Front Suspension
12
Rear Suspension
13
T02082 M3x10 Screw
............4
T02092 Ball stud-Long
.....................2
Rear Suspension
14
T02083 M3x8 Screw
..................2
T02055 3x48 Hinge Pin Rear Inner
............2
Assemble Both Left And Right
L
R
T02082 M3x10
T02082 M3x10
T02082 M3x10
T02092
TU0221
T02055
TU0221
TS2020
T02018
TU0221
T02083 M3x8
6
T02082 M3x10 Screw
TG2004
T02009
............6
L
R
