- Page 1 MANUAL ZONE4 INFO@APART-AUDIO.COM...
- Page 2 System integrators will be pleased to find a RS232 port at the back, allowing full control of the most important system parameters. If you need to control the zones locally, you can always add a wired remote, APart model ZONE4R to any zone. Wiring is simple, using standard RJ45 connectors and CAT5 cable.
-
Page 3: Front Panel
19. On/off switch : fl ip this switch to turn the unit on or off. 20. Power led : this led is lit when the power is on. When the unit is set to stand-by via RS232, then this led will still be lit to indicate that mains power is still present. INFO@APART-AUDIO.COM... -
Page 4: Rear Panel
Damage caused by poor or incorrect installation is excluded from the warranty. Up to 8 pcs. ZONE4R remote panels can be connected to a single ZONE4. More than 1 panel per zone can be used. Please refer to the ZONE4R manual. - Page 5 MICPAT-4 selective paging station. 29. RJ45 connector for the MICPAT-4 selective paging station only. Up to 4 pcs. of MICPAT-4 can be connected to a single ZONE4. A smart bus-sytem arranges the Priority (busy-line). Please refer to the MICPAT4 manual.
-
Page 6: Block Diagram
Block diagram WWW.APART-AUDIO.COM... - Page 7 INFO@APART-AUDIO.COM...
- Page 8 ZONE4 REMOTE CONTROL CODE IR FUNCTIONS ZONE LEAD DEVICE ID DATA CODE CODE CODE MUSIC VOLUME UP ZONE 1 04FB MUSIC VOLUME DOWN ZONE 1 04FB MIC VOLUME UP ZONE 1 04FB MIC VOLUME DOWN ZONE 1 04FB SELECT SOURCE A...
- Page 9 DISCONNECT PAGING (ON) 04FB CONNECT PAGING (OFF) 04FB SOURCE UP ZONE 1 04FB SOURCE UP ZONE 2 04FB SOURCE UP ZONE 3 04FB SOURCE UP ZONE 4 04FB Command structure : ZONE4 ID code –> command –> inverse command. INFO@APART-AUDIO.COM...
-
Page 10: Remote Control
> 65 dB @ mic level 4mV < 0,09% PHANTOM POWER MIC 2 AND 3 18 V, individually switchable TONE CONTROL MIC/LINE 1 TO 3 from 100Hz/+3dB,10kHz/-6dB to 100Hz/-9dB, 10KHz/+4dB ReMOte cOntROL VIA RJ45 CAT-5 PER ZONE OPTIONAL MODELS WWW.APART-AUDIO.COM... -
Page 11: Safety Information
Do not use the unit near stoves, heat registers, radiators, or other heat producing devices. • Do not remove the cover. Removing the cover will expose you to potentially dangerous voltages. • In case of mal-function this device should be serviced by qualified service personnel only. INFO@APART-AUDIO.COM... - Page 12 ANY SUGGESTION? They are well appreciated and eventually rewarded! Send your ideas or suggestions to suggestions@apart-audio.com ZONE4 is developed by Audioprof nv Lanteernhofstraat 90 BE-2100 Deurne BELGIUM WWW.APART-AUDIO.COM...
