- Page 1 PCR3000RMKII Instruction manual...
- Page 3 PCR3000RMKII Instruction manual PCR3000RMKII Manual...
- Page 4 MEDIA PLAYER Features The Apart PCR3000RMKII is a professional multisource CD/USB/ SD card music player with integrated FM RDS and DAB+ tuner, equipped with multiple independent analog outputs, coaxial and optical digital output for the CD/USB/SD player and a RS232 port for use in automated systems.
-
Page 5: Front Panel
PCR3000RMKII Instruction manual Front panel 28 27 26 25 14 13 12 11 10 1. Power led: lights up blue when powered on, lights up red when in standby mode. 2. CD tray. 3. CD/USB/SD player display: displays track number and playback time and status. - Page 6 MEDIA PLAYER 8. Tuning back button: tune one step back (FM mode). In DAB mode the tuner will tune to the previous station. 9. Tuning forward button: tune one step up (FM mode). In DAB mode the tuner will tune to the next station. 10.
- Page 7 PCR3000RMKII Instruction manual 18. Fast forward button, Fast backward: push once to search forward or backward. Push again to resume normal play. 19. Track down button: push to go one track back,Track up: pushto skip to the next track. 20. Repeat button:...
-
Page 8: Rear Panel
MEDIA PLAYER Rear panel 1. Antenna connector: connect the antenna supplied here. Do not connect this to a cable distribution network, unless you use an isolation transformer. Connecting the unit to a cable network may cause interference to the DAB reception. This depends on the signal present on the cable network. - Page 9 PCR3000RMKII Instruction manual This connector carries the SPDIF digital output from the CD/ USB/SD player in 16 bits/44.1 kHz PCM format. 9. Coaxial digital output: digital output on RCA connector. This connector carries the SPDIF digital output from the CD/USB/SD player in 16 bits/44.1 kHz PCM format.
- Page 10 MEDIA PLAYER *Please note: the unit may respond slowly when you change the input source. This depends on the memory capacity and reading speed of the memory stick/card and the number of files present on the media. When inserting a CD, the unit will first read the table of content to determine the type of media present on the disc.
- Page 11 PCR3000RMKII Instruction manual RS232 communication Communication with PC1000RMKII via RS232 is done with simple ASCII commands. The port settings are: 38400 baudrate, 8 databits, no parity, handshake off. These parameters cannot be changed. The physical connection is made with a straight through...
- Page 12 Unknown characters in your terminal communication program usually indicate that the baudrate is incorrect. Below is a table with the list of commands recognized by PCR3000RMKII and some examples of the replies sent by the PCR3000RMKII.
-
Page 13: Command Description
PCR3000RMKII Instruction manual RS232 COMMANDS COMMAND (DESCRIPTION) REPLY PLAY PCR3000R--> Play PAUSE PCR3000R--> Pause STOP PCR3000R--> Stop EJECT PCR3000R--> Eject Comman SKIP+ (go to next track) PCR3000R--> Skip Next SKIP- (go to previous track) PCR3000R--> Skip Back FAST+ (fast forward search, send PCR3000R-->... -
Page 14: Random Off
REPEAT ALL PCR3000R--> Repeat All REPEAT OFF PCR3000R--> Repeat Off STATUS CD (displays the status of PCR3000R--> Device: CD Player the PCR3000RMKII) PCR3000R--> MP3: 030 PCR3000R--> Status: Play PCR3000R--> Time: 03:18 DAB ON (switches the tuner ON) PCR3000R--> DAB on DAB OFF (switches the tuner to PCR3000R-->... - Page 15 PCR3000RMKII Instruction manual DAB MUTE ON (mute tuner, FM or PCR3000R--> DAB Mute On DAB+) DAB MUTE OFF (un-mute, FM or PCR3000R--> DAB Mute Off DAB+) STATUS DAB (displays tuner status, PCR3000R--> 97.40 MHz FM Auto FM or DAB+) (Stereo) INFO (switch between different PCR3000R-->...
-
Page 16: Specifications
MEDIA PLAYER Specifications CD PLAYER Compatible media Audio CD, CDR, CDRW, DVD, DVDR, DVDRW Audio format Audio CD 16 bit PCM, MP3 32-320 kbps and variable bitrate, WMA. ID3 tags are not supported. Maximum number of files on the media = 4095. File name recognition is limited to 8 characters. - Page 17 PCR3000RMKII Instruction manual S/N ratio >90dB <0.05% Frequency range 20Hz - 20KHz FM-RDS/DAB/DAB+TUNER Technical Specifications Frequency range FM radio 87.5 MHz to 108 MHz Frequency range DAB radio band 3 174 MHz to 240 MHz Frequency response FM radio 20 Hz - 15 KHz...
- Page 18 MEDIA PLAYER RS232 port setting (fixed) 38400 baudrate, 8 databits, no parity, handshake off Infrared extension port Mini jack connector at the rear, disables the front infrared receiver Remote control battery type AAA type LR03 Operating temperature 10 - 40 °C Relative humidity 10 to 80 % non condensing...
-
Page 19: Important Safety Instructions
PCR3000RMKII Instruction manual Important safety instructions Please check the carton for any kind of damage on reception of the goods. In case of a damaged carton, please contact your dealer before opening the carton. Read all documentation before operating your equipment. - Page 20 MEDIA PLAYER Power down & disconnect units from mains voltage before making connections. Do not use the unit near stoves, heat registers, radiators, or other heat producing devices. Do not remove the cover. Removing the cover will expose you to potentially dangerous voltages.
- Page 21 PCR3000RMKII Instruction manual Notes...
- Page 22 MEDIA PLAYER...
- Page 24 Audioprof nv Industriepark Brechtsebaan 8 bus 1 2900 Schoten - Belgium Company names, product names and trademarks are property of their respective owners. Apart-Audio specifications are subject to change without notice.
