BandLuxe R550 Series User Manual

Lte/hspa+ wi-fi router
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
BandLuxe
R550 Series
LTE/HSPA+ Wi-Fi Router

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R550 Series and is the answer not in the manual?

Questions and answers

Related Manuals for BandLuxe R550 Series

Summary of Contents for BandLuxe R550 Series

  • Page 1 User Manual BandLuxe R550 Series LTE/HSPA+ Wi-Fi Router...

  • Page 3: Table Of Contents

    Table of Contents Package Contents ................4 Features ........................4 Hardware Overview ....................5 Installation ..................7 Using Web-based Management ..........10 Status ........................11 Overview ......................11 System ..........................11 Network ........................... 12 DHCP Leases ........................12 Local Network ........................12 System Log ......................
  • Page 4 Physical Settings ......................25 Firewall Settings ......................25 Mobile Internet ..................... 27 WWAN Setting ......................... 28 Network Settings ......................28 Auto APN Information ....................29 APN Profile Settings ....................29 Reset Modem ....................... 29 U/SIM PIN Management....................30 Scenario 1: No mobile internet service ................ 30 Scenario 2: Mobile internet service pending ..............
  • Page 5 SMS ........................61 New SMS ......................... 61 Inbox ..........................62 Outbox ..........................62 Draft ..........................64 Setting..........................65 Setting .......................... 65 Backup ......................... 66 Help ........................67 Logout ........................67 Appendix A: FAQ ................. 68 Appendix B: Specifications ............75 Appendix C: Important Safety Information and Glossary ..

  • Page 6: Package Contents

    Package Contents R550 series LTE Home Router Power Adapter Features  R550 series LTE Home Router  Wi-Fi Protected Setup (WPS) Support  Uplink up to 50 Mbps  Downlink up to 100Mbps  Supports Wi-Fi 802.11 b/g/n ...

  • Page 7: Hardware Overview

    Package Contents Hardware Overview 4G External Connect 4G External Antennas if needed. Antenna Ports SIM Card Slot Insert SIM/USIM. Push-push type. Power Switch Switch on/off the router. Signal Strength Short press (1 second): Enable signal strength LED/WPS/Reset indication. button Press for 3 seconds (< 10 seconds): Active WPS.
  • Page 8 Package Contents Power LED Solid when power is on / Signal Strength LED WiFi LED Solid when WiFi is on; Flashing during WiFi data transmission / Signal Strength LED WPS LED Flashing when WPS is in use /Signal Strength SMS LED Flashing when there is unread SMS / Signal Strength LED Signal Strength...

  • Page 9: Installation

    Installation Installation 1. Connect the power Adapter to the Router( ) and connect it to an outlet. 2. Insert your SIM card into the slot on the Router, making sure the SIM card orientation matches the SIM card slot, as shown in the picture. 3.
  • Page 10 Installation A. Wireless Connection (for Windows) To connect your PC to the Router via WiFi, in Microsoft Windows, go to Control Panel > Network Connections. Right click on Wireless Network Connection and choose View Available Wireless Networks. Select default SSID [BR_LTE_xxxx] and enter default password (WPA key, refer to label on the Router’s backside).
  • Page 11 Installation 5. The router uses a web-based configuration utility. To access the configuration utility, open a browser (ex: Mozilla, Firefox, etc.) and enter the IP address (http://192.168.1.1) for the Router in your browser’s address bar. Enter the router Username (admin) and Password (admin), and then click...

  • Page 12: Using Web-Based Management

    Using Web-based Management Using Web-based Management This chapter will guide you on how to configure your router via the web-based utility. Login 1. Launch a web browser (e.g Mozilla Firefox). 2. In the address bar, enter http://192.168.1.1, then press Enter. 3.

  • Page 13: Status

    Using Web-based Management Status This menu displays various status of the router. The associated submenu items are: Overview, System Log, VnStat Traffic Monitor, and Mobile Internet. Overview The Overview submenu renders complete statistics for the router. System Displays system information: router model name, router firmware version,...

  • Page 14: Network

    Using Web-based Management modem firmware version, phone number (MDN), ICCID, MIN (MSID), PRL version, IMEI, MEID, and local time. Network Displays current network connection information of IPv4 WAN and/or IPv6 WAN: type of network assignment (e.g. DHCP), network address, netmask, gateway, DNS addresses 1 &...

  • Page 15: Vnstat Traffic Monitor

    Using Web-based Management VnStat Traffic Monitor Graphs Displays VnStat network traffic history in various graphic analysis options: Summary display, Top 10 display, Hourly traffic, Daily traffic, and Monthly traffic. Click to select an analysis option from the drop-down list, and click Update. The VnStat Graphs will be updated accordingly.

  • Page 16: Mobile Internet

    Using Web-based Management VnStat Traffic Monitor configurations can be made here. a) Monitor selected devices: Click the checkbox to enable/disable network monitoring of the displayed interface(s). Click the link to jump to the  Common Configuration setting under the submenu Network Interfaces.

  • Page 17: Registered Network

    Using Web-based Management d) PIN Enable(Verified) – PIN protection is enabled while the SIM card status is verified; mobile internet service is available with this status. Registered Network a) Network Name – name of your mobile internet service provider b) Network Technology – mobile internet communication signal type. Ex: WCDMA (3G) and LTE (4G).

  • Page 18: System

    Using Web-based Management System This menu is for system information and configurations. System System Properties Click either the “General Settings” or “Language and Style” tab to configure their respective settings. General Settings Local Time – Displays current local time. To synchronize local time with the browser, click Hostname –...

  • Page 19: Language And Style

    Using Web-based Management Language and Style Language – Sets the desired display language and style of the router. Click and select the desired display language and style. Time Synchronization Enable NTP client: Click the checkbox to enable/disable. With this option enabled, two more options will appear–...

  • Page 20: Administration

    Using Web-based Management Administration Router Password Login password of the router can be changed here. Enter the new password in the ‘Password’ field, and enter the same password once again in the ‘Confirmation’ field. Remote Access This field specifies whether or not to allow remote access of this router. After changing password and/or specifying remote access, click .

  • Page 21: Backup / Flash Firmware

    Using Web-based Management Backup / Flash Firmware Backup / Restore Download backup Here you can backup all current settings of the router to a TAR archive file on your computer or mobile device. Just click . A dialog window will prompt you to open or save the archive file.

  • Page 22: Reset To Defaults

    Using Web-based Management Reset to defaults Here you can restore the router to its original factory settings. Just click , and a dialog message will appear to indicate the factory reset process. After completion of the reset process, the router will automatically reboot and return to its initial login prompt.

  • Page 23: Reboot

    Using Web-based Management update. For manual wireless update, disable “Auto check”. Confirm that the “Check link for Router” and “Check link for Module” fields have appropriate web address(es) present in their text boxes, i.e. http://www.bandrich.com/mdm9x15/ . Click to activate the wireless update configurations into effect.

  • Page 24: Services

    Using Web-based Management Services Dynamic DNS The Services menu hosts configuration options for DDNS (Dynamic Domain Name Service), which is a system that allows the domain name data held in a name server to be updated in real time. It allows an Internet domain name to be assigned to a computer with a varying (dynamic) IP address.

  • Page 25: Network

    Using Web-based Management Network Interfaces The Interfaces submenu allows interface configurations of different networks connected to this router. The configuration items are the same for each network with different default settings. Interface Overview Here you can see the brief network status summary for LAN (local area network) and WAN (wide area network).

  • Page 26: Common Configuration

    Using Web-based Management Common Configuration General Setup Status: Displays protocol-dependent statistics of network connection. Protocol: Specifies the protocol to be used for the network. The available protocols are Static address, DHCP client, Unmanaged, PPP, PPtP, PPPoE, PPPoATM, UTMS/GPRS/EV-DO, and L2TP. The default LAN protocol is Static address, whereas the default WAN protocol is DHCP client.

  • Page 27: Advanced Settings

    Using Web-based Management Advanced Settings This tab is for advanced users to make detailed configurations of protocol-related settings. Actual configuration items will vary according to the protocol chosen in the tab item General Setup. Physical Settings This tab is for selection of physical interface of the associated network. Click one of the available physical interfaces or click and enter your own interface name.
  • Page 28 Using Web-based Management you can define a new zone by entering your own firewall name in the unspecified -or- create field and clicking...

  • Page 29: Mobile Internet

    Using Web-based Management Mobile Internet The Mobile Internet submenu is for setup and adjustment of mobile internet connection and furthermore has four setting tabs: WWAN Setting, U/SIM PIN Management, SIM Management, and Preferred Network.

  • Page 30: Wwan Setting

    Using Web-based Management WWAN Setting Network Settings Roaming Enables or disables current roaming setting. Connection: Update Profile: Click Update to update the network profile. Update PRL: Click Update to update the PRL (Preferred Roaming List). APN Update: Displays the current APN (Access Point Name) version.

  • Page 31: Auto Apn Information

    Using Web-based Management Settings for network. This item appears when APN is set to ‘Manual’. Profile Selection: Auto APN Information This section displays automatic APN information. APN Profile Settings For Advanced Users This section allows you to establish your own APN profile settings. To establish a new APN profile, type in a new APN profile name in the text box and click Enter the APN, username, and password.

  • Page 32: U/Sim Pin Management

    Using Web-based Management U/SIM PIN Management This submenu features configurable items that are dependent on the router’s mobile internet status, as detailed below. Scenario 1: No mobile internet service Without a valid SIM card inserted into the router, the Verify dialog will show the following SIM card status: Here the Verify dialog shows SIM status as “Read SIM Fail”, meaning that no valid SIM card is inserted.

  • Page 33: Scenario 3: Mobile Internet Service Enabled

    Using Web-based Management ready to use the SIM card’s associated mobile internet access, and the top right status area will be updated accordingly. Operator Name: Displays the name of the internet service provider WiFi: Shows the active WiFi SSID of this router Counter: Shows number of clients currently connected to the active SSID...

  • Page 34: Sim Management

    Using Web-based Management mobile internet access. “PIN Disable(Verified/Retries:#)” means that the SIM card is enabled for mobile internet access without requiring PIN code verification. Note that if PIN protection is re-enabled, # is the number of allowed PIN verifications remaining before SIM lock occurs. PIN Protection: Enables or disables the PIN protection by clicking and making the appropriate choice from the drop-down...

  • Page 35: Scenario 1: Sim Lock Absent

    Using Web-based Management Scenario 1: SIM lock absent “SIM no lock” means that the SIM card is unlocked. Scenario 2: SIM lock present If your SIM card is locked for some reason, here you can also enter the SIM unlock code to unlock it. After entering the SIM unlock code in the text box “SIM Unlock”, click Preferred Network Here you can select the preferred mobile network type by clicking...

  • Page 36: Router

    Using Web-based Management Router Router Settings Router IP Local IP Address: The default local IP address of this router is 192.168.1.1. If this address conflicts with another local network device, you can enter another local IP address here. Subnet Mask: Displays current Subnet Mask Device Name: The current device name is displayed in gray color.

  • Page 37: Dhcp Service

    Using Web-based Management DHCP Service DHCP Server: Enables or disables the DHCP Server feature. Start IP Address: Specifies the starting number of the last 3 digits of assigned client IP address. For example, the default value of 100 means that the first assigned client IP address will be 192.168.1.100;...

  • Page 38: Static Leases

    Using Web-based Management This section displays active DHCP lease information for each client: Hostname, IPv4 address, MAC address, and Lease time remaining. Static Leases This option allows fixed IP address and symbolic hostname assignments for DHCP clients. To add a static lease, first click Enter the desired hostname.

  • Page 39: Advanced Routing Settings

    Using Web-based Management Advanced Routing settings Static Routing This option allows fixed network routing path assignment (as opposed to the initial adaptive routing). To add a static network routing path, click . To remove any unwanted static network routing path, click the corresponding button.

  • Page 40: Routing And Redirection Service

    Using Web-based Management specified here. Metric: Specifies the network path priority number (usually associated with the network path’s administrative distance). The lower the metric number, the higher priority of this static route in the network routing protocol. The default value is 0 (highest priority). A different metric number can also be specified here.

  • Page 41: Wifi

    Using Web-based Management WiFi This submenu item is for configuring all Wi-Fi-related settings. This router supports up to two WiFi SSIDs. The default SSID is as follows: Tab Name Corresponding SSID Default Password “BR_LTE_xxxx” BR_LTE_xxxx The last 4 digits of MAC address (xxxx) converted into 2-digit decimal numbers, please see table below for...

  • Page 42: Device Configuration

    Using Web-based Management Device Configuration General Setup Wireless WiFi connection of the associated SSID is enabled. network is To disable WiFi connection of this SSID, click enabled* Wireless WiFi connection of the associated SSID is disabled. network is To enable WiFi connection of this SSID, click disabled* * Note: The associated SSID is displayed either in the selected submenu tab under WiFi or in the WiFi category...

  • Page 43: Advanced Settings

    Using Web-based Management 7 (2.442 GHz) 8 (2.447 GHz) 9 (2.452 GHz) 10 (2.457 GHz) 11 (2.462 GHz)  assigns channel automatically auto  manually specifies WiFi channel -- custom -- Normally one of the channels is already selected, and no change is needed unless there exists interference problems with other WiFi or Bluetooth devices (that also use the 2.4GHz frequency range for communications).

  • Page 44: Interface Configuration

    Using Web-based Management Interface Configuration General Setup SSID Service Set Identification To change the SSID, click the text box and enter the new SSID (up to 32 alphanumeric characters) Mode Wireless operating mode of this router. Wireless Access Point Hide SSID Enable this option to make wireless network of this SSID unavailable to nearby WiFi clients.
  • Page 45 Using Web-based Management The encryption options are: 1. No Encryption ata transmitted over wireless networks can be seen by others. 2. WEP Open System Wired Equivalent Privacy encryption with Open System authentication ey: Enter a password for accessing this SSID’s wireless network. 3.
  • Page 46 Using Web-based Management Cipher: Specifies the desired encryption protocol by clicking selecting an option from the drop-down list: auto – (Default setting) the system automatically chooses the optimal encryption protocol Force CCMP (AES) – Use CCMP (AES) encryption exclusively (stronger than TKIP) Force TKIP –...
  • Page 47 Using Web-based Management “WiFi Protected Access – Extensible Authentication Protocol” encryption Cipher: Specifies the desired encryption protocol by clicking selecting an option from the drop-down list: auto – (default setting) the system automatically chooses the optimal encryption protocol Force CCMP (AES) – Use CCMP (AES) encryption exclusively (stronger than TKIP) Force TKIP –...

  • Page 48: Mac-Filter

    Using Web-based Management auto – (default setting) the system automatically chooses the optimal encryption protocol Force CCMP (AES) – Use CCMP (AES) encryption exclusively (stronger than TKIP) Force TKIP – Use TKIP encryption exclusively Force TKIP and CCMP (AES) – Use TKIP and CCMP (AES) encryption protocols together Radius-Authentication-Server: Enter the name of the RADIUS authentication server.

  • Page 49: Advanced Settings

    Using Web-based Management Advanced Settings This tab item is for advanced adjustment settings for WiFi connection. Fragmentation Maximum transmittable data packet frame size Threshold without frame fragmentation; the default value is 2346 RTS/CTS Defines Request-To-Send (transmitter) and Threshold Clear-To-Send (receiver) control packet size; the default value is 2347 WMM Mode Enables or disables Wi-Fi Multimedia Mode, which...
  • Page 50 Using Web-based Management must have a WPS button configured to PBC Mode.) PIN Mode – Personal Identification Number Mode (Note: To use this setup method, the client must have a WPS button configured to PIN Mode.) After choosing PIN Mode, an additional text box item “PIN Code”...

  • Page 51: Firewall

    Using Web-based Management Firewall Single Port Forward Single Port Forward Port Forwarding allows you to set up public services on your network, such as web servers, ftp servers, e-mail servers, and other specialized Internet applications. To forward a single port: 1.
  • Page 52 Using Web-based Management In the status area, the message Unapplied Change may appear next to “Operator Name” to indicate configuration changes temporarily stored in the router. 7. More rules can be added to the Port Forwards list by repeating ‎ ‎...

  • Page 53: Port Trigger

    Using Web-based Management Port Trigger Port Trigger Port Triggering allows the Router to watch outgoing data for specific port numbers. The Router remembers the IP address of the computer that sends the matching data, so that when the requested data returns through the Router, the data is pulled back to the proper computer by way of IP address and port mapping rules.
  • Page 54 Using Web-based Management 5. Click . The port triggering rule you have just entered will be added to the Port Triggering list. the status area, the message Unapplied Change may appear next to “Operator Name” to indicate configuration changes stored in the router. 6.

  • Page 55: Security Filter

    Using Web-based Management Security Filter Here you can make Firewall, Internet Filter, and Web Filters adjustments for network security. Firewall SPI Firewall Enable or Disable Stateful Packet Inspection (SPI) feature of the firewall. The default setting is ‘Enable’. Protection: Internet Filter Filter Anonymous This filter blocks anonymous internet requests from outside network.

  • Page 56: Web Filters

    Using Web-based Management external address) from other local computers. The default setting is ‘enabled’. Filter IDENT This feature keeps Port 113 from being scanned by (Port113): devices outside of your local network. The default setting is ‘disabled’. Web Filters Using the Web Filters feature, you may enable up to four specific filtering methods.

  • Page 57: Ip Filtering

    Using Web-based Management address of the computers that are placed outside the firewall of your network. In the text box, enter the last 3 digits of the DMZ host address (the prefix is 192.168.1 for this router), and then click The host IP address will be added to the DMZ Host list, which can be further disabled or enabled by clicking the ‘Enable’...
  • Page 58 Using Web-based Management 4. Filter Source Port: Enter the source port number to be filtered. 5. Click . The IP filtering rule you have just entered will be added to the IP Filtering list. In the status area, the message Unapplied Change may appear next to “Operator Name”...

  • Page 59: Port Range Forward

    Using Web-based Management Port Range Forward Port Range Forward Port Range Forward allows you to set up public services on your network, such as web servers, ftp servers, e-mail servers, and other specialized Internet applications. To forward a port range: 1.
  • Page 60 Using Web-based Management 5. Click . The port range forwarding rule you have just entered will be added to the Port Range Forward list. the status area, the message Unapplied Change may appear next to “Operator Name” to indicate configuration changes temporarily stored in the router.

  • Page 61: Diagnostics

    Using Web-based Management Diagnostics This menu contains tools for effective network analysis and troubleshooting. Network Utilities Ping This feature allows you to check the status of a connection. 1. In the text box next to , enter the IP address or URL that you want to ping, and then select its corresponding internet protocol by clicking either the IPv4 or IPv6 radial button.

  • Page 62: Ns Lookup

    Using Web-based Management 1. In the text box next to , enter the IP address or URL that you want to trace route, and then click to start the performance text. ‘Traceroute’ messages will appear below. NS Lookup This feature allows you to retrieve name server information. 1.

  • Page 63: Sms

    Using Web-based Management Short Message Service – Allows mobile phones and network devices to exchange short text messages. New SMS Here you can write and send a new SMS message. Enter the recipient’s phone number in the field Phone number. Enter message texts in the field Contents. To erase written contents and start over again, click .

  • Page 64: Inbox

    Using Web-based Management Inbox Here you can receive and read incoming SMS messages. To get messages from the server, click . To remove unwanted messages, select messages to delete and click Outbox Here you can see SMS messages that have been sent out.
  • Page 65 Using Web-based Management To forward a particular SMS message, check only the message of interest without checking others. Click An additional configuration item Forward SMS will appear on top of the configuration item Outbox. If necessary, modify the recipient’s phone number in the field Phone number or modify message texts in the field Contents.

  • Page 66: Draft

    Using Web-based Management Draft Here you can review and send out SMS messages drafts that have been previously saved. To send a particular SMS draft message, check only the message of interest without checking others. Click An additional configuration item Edit SMS will appear on top of the configuration item Draft.

  • Page 67: Setting

    Using Web-based Management contents as a draft for later use, click . When you are ready to send the SMS draft message, click To remove SMS draft messages from the draft list, check messages to remove. Click Setting Here you can configure settings for service center and SMS backup. Setting Enter the service center phone number in the field Service Center Address and click...

  • Page 68: Backup

    Using Web-based Management Backup To backup SMS messages to your local computer, click in the field Backup SMS to client. Choose Save File, click OK, and follow directions on the screen to save SMS messages on your local computer as a packed ZIP file. To recover SMS messages from your local computer, click Browse in the field Recover SMS from client and select the ZIP file that you have saved previously, and then click...

  • Page 69: Help

    Using Web-based Management Help Click the appropriate download link to download the latest Quick Start Guide or User Manual of this product. Logout Exits the web configuration interface and re-directs to login prompt. Note: After a period of inactivity, automatic logout will occur. After clicking any menu item, the login prompt will appear as re-login is needed to continue using the web configuration interface.

  • Page 70: Appendix A: Faq

    Appendix A: FAQ Appendix A: FAQ Q: What should I know and how long does it take when I upgrade the firmware of router or modem? A: 1. While upgrading the firmware requires some time to finish. During that, MUST NOT turn off the power or interrupt the progress.
  • Page 71 Appendix A: FAQ If you use Local Area Connection to connect the Router, click Network Connections and right click on Local Area Connection, click Repair. Vista/7: 1. If you are a WiFi user, please click Network and Sharing Center > Manage network connections >...
  • Page 72 Appendix A: FAQ 2. Please click Reset the network adapter “Wireless Network Connection” and it will began to repair. 3. If you use Local Area Connection to connect the Router, please click Network and Sharing Center > Manage network connections > Local Area Connection >...
  • Page 73 Appendix A: FAQ Q: How can I have a long-time link? A: Click the menu tabs Network  Router  Router Setting. Under “DHCP Service”, set Client Lease Time to a large value (e.g. 120h = 120 hours = 5 days).
  • Page 74 Appendix A: FAQ 2. Click the menu tabs Network  Wi-Fi to access the Wi-Fi submenu, and then click the submenu tab of the currently used ESSID. Then select a different WiFi Channel under “Device Configuration.” Q: I have connected the computer with the router via LAN connection. Why can’t I access the router’s IP address “http://192.168.1.1”...
  • Page 75 Appendix A: FAQ each other. Q: How do I configure the settings when I use xDSL to link the router? A: 1. PPPoE: Go to the GUI Internet > Basic Setting > Ethernet Setting. Change Connection Type to PPPoE. Enter the Username and Password provided by your ISP.
  • Page 76 Appendix A: FAQ Q: Where can I change the password of the router? A: Click the menu tabs System  Administration . Enter the new password twice (set and confirm) and click Q: Can I backup and restore all my settings of the router? A: Yes.

  • Page 77: Appendix B: Specifications

    Appendix B: Specifications Appendix B: Specifications Note: Specifications are subject to change without notice. Physical WLAN 802.11 b/g/n (2x2 MIMO) Embedded, LTE Cellular modem FDD&TDD/DC-HSPA+/HSPA+/HSPA/WCDMA/EDGE/GPRS/GSM Dimensions 143.6 x 73.3 x 143 (LxWxH, mm) Weight (g) Interface Power On/Off Switch RJ45 Ports Four LAN ports, each with LED indicator.
  • Page 78 Appendix B: Specifications diversity antenna Cellular external main antenna port Cellular external diversity antenna port WiFi antenna Embedded Router Features Routing Static Routing, Dynamic Routing (RIP) Multiple VPN pass-through (IPSec, PPTP, L2TP), Internet Access Security Policy (Parental control), Stateless and SPI Firewall Single Port Forwarding, Port Range Forwarding, Port Range NAT-NAPT Triggering, Port Filtering, DMZ, UPnP, Multicast Pass-Through...
  • Page 79 Appendix B: Specifications Auto Channel Yes, for channel 1 through 11 Select (ACS) WPS software button, SSID broadcast disable, Guest Network Other features (Dual SSID), Access control (MAC filter), WLAN on/off software switch. Status Indication 1x 3-color Network Status 1x Power (also multiplexed with signal strength) 1x WiFi (also multiplexed with signal strength) LED Display 1x WPS (also multiplexed with signal strength)
  • Page 80 Appendix B: Specifications Operation C to 45 C (32 F to 113 Temperature Storage C to 60 C (-4 F to 140 Temperature Operating 10% to 80% Non-Condensing Humidity Storage 5% to 90% Non-Condensing Humidity Certification RoHS...

  • Page 81: Appendix C: Important Safety Information And Glossary

    Appendix C: Important Safety Information and Glossary Appendix C: Important Safety Information and Glossary Europe – EU Declaration of Conformity European Union Notice Products with CE marking comply with the R&TTE Directive (99/5/EC), the EMC Directive (2004/108/EC), and the Low Voltage Directive (2006/95/EC) issued by the Commission of the European Community.

  • Page 82: Federal Communication Commission Interference Statement

    Appendix C: Important Safety Information and Glossary ETSI EN 301 489-17 Electromagnetic compatibility and Radio spectrum Matters (ERM); Electromagnetic Compatibility (EMC) standard for radio equipment and services; Part 17: Specific conditions for 2.4 GHz wideband transmission systems. ETSI EN 301 908-1 & -2 Electromagnetic compatibility and Radio spectrum Matters (ERM);...
  • Page 83 Appendix C: Important Safety Information and Glossary 2) This device must accept any interference received, including interference that may cause undesired operation of the device. FCC RF Radiation Exposure Statement: For body worn operation, this device has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the device a minimum of 20 cm from the body.

  • Page 84: Glossary

    Appendix C: Important Safety Information and Glossary Glossary 2G: Second-generation mobile networking technology. Represents a switchover from analog to digital; most 2G networks use GSM. 3G: Third-generation mobile networking technology that enables simultaneous transfer of voice and non-voice data; most 3G networks use WCDMA. 3.5G: A more recent standard of mobile networking technology;...
  • Page 85 Appendix C: Important Safety Information and Glossary Kbps (Kilobits per second): A data flow measure; 1024 bits/second. LAN (Local Area Network): A data network with limited range but good bandwidth. Mbps (Megabits per second): A data flow measure; 1,048,576 bits/second. LTE (Long Term Evolution): High-speed mobile communication standard based on the GSM/EDGE and UMTS/HSPA network technologies.
