ZyXEL Communications Prestige 660-H User Manual

Your ZyXEL Prestige 660-H 4-Port Broadband Router
Your Starter Pack Contents:
1 x ZyXEL Prestige 660-H 4-Port Broadband Router
1 x Ethernet cable (red)
1 x Telephone cable (black)
1 x Power supply
2 x Microfilters (bagged)
1x Instruction CD
1x Quick Start Guide
Important
You need to ensure that all the devices connected to your phone line are filtered in order
for ADSL to work correctly. If you are unsure how the microfilters that we have provided
should be configured then read our Guide To Fitting Microfilters, in the support section of
our website.
1
Fit a microfilter in-between the wall socket and each device that shares the
telephone line. This applies not just to telephones but can also include fax
machines, burglar alarms, and any digital satellite equipment. You should have
received two microfilters with your router.
2
Plug the power supply into the back of your router (the socket marked Power), then
plug the other end of the power supply into the nearest mains socket.
Plug one end of the black telephone cable into the DSL socket on the back of the
3
router and plug the other end into the microfilter (attached to your phone line in
step 1). The microfilter socket is also marked DSL.
4
Press the Power button on the back of the router to switch it on. The PWR/SYS
light on the front will flash and then turn green.
Wait until the DSL/PPP light stops flashing green and turns orange. This may
5
take a minute or more. Once the light is orange, your Prestige 660 router has
been successfully set-up.
Plug the Ethernet cable (red) into your computer's network socket, plug the
6
other end of the cable into any of the router's four available network sockets.

Troubleshooting

If the DSL light continues to flash for more than a mi n ute, check your
telephone cable and microfilters, only use the cables provided with your
router. Ensure no other broadband equipment is installed on your computer.
For more help, view the included Quick Start Guide, or the detailed manual
included on the CD.
Instructions continue on other side
Item Code: 037837
