Summary of Contents for Kuppersbusch EGE3710.1ED

  • Page 1 BEDIENUNGSANWEISUNG mit Montageanweisungen Instructions for use and installation Instructions d’utilisation et d’installation EGE3710.1ED...
  • Page 2: Table Of Contents

    Dear customers, Thank you for having chosen a KÜPPERSBUSCH ceramic hob In order to install properly your appliance and to make the best use of it, please read this entire instruction manual carefully. SUMMARY SAFETY ............................14 ...................... 14 RECAUTIONS BEFORE USING ........................
  • Page 3: Safety

    SAFETY Precautions before using  Unpack all the materials.  The installation and connecting of the appliance have to be done by approved specialists. The manufacturer cannot be responsible for damage caused by building-in or connecting errors.  To be used, the appliance must be well-equipped and installed in a kitchen unit and an adapted and approved work surface.
  • Page 4: Precautions Not To Damage The Appliance

    Precautions not to damage the appliance  Raw pan bottoms or damaged saucepans (not enamelled cast iron pots,) may damage the ceramic glass.  Sand or other abrasive materials may damage ceramic glass.  Avoid dropping objects, even little ones, on the vitroceramic. ...
  • Page 5: Description Of The Appliance

    DESCRIPTION OF THE APPLIANCE Technical data Type Power Diameter EGE3710.1ED 2300 W 185 x 305 mm Control panel Power display [ - ] key [ + ] key On/Off Sensitive touches Your ceramic hob is equipped with electronic controls with sensitive touch keys. When your finger touches the key, the corresponding command is activated.
  • Page 6: Display

    Display Display Designation Function Zero The heating zone is activated 1…9 Power level Selection of the cooking level Heat accelerator Automatic cooking Error message Electronic failure Residual heat The heating zone is hot Residual heat indication After the switch-off of the hob, the heating zone is still hot and indicates [ H ] on the display. The symbol [ H ] disappears when the heating zone may be touched safely.
  • Page 7: Automatic Cooking

    Automatic cooking All the cooking zones are equipped with an automatic “go and stop” cooking device. The cooking zone starts at full power during a certain time, then reduces automatically its power on the preselected level.  Start-up : Action Control panel Display Full power setting...
  • Page 8: Cooking Advices

    COOKING ADVICES Examples of power setting: (The values below are indicative) Sauces, butter, chocolate, gelatine 1 to 2 Melting, Reheating Dishes prepared beforehand Rice, pudding, sugar syrup 2 to 3 Simmering, Defrosting Dried vegetables, fish, frozen products 3 to 4 Steam Vegetables, fish, meat 4 to 5...
  • Page 9: What To Do In Case Of A Problem

    WHAT TO DO IN CASE OF A PROBLEM The hob or the cooking zone doesn’t start-up:  The hob is badly connected to the electrical system.  The protection fuse has blown.  The locking function is activated  The sensitive keys are covered by grease or water. ...
  • Page 10: Installation Instructions

    Stick the gasket (2) two millimeters from the external edge of the glass, after removing the protection tape (3). Fitting - installing:  Cut out sizes of the worktop: EGE3710.1ED 298 mm 518 mm 280 mm 490 mm 42 mm ...
  • Page 11: Electrical Connection

     Not to install the hob to the top of a not ventilated oven or a dishwasher.  To guarantee under the bottom of the hob casing a space of 20 mm to ensure a good air circulation of the electronic device. ...
