Hear Technologies Hear Back OCTO Quick Start Manual

QUICK START GUIDE
Thank you for purchasing the Hear Back OCTO 8-channel personal monitor mixer system!
Use this Quick Start Guide to setup quickly and easily. Refer to the User Guide for complete
instructions, available online at www.hearback.com/support or scan the QR code above.
CONNECTING THE SYSTEM
Connect the appropriate input(s) as shown in the hook-up diagram.
1
Select the desired input using the front panel switch.
2
Connect Hear Back OCTO Mixers to the Network Card outputs
3
using CAT5e cables.
4
Set all Mixer Channels and Master Volume levels to "Off"
(full counter-clock-wise position).
5 Connect the headphones, in-ear monitors, and/or line outputs
for connecting to wireless in-ear systems, powered monitors, or
other devices requiring line-level inputs.
6 Apply power to the Hub.
HOOK-UP DIAGRAM
HUB FRONT PANEL
HUB REAR PANEL
1 6
Daisy-Chain Additional OCTO Hubs
3
ADAT Optical Input
4
5
4
Hear Back OCTO is proudly designed & assembled
in the U.S.A. by musicians and audio engineers.
WARNING
!
• The Hear Back OCTO is capable of
driving most headphones to extreme
levels that can damage your HEARING!
• ALWAYS turn down the Mixer "Master"
volume down before putting on in-ear
headsets or headphones.
2
Connect Additional OCTO Mixers
4
5
5
5
FOR USER
Analog Inputs
4
SCAN
CODE
GUIDE
