GUIDE TO INSTALLATION AND USE
Cooking Hob
I I M M P P O O R R T T A A N N T T : Save this manual for the local electrical inspector's use.
I I N N S S T T A A L L L L E E R R : Please leave this manual with the unit for the owner.
O O W W N N E E R R : Please keep this manual for future reference.
I I M M P P O O R R T T A A N N T T : Local codes vary. Installation, electrical connections and
grounding must comply with all applicable codes.
EKI956UL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kuppersbusch EKI956UL
Summary of Contents for Kuppersbusch EKI956UL
-
Page 1: Cooking Hob
O O W W N N E E R R : Please keep this manual for future reference. I I M M P P O O R R T T A A N N T T : Local codes vary. Installation, electrical connections and grounding must comply with all applicable codes. EKI956UL... -
Page 2: Important Safety Instructions
99637771_A_EN.qxp 19/07/2005 11:45 Page 2 IMPORTANT SAFETY INSTRUCTIONS 1 - Proper Installation - Be sure your appliance is properly grounded and installed by a qualified technician. 2 - Never Use your Appliance for Warming or Heating the Room. 3 - Do Not Leave Children Alone - Children should not be left alone or unattended in an area where appliance is in use. - Page 3 Some cleaners can produce noxious fumes if applied to a hot surface. CAUTION Do not store items of interest to children in cabinets above or around the cooktop - children climbing on the cooktop to reach items, could be seriously injured.
-
Page 4: Installation
99637771_A_EN.qxp 19/07/2005 11:45 Before I I nstallation Installation Other I I nstallation R R equirements Electrical C C onnection Safety P P recautions Principle o o f I I nduction Glass T T op, C C oil S S ize a a nd C C ontrols Controls a a nd O O peration Heating Z Z ones, C C oil S S izes &... - Page 5 After delivery, have your induction cooktop carefully unpacked, and again check forany visible damage. If you find any damage onthe unit at this point, immediately inform your dealer or distributor.
- Page 6 99637771_A_EN.qxp 19/07/2005 11:45 1 1 / INSTALLATION To install the cooktop, cut out a rectangular opening in the counter as shown on the drawing and table below. Also, ensure that you have a minimum of 10 mm (3/8”) of space in the back of the unit, between the rim and backsplash on your counter (or wall if no backsplash) for ventilation.
- Page 7 The air intake is on the bottom of the cooktop box, and the warm air exhaust is located on the back of the rim, as shown on the schematic. If the air...
- Page 8 99637771_A_EN.qxp 19/07/2005 11:45 Electrical Connection cooktop e e lectrical c c haracteristics a a re: Operating voltage... 240 V~ 60 Hz Maximum power output ... 10800 W Connect to ... 240 V, 60 Hz, 2 Pole+G, 40 A (min) supply,...
- Page 9 If the unit is connected directly to supply inside a junction box, then disconnect its breaker, or remove fuses manually. Do not re-use your cooktop until the glass top is changed. When cooking never use aluminum foil and never place products wrapped in aluminum foil, nor products deep-frozen in aluminum packs on the hob.
- Page 10 99637771_A_EN.qxp 19/07/2005 11:45 The p p rinciple o o f i i nduction When an induction element - also called: ‘a heating zone’, or simply: ‘a coil’ - is switched on, the appropriate utensil is used, and a desi- red level of heating power selected, the elec- tronic circuit unit (‘induction generator’...
-
Page 11: Description Of The Control Panel
99637771_A_EN.qxp 19/07/2005 11:45 Glass Top, Coil Size and Controls 18 c c m(7” ) ) 50 W à 2800 W 28 c c m 50 W à 3600 W 18 c c m ( ( 7”) 50 W à 2800 W DESCRIPTION OF THE CONTROL •... -
Page 12: Power Sharing
99637771_A_EN.qxp 19/07/2005 11:45 • WHICH COOKING ZONE SHOULD YOU USE BASED ON YOUR COOKWARE? Cooking Cookware to use zone 16 c c m ( ( 6 ”) 10 ..1 1 8 c c m ( ( 4..7”) 18 c c m 12 . - Page 13 If a utensil is left on an element at full power, temperature of the dish may increase rapidly, the safeties would not engage, and this may damage your utensil, the cooktop, and could result in an injury or a damage to your property. Page 13...
- Page 14 Your cooktop must never be used as a storage space or surface for piling up of any material. Page 14 - Avoid storing flammable products in the cabinets under your cooktop.
-
Page 15: Maintaining Your Appliance
MAINTAINING YOUR APPLIANCE • Cleaning of an induction cooktop is easy. Read and follow these WHAT T T O D D O T T Y Y P P E E O O F F S S T T A A I I N N S S / / S S P P O O T T S S... - Page 16 99637771_A_EN.qxp 19/07/2005 11:45 4 4 / SPECIAL MESSAGES, DIFFICULTIES You have doubts about whether your hob is working correctly. This does not necessarily mean that there is a breakdown. Nevertheless, check the following points. P R O B L E M When you switch the unit on, the supply-line breaker trips off or the supply-line fuse burn.
