Hear Technologies Hear back pro Quick Start Manual

QUICK START GUIDE
Thank you for purchasing the Hear Back PRO 16-channel personal monitor mixer system!
Use this Quick Start Guide to setup quickly and easily. Refer to the User Guide for complete
instructions, available online at www.hearback.com/support or scan the QR code above.
CONNECTING THE SYSTEM
1
Connect the appropriate input(s) as shown in the hook-up diagram.
2
Select the desired input using the front panel switch.
3 Connect Hear Back PRO Mixers to the Network Card outputs
using CAT6* cables.
4
Turn on Hub Power.
5 Set all Mixer Channels and Master Volume levels to 0%.
6 Connect the headphones, in-ear monitors, and/or line outputs
for connecting to wireless in-ear systems, powered monitors, or
other devices requiring line-level inputs.
HOOK-UP DIAGRAM
HUB FRONT PANEL
HUB REAR PANEL
1
*Cable complying with the National authorities (cable with an outer jacket or sleeving rated VW-1 or better).
Hear Back PRO is proudly designed & assembled
in the U.S.A. by musicians and audio engineers.
WARNING
!
• The Hear Back PRO is capable of
driving most headphones to extreme
levels that can damage your HEARING!
• ALWAYS turn down the Mixer "Master"
volume down before putting on in-ear
headsets or headphones.
2 4
3
5
6
5
6
FOR USER
5
6
5
6
SCAN
CODE
GUIDE
