Summary of Contents for ECS I36IA1

  • Page 2 Preface  Copyright 2009  All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if...
  • Page 3 Reorient or relocate the receiving antenna Increase the separation between the equipment and receiver Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radio TV technician for help This device complies with Part 15 of the FCC Rules.

  • Page 4: Table Of Contents

    Table of Content   ................2 EFORE YOU TART ..........9   ET YOUR COMPUTER ACCLIMATE ITSELF ............ 9   UMIDITY LARE ..............10   UITABLE PLACE TO WORK   ..................12 NTRODUCTION ..................13   RONT ..................15   IEWS ..................
  • Page 5 ................53   ALIBRATE OLOR ..............53   DJUST ISPLAY ETTING ............... 54   ONNECT TO A ROJECTOR ..............54   DJUST LEAR   3G C .................. 56 ONNECTION   ................61 ROUBLESHOOTING ................ 62   O SPEAKER OUTPUT ............62  ...

  • Page 7: Before You Start

    Use this manual will help you get the most from your notebook computer. If you are an experienced user of computers and/or Microsoft’s Windows operating systems, you might find it useful to read the Quick Start Guide that comes along with your accessories.
  • Page 8 Make sure to use the right voltage for the power source when connecting the equipment to the power outlet. Place the power cord in such a way that people can not step on it. Do not place anything on top of the power cord. All cautions and warnings on the equipment should be noted.
  • Page 9 The minimum specifications for the flexible cord are  No. 18 AWG, (2) Type SPT-2, and (3) 2-conductor. For Japan: All components of the cord set must bear a “PSE”  mark and in accordance with the Japanese Dentori Law. The minimum specifications for the flexible cord ...
  • Page 10  Do not use the telephone to report a gas leak in the vicinity of the leak.  Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special instructions.
  • Page 11 Bitte lesen Sie diese Hinweis sorgfältig durch. Heben Sie dirse Anleitung für den späteren Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Versenden Sie Keine Flüssig- oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. Die Netzanschluβsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein.
  • Page 12 Stromnetz zu trennen und von einer qualifizierten Servicestelle zu Überprüfung.: Netzlabel oder Netzstecker sind beschädigt. Flüssigkeit ist in das Gerät eingedrungen. Das Gerät war Feuchtigkeit ausgesetzt. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
  • Page 13 Die Minimalanforderungen für das Kabel sind .75m  ㎡ Leiter. (2) Type VCTF oder VCTFK, und (3) 2- conductor. Der Kabelsatz muss mindestens für eine  Stromstärke von 7A geeignet sein. Der Wandstecker muss ein zweipoliger geerdeter  Steckertyp gemäß dem Japanese Industrial Standard C8303 (15A, 125 VAC) sein.

  • Page 14: Let Your Computer Acclimate Itself

    Batterien nicht ins Feuer, sie könnten explodieren. Informieren Sie sich über die örtlichen Bestimmungen bezüglich der Entsorgung. Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu Wasser oder anderen Flüssigkeiten. Gießen Sie nie Flüssigkeiten über das Netzteil. Es besteht Explosionsgefahr, wenn der Akku nicht ordnungsgemäß...

  • Page 15: Suitable Place To Work

    Do not place your computer in direct sunlight. Your computer will run well wherever you’re comfortable but extremes of temperature and humidity can be challenging to your system’s parts. There are some things you can tolerate that the computer can’t – things like static electricity, dust, water, steam and oil.

  • Page 17: Introduction

    Install the battery pack Connecting the AC adapter Opening the display panel...

  • Page 18: Front View

    Turning on your computer With the LCD screen open, you will see several features important for operating your notebook computer.
  • Page 19 Camera (Optional) LCD Display Power/Suspend Button  Press for 1~1.5 seconds to turn on the system.  Press and hold for at least 4 seconds to turn off the system.  Press the power / suspend button again to return from the suspend mode.

  • Page 20: Left Views

    Blue light indicates the hard drive and/or optical drive is being accessed. FingerPrint (Optional) 4-in-1 Card Reader (SDHC/MS/MMC/MS pro Memory Card) Touchpad Touchpad Buttons HDMI/CRT Port USB 2.0 Port Enhanced USB 2.0 Port Microphone/Audio Line-in Jack Stereo Headphone Jack...

  • Page 21: Right View

    DC In Kensington Lock USB 2.0 Port Optical Drive Modem Port (Optional) Ethernet / LAN Port...
  • Page 22 Battery Lock Battery Compartment Battery Release Latch...

  • Page 24: Started

    A universal AC adapter is provided to supply your computer with power and also charge the computer’s battery pack. The adapter’s AC input voltage can range anywhere from 100 to 240 volts, covering the standard voltages available in almost every country. To connect the computer to an external power source:...
  • Page 25 Whenever possible, keep the AC adapter plugged into the notebook and an electrical outlet to recharge the battery. ’ ’ Hold the button down for a second or two and release. The Power- On Self Test (POST) runs automatically. After the POST is completed, the computer reads the operating system from the hard disk drive into computer memory (this is commonly referred to as “booting”...

  • Page 26: T I B Pack

    ’ ’...
  • Page 27 The installed battery pack charges automatically any time the computer is connected to the AC adapter and an external power source. It is a good idea to occasionally discharge the battery pack fully to preserve its operating performance.

  • Page 29: Using The Notebook Computer

    The LCD screen display can be adjusted by the following key combinations. Fn + F4 Changes Display Mode: LCD-only, CRT-only (or HDMI only) and LCD&CRT (HDMI). Fn + F7 Increases the brightness level. Fn + F8 Decreases the brightness level. LCD screens are delicate devices that need careful handling.
  • Page 30 You can switch between these display configurations by pressing the key combination [Fn] + [F4]. ’ ’ Action System Control Fn + F1 Enters Suspend Mode. Fn + F2 Enters the Silent Mode. Fn + F3 Mute/Unmute Audio/ PC beep to Output Fn + F4 Changes Display Mode: LCD-only, CRT-only (or HDMI only) and LCD&CRT (HDMI).
  • Page 31 Scroll Locks On/Off RF On/Off Fn + F10 3G On/Off Fn + F12 Brightness Fn + F7/F8 Mute On/Off Fn + F3 Volume Fn + F5/F6 OSD-Bar Icon Caps Locks On Num Locks On Scroll Locks On Silent Mode ON Touchpad Off WLAN On RF On (By project)
  • Page 32 Live Power is a saving scheme technique that provides saving your battery consumption by disabling some devices thus extending the battery life. Click on the Live Power icon from the lower right bar of your screen to open up the Live Power Display.

  • Page 33: Power Saving Mode

    This Live Power application provides a super saving options if the following items are selected: Power Off LCD panel Enable advance power saving engine Turbo Mode LCD Brightness: Level 1 HDD Off: Idle after 3 minutes CPU Speed: Level 0 Sleep: Idle after 5 minutes LCD Off: Idle after 5 minutes Hibernate: Idle after 10 minutes...

  • Page 34: High Performodeance Mode

    LCD Brightness: Level 5 HDD Off: Idle after 30 minutes CPU Speed: Maximum level Sleep: Idle after 1 hour LCD Off: Idle after 15 minutes Hibernate: Idle after 2 hours LCD Brightness: Level 5 HDD Off: Never CPU Speed: Maximum level Sleep: Never LCD Off: Never Hibernate: Never...

  • Page 35: Mode

    LCD Off: Idle 4 hours Hibernate: 2 hours CPU Loading Battery High Middle plus Middle life% 50% up 30% up 4%up <4% level High Performance High Performance High Performance Normal mode mode mode mode level High Performance High Performance Normal Normal mode mode mode...

  • Page 36: Touch Pad Precautions

    The touchpad is a rectangular electronic panel located just below your keyboard. You can use the static-sensitive panel of the touchpad and slit it to move the cursor. You can use the buttons below the touchpad as left and right mouse buttons. The TouchPad is a pressure sensitive device.

  • Page 37: Data Storage And Retrieval

    The system will only enable you to use one tracking device whether it is an internal or external tracking device. Data storage and retrieval are two of the most fundamental tasks you will perform when working with your computer. The Notebook is equipped with a hard disk drive (HDD).

  • Page 38: Calibration )

    To remove the battery pack from its compartment, please refer to Chapter 3, Inserting and Removing the Battery Pack. Before using the battery pack for the first time, battery pack should be calibrated in order to get accurate reporting of remaining battery life status..

  • Page 39: Battery Status

    Windows 7 has an applet in the Control Panel that will display an icon in the Windows taskbar indicating when the notebook is running on battery power or is attached to the AC adapter. This applet also displays a meter that indicates how much charge is remaining in the battery.

  • Page 40: Help Windows

    After installing a software application package, you may be prompted to reset the system to load the changed operating environment. To reset the system, or “reboot,” press the [Ctrl]+[Alt]+[Delete] keys simultaneously. This is known as “warm boot.” This key combination acts as “software” reset switch when you encounter hardware or software problems, which lock up the notebook.

  • Page 41: Desktop

    Desktop may vary differently on the software installed in your notebook with different or additional shortcuts. Recycle Bin Used for storing deleted files in case you want to recover and save it in your system. The files will only be deleted from the Recycle Bin permanently only if you empty it by right clicking your mouse and select the “Empty Recycle Bin”.
  • Page 42 The Start menu allows you to adapt and show the programs used most frequently. If you wish to keep an item, right click the item and click Pin to Start menu. Log Off will enable the current user to log off and allows a new user to log on.
  • Page 43 It is in this area that you can change how Windows looks and works. Click Start  Control Panel dialog box. There are two interfaces – Classic View.
  • Page 46 “ ” “ ”...

  • Page 49: Running Bios Setup

    The Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/Output System). It runs and maintains a variety of hardware functions. It is menu-driven software, which allows you to easily configure and change the settings. The BIOS contains manufacture’s default settings for the computer’s standard operations.

  • Page 50: Info Setup

    Function Key Command Description Leaves a sub-menu to return to the Exit previous menu OR exits the BIOS setup while saving changes. Enter Go to Sub Screen Shows the Sub Menu General Help Shows the Help Screen Default Set to default Saves changes and reboots the Save and Exit computer.

  • Page 51: Main Setup

    Under this menu, you may change time/date and view basic processor and system memory information.

  • Page 56: Vga Utilities

    You can click the touchpad or mouse right button and select the “Personalize” item.

  • Page 61: Connection

    3G is the third generation of mobile phone standards and technology. 3G enable users a wide range of more advanced service while achieving greater network capacity through improved spectral efficiency. Press Fn + F12 to run the 3G application. Procedures in installing the application...
  • Page 62 Insert the SIM card into the SIM slot. Execute the application by pressing the Mobile Partner icon From the Mobile Partner display window, click on the “Tools” item Select the “Options”.
  • Page 63 Double click on the “Profile Management” and click on the “New” tab Click on the “OK” tab.
  • Page 64 On the next window, click on the “Connect” tab. The HSPA is successfully connected...

  • Page 66: Troubleshooting

    Your computer has been fully tested and complies with the system specifications before shipping. However, incorrect operations and/or mishandling may cause problems. This chapter provides a reference for identifying and correcting common hardware and software problems that you may encounter. When you encounter a problem, you should first try to go through the recommendations in this chapter.

  • Page 67: N O Speaker Output

    Be sure all the device drivers are installed properly. For example, without the audio driver properly installed, the speakers and microphone will not work. If external devices such as USB camera, scanner, printer do not function correctly when connected to the system, it is usually the device’s own problem.

  • Page 68: The Hard Disk Drive Does Not Work Or Is Not Recognizable

     Select Recording and click the OK button.  After Click OK button, the recording volume control panel will appear. Go to [Start > Settings > Control Panel] and double-click the Multimedia icon (or Sounds and Audio Devices icon). In the Volume or Audio page, make sure that the audio codec mentioned in the spec is the default recording device.

  • Page 69: The Hard Disk Takes Longer To Read A File

    Many browsers store files in the hard drive as a cache to speed up the performance. Check the program’s Online Help for instructions on decreasing the cache size or on removing temporary Internet files. Empty the Recycle Bin to create more disk space. When you delete files, Windows saves them to the Recycle Bin.

  • Page 70: The Built - In Touch Pad Performs Erratically

    down or powering up. Make sure there is no excess perspiration or humidity on your hand when using the touch pad. Keep the surface of the touch pad clean and dry. Do not rest your palm or wrist on the surface of the touchpad while typing or using the touch pad.

  • Page 71: The Post Does Not Show An Increased Memory Capacity When

    Certain brands of memory module may not be compatible with your system. You should ask your vendor for a list of compatible DIMM. The memory module may be defective. This is often a software or Windows-related problem. A program is draining the memory resources. Close the application programs you’re not using and restart the system.

  • Page 72: Windows Crashes Or Freezes When You Remove The Wpc Card

    Make sure you have <Stop> the PC card before removing it. Double-click the Safely Remove Hardware icon at the lower right corner of the task bar and select the card you wish to stop. When you click <Close>, in few seconds Windows will prompt you to remove the card.

  • Page 73: The Usb Device Does Not Work

    Check the settings in the Windows Control Panel. Make sure you have installed the necessary device drivers. Contact the device vendor for additional support. Detach the external device; insert it into the Enhanced USB port. Separate the cable with the equipment; first insert the wire into the port, then connect the device with the cable that is inserted into the Enhanced USB port.

  • Page 75: Specification

    O.S. Supports Windows 7 Home Premium ULV Intel Celeron Processor SFF support, 743/SU2300 (Up to 1.3GHz), 1MB L2 Cache, 800MHz FSB, TDP: 10 W ULV Intel Pentium® Processor SFF support, SU4100 (Up to 1.3GHz), 2MB L2 Cache, 800MHz FSB, TDP: 10W Memory DDRIII 800/1066/1333MHz support (1066/1333MHz may downgrade to 800MHz)
  • Page 76 LAN Controller Supports 10/100 Mb/Sec (8103EL--VB-GR) or 10/100/1000Mb/Sec (8111DL-VB-GR). PCI-E interface Wireless LAN PCI-E interface Half-Card size IEEE 802.11 B/G/N Camera (Optional) Support 1.3M/2.0M Camera Keyboard US 86 /UK 87/ BR 88 keys KB support Pointing Device PS2 Touch Pad with 2 buttons Support gesture function 14"...
  • Page 77 Speaker/MIC Build-in 2 speakers Internal Microphone support BIOS Supports PnP, ACPI 3.0 Support external USB flash memory card boot up. Be with Phoenix BIOS and 2MB flash ROM Power Management (default: Silent mode) “Smart Power II” Power Management Physical Outline 348mm x 229.5mm x 27.8~31.8 (w/ rubber foot, w/ ODD) 348mm x 229.5mm x 27.04~31.04 (w/o rubber foot, w/ ODD) 348mm x 229.5mm x 24.8~31.8 (w/ rubber foot, w/o ODD)
