to allow use of either external speakers or the internal speakers of your MacBook. To use external speakers, move the Headphone Out Connector to engage into the MacBook:... -
Page 9: Security For Your Macbook ® And Bookendz ® Dock
Security Cable. The MacBook has its own security slot on the left side towards the front of the computer, and the BookEndz Dock has a security slot on its left side near the back of the dock. You may wish to secure one or both items while you are away. -
Page 10: Docking And Undocking Your Bookendz ® Dock
With your MacBook shutdown (not asleep), position the dock on the fl at surface you intend to use it on. Align the connectors on the BookEndz Dock, with the ports on the MacBook, and gently push the BookEndz Dock until docking is complete. -
Page 11: Limited Warranty
No waiver or modifi cation of the Warranty or any of its terms shall bind OlympicControls Corp. unless in writing and signed by an offi cer of OlympicControls Corp. Apple and MacBook are registered trademarks of Apple Computer Inc. BookEndz trademark of OlympicControls Corp. All other product names are trademarks or registered trademarks of their respective holders. - Page 12 Toll Free: 888-622-1199 Phone: 847-742-3566 Fax: 847-742-5686 E-mail: Sales@BookEndzdocks.com www.BookEndzdocks.com Pub. No. BE-10281-Rev A BookEndz is protected by US Patent #5,186,646 and produced by OlympicControls Corporation...
