- Page 1 BookEndz BookEndz Owner’s Manual c2007OlympicControls Corp.
- Page 2 THANK YOU Thank you for purchasing the BookEndz Dock for ® your MacBook Pro Computer. The purpose of ® the BookEndz Dock is to eliminate the hassles, ® headaches, wear & tear, and delays that arise from having to plug in all of your peripheral cables each time you want to use them.
-
Page 3: Table Of Contents
BookEndz ® Rear View BookEndz Dock w/Firewire 800 - Features & Ports ® Rear View Audio Hookup Docking and Undocking Your BookEndz Limited Warranty TAble Of cONTeNTs Dock ® - Features & Ports ® w/Firewire 800 - Features & Ports ®... -
Page 4: Installing Your New Bookendz
INsTAllINg YOUr New BookEndz 1. Place the BookEndz Dock on the flat surface on which it will be used and plug all of your external devices into the BookEndz Docking Station (video monitor, network, modem, etc.). 2. Shut down the MacBook Pro and close the LCD screen. - Page 5 Your 15” MacBook Pro has nine side panel ports and features as shown: Left Side: Right Side: 1. MagSafe Power Connector 2. USB 2.0 3. Audio Line Input 4. Audio Line Output 5. Security Slot THe 15” Macbook Pro feATUres & POrTs 6.
- Page 6 THe 15” Macbook Pro w/Firewire 800 Your 15” MacBook Pro 800 Firewire has ten side panel ports and features as shown: Left Side: Right Side: 1. MagSafe Power Connector 2. USB 2.0 3. Audio Line Input 4. Headphone Output 5. Security Slot feATUres &...
-
Page 7: Bookendz ® Dock
BookEndz The connectors shown below mate with those on your MacBook Pro and allow you to easily dock and undock with your external devices. 1. MagSafe Housing 2. USB 2.0 3. Audio Line In 4. Headphone Out* 5. DVI Out *See page 8 for more details on the Audio Hookup. -
Page 8: Bookendz
BookEndz dOcK feATUres & cONNecTOrs The connectors shown below mate with those on your MacBook Pro with 800 Firewire and allow you to easily dock and undock with your external devices. 1. MagSafe Housing 2. USB 2.0 3. Audio Line In 4. -
Page 9: Rear View
2. Firewire 400 3. Ethernet 4. DVI* 5. VGA Monitor* * The BookEndz Dock splits the DVI Port of the MacBook Pro into a DVI and VGA Monitor Port. (Cannot be used at the same time.) dOcK feATUres & POrTs ®... -
Page 10: Bookendz
3. Firewire 800 4. Ethernet 5. DVI* 6. VGA Monitor* * The BookEndz Dock splits the DVI Port of the MacBook Pro into a DVI and VGA Monitor Port. (Cannot be used at the same time.) w/Firewire 800 ® Rear View 7. -
Page 11: Audio Hookup
AUdIO HOOKUP The Headphone Out Connector on your BookEndz Dock was designed to allow use of either external speakers or the internal speakers of your MacBook Pro. To use external speakers, move the Headphone Out Connector to engage into the MacBook Pro:... -
Page 12: Docking And Undocking Your Bookendz
With your MacBook Pro shutdown (not asleep), position the dock on the flat surface you intend to use it on. Place the MacBook Pro on to the BookEndz Dock. Make sure that the ports of the MacBook Pro align with the connectors of the BookEndz Dock. -
Page 13: Limited Warranty
No waiver or modification of the Warranty or any of its terms shall bind OlympicControls Corp. unless in writing and signed by an officer of OlympicControls Corp. Apple and MacBook Pro are registered trademarks of Apple Computer Inc. BookEndz registered trademark of OlympicControls Corp. All other product names are trademarks or registered trademarks of their respective holders. - Page 14 Toll Free: 888-622-1199 Phone: 847-742-3566 Fax: 847-742-5686 E-mail: Sales@BookEndzdocks.com www.BookEndzdocks.com Pub. No. BE-10291-Rev A BookEndz is protected by US Patent #5,186,646 and produced by OlympicControls Corporation...
