  • Page 1 BookEndz BookEndz Owner’s Manual c2007 OlympicControls Corp.
  • Page 2 THANK YOU Thank you for purchasing the BookEndz Dock for ® your MacBook Pro Computer. The purpose of ® the BookEndz Dock is to eliminate the hassles, ® headaches, wear & tear, and delays that arise from having to plug in all of your peripheral cables each time you want to use them.

  • Page 3: Table Of Contents

    Installing your new BookEndz Dock ® 17” MacBook Pro - features & Ports ® Dock - features & Connectors BookEndz ® Top View BookEndz Dock - features & Ports ® Rear View Audio hookup Docking and undocking your BookEndz Dock ® limited warranty...

  • Page 4: Installing Your New Bookendz

    INsTALLINg YOUR NEW BookEndz DOcK ® 1. Place the BookEndz Dock on the flat surface on which it will be used and plug all of your external devices into the BookEndz Docking station (video monitor, network, modem, etc.). 2. shut down the MacBook Pro and close the lCD screen.
  • Page 5 THE 17” Macbook Pro fEATUREs & PORTs Your 17” MacBook Pro has thirteen side panel ports and features as shown: Left Side: Right Side: 1. MagSafe Power Connector 7. USB 2.0 2. USB 2.0 8. FireWire 400 3. USB 2.0 9.

  • Page 6: Bookendz

    BookEndz DOcK fEATUREs & cONNEcTORs ® Top View The connectors shown below mate with those on your MacBook Pro and allow you to easily dock and undock with your external devices. 1. MagSafe Housing 7. Ethernet 2. USB 2.0 8. FireWire 800 3. USB 2.0 9. FireWire 400...

  • Page 7: Bookendz

    3. FireWire 800 9. USB 2.0 4. Ethernet 10. Audio Line In 5. DVI 11. Headphone Out 6. VGA Monitor * The BookEndz Dock splits the DVI Port of the MacBook Pro into a DVI and VGA Monitor Port. (Cannot be used at the same time.)

  • Page 8: Audio Hookup

    AUDIO HOOKUP The Headphone Out Connector on your BookEndz Dock was designed to allow use of either external speakers or the internal speakers of your MacBook Pro. To use external speakers, move the Headphone Out Connector to engage into the MacBook Pro:...

  • Page 9: Docking And Undocking Your Bookendz

    MacBook Pro shutdown (not asleep), position the dock on the flat surface you intend to use it on. Place the MacBook Pro on to the BookEndz Dock. Make sure that the ports of the MacBook Pro align with the connectors of the BookEndz Dock.
  • Page 10 OlympicControls Corp. unless in writing and signed by an officer of OlympicControls Corp. Apple and MacBook Pro are registered trademarks of Apple Computer Inc. BookEndz is a ®...
  • Page 12 Toll Free: 888-622-1199 Phone: 847-742-3566 Fax: 847-742-5686 E-mail: Sales@BookEndzdocks.com www.BookEndzdocks.com Pub. No. BE-10309 Rev. A BookEndz is protected by US Patent #5,186,646 and produced by OlympicControls Corporation...
