Prestige 652 Series

ADSL Security/Wireless LAN Router

User's Guide

Version 3.40

August 2003

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the Prestige 652 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ZyXEL Communications Prestige 652 Series

Page 1 Prestige 652 Series ADSL Security/Wireless LAN Router User's Guide Version 3.40 August 2003...
Page 2: Copyright
Trademarks ZyNOS (ZyXEL Network Operating System) is a registered trademark of ZyXEL Communications, Inc. Other trademarks mentioned in this publication are used for identification purposes only and may be properties of their respective owners.
Page 3: Federal Communications Commission
Prestige 652 Series User’s Guide Federal Communications Commission (FCC) Interference Statement This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operations.
Page 4: Zyxel Limited Warranty
Prestige 652 Series User’s Guide ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two years from the date of purchase. During the warranty period, and...
Page 5: Customer Support
Prestige 652 Series User’s Guide Customer Support Please have the following information ready when you contact customer support. • Product model and serial number. • Warranty Information. • Date that you received your device. • Brief description of the problem and the steps you took to solve it.
Page 6: Table Of Contents
Preface ................................ xxxv What is DSL?............................xxxvii Getting Started ..............................I Chapter 1 Getting To Know Your Prestige.....................1-1 Introducing the Prestige 652 Series ...................1-1 Features of the Prestige......................1-1 Applications for the Prestige......................1-6 Chapter 2 Introducing the Web Configurator....................2-1 Web Configurator Overview......................2-1 Accessing the Prestige Web Configurator .................2-1...
Page 7 Prestige 652 Series User’s Guide IP Address and Subnet Mask .....................3-4 IP Address Assignment ......................3-4 Nailed-Up Connection (PPP) .....................3-6 NAT ............................3-6 3.10 Wizard Setup Configuration: Second Screen ................3-6 3.11 DHCP Setup..........................3-11 3.12 Wizard Setup Configuration: Third Screen................3-12 3.13 Wizard Setup Configuration: Connection Tests...............3-14 3.14 Test Your Internet Connection ....................3-15...
Page 8 Prestige 652 Series User’s Guide Configuring 802.1x ........................6-10 Configuring Local User Authentication...................6-12 6.10 Configuring RADIUS ......................6-14 Chapter 7 WAN Setup............................7-1 WAN Overview .........................7-1 Metric............................7-1 PPPoE Encapsulation.........................7-1 Traffic Shaping ..........................7-2 Configuring WAN Setup ......................7-3 WAN Backup..........................7-7 Traffic Redirect..........................7-7 Configuring WAN Backup ......................7-9 Configuring Advanced WAN Backup ..................7-11...
Page 9 Prestige 652 Series User’s Guide Dynamic DNS ..........................9-1 Configuring Dynamic DNS......................9-1 Chapter 10 Time Zone..........................10-1 10.1 Configuring Time Zone......................10-1 Firewall and Content Filters..........................IV Chapter 11 Firewalls ............................11-1 11.1 Firewall Overview........................11-1 11.2 Types of Firewalls........................11-1 11.3 Introduction to ZyXEL’s Firewall....................11-2 11.4 Denial of Service........................11-3 11.5 Stateful Inspection........................11-7...
Page 10 Prestige 652 Series User’s Guide 14.1 Introduction to Customized Services ..................14-1 14.2 Creating/Editing A Customized Service ..................14-2 14.3 Example Custom Service Firewall Rule ..................14-3 Chapter 15 Content Filtering Screens ......................15-1 15.1 Content Filtering Overview .....................15-1 15.2 Configuring Keyword Blocking....................15-1 15.3 Configuring the Schedule ......................15-3 15.4 Configuring Trusted Computers ....................15-4...
Page 11 Prestige 652 Series User’s Guide 17.13 Configuring Manual Key .......................17-19 17.14 Viewing SA Monitor......................17-22 17.15 Configuring Global Setting ....................17-24 17.16 Telecommuter VPN/IPSec Examples ..................17-25 17.17 VPN and Remote Management....................17-27 Remote Management, UPnP and Logs......................VI Chapter 18 Remote Management Configuration..................18-1 18.1 Remote Management Overview....................18-1 18.2 Telnet ............................18-2...
Page 12 Prestige 652 Series User’s Guide 21.4 Bandwidth Management Usage Examples................21-2 21.5 Scheduler ..........................21-4 21.6 Maximize Bandwidth Usage....................21-4 21.7 Bandwidth Borrowing......................21-7 21.8 Configuring Summary ......................21-9 21.9 Configuring Class Setup ......................21-11 21.10 Configuring Monitor......................21-18 Maintenance..............................VIII Chapter 22 Maintenance ..........................22-1 22.1 Maintenance Overview ......................22-1 22.2 System Status Screen .......................22-1...
Page 13 Prestige 652 Series User’s Guide 25.4 Configuring Dial Backup Setup ....................25-4 25.5 Advanced Dial Backup Setup ....................25-6 25.6 Remote Node Profile (Backup ISP) ..................25-8 25.7 Editing PPP Options.......................25-10 25.8 Editing TCP/IP Options ......................25-11 25.9 Editing Login Script.......................25-13 25.10 Remote Node Filter ........................25-14 Chapter 26 Menu 3 LAN Setup ........................26-1...
Page 14 Prestige 652 Series User’s Guide 29.5 Editing ATM Layer Options ....................29-9 Chapter 30 Static Route Setup ........................30-1 30.1 IP Static Route Overview......................30-1 30.2 Configuration ...........................30-2 Chapter 31 Bridging Setup ..........................31-1 31.1 Bridging in General........................31-1 31.2 Bridge Ethernet Setup ......................31-1 Chapter 32 Network Address Translation (NAT)..................32-1 32.1 Using NAT..........................32-1...
Page 15 Prestige 652 Series User’s Guide Chapter 35 SNMP Configuration .........................35-1 35.1 About SNMP..........................35-1 35.2 Supported MIBs ........................35-2 35.3 SNMP Configuration .......................35-2 35.4 SNMP Traps..........................35-4 Chapter 36 System Security .........................36-1 36.1 System Security........................36-1 36.2 Creating User Accounts on the Prestige...................36-5 Chapter 37 System Information and Diagnosis....................37-1 37.1 System Status ...........................37-1...
Page 16 Prestige 652 Series User’s Guide Chapter 41 IP Policy Routing ........................41-1 41.1 IP Policy Routing Overview ....................41-1 41.2 Benefits of IP Policy Routing ....................41-1 41.3 Routing Policy .........................41-1 41.4 IP Routing Policy Setup......................41-2 41.5 Applying an IP Policy......................41-5 41.6 IP Policy Routing Example......................41-7 Chapter 42 Call Scheduling .........................42-1...
Page 17 Prestige 652 Series User’s Guide Appendix C Wireless LAN and IEEE 802.11 ....................C-1 Appendix D PPPoE............................D-1 Appendix E Virtual Circuit Topology ......................E-1 Appendix F Power Adaptor Specifications ....................F-1 Appendix G Example Internal SPTGEN Screens ..................G-1 Appendix H Setting up Your Computer’s IP Address ...................H-1 Appendix I Splitters and Microfilters......................
Page 18: List Of Figures
Prestige 652 Series User’s Guide List of Figures Figure 1-1 Prestige Internet Access Application.....................1-7 Figure 1-2 Firewall Application........................1-8 Figure 1-3 VPN Application ...........................1-9 Figure 1-4 Prestige LAN-to-LAN Application .....................1-10 Figure 2-1 Password Screen ...........................2-2 Figure 2-2 Web Configurator SITE MAP Screen ...................2-3 Figure 2-3 Example Xmodem Upload......................2-4...
Page 19 Prestige 652 Series User’s Guide Figure 6-8 RADIUS ............................. 6-14 Figure 7-1 Example of Traffic Shaping......................7-3 Figure 7-2 WAN Setup........................... 7-4 Figure 7-3 Traffic Redirect Setup Example ....................7-8 Figure 7-4 Traffic Redirect LAN Setup ......................7-8 Figure 7-5 WAN Backup..........................7-9 Figure 7-6 Advanced WAN Backup......................
Page 20 Prestige 652 Series User’s Guide Figure 13-4 Creating/Editing A Firewall Rule....................13-10 Figure 13-5 Adding/Editing Source and Destination Addresses..............13-12 Figure 13-6 Timeout ...........................13-13 Figure 14-1 Customized Services .........................14-1 Figure 14-2 Creating/Editing A Customized Service..................14-2 Figure 14-3 Configure Source IP Example ....................14-4 Figure 14-4 Customized Service for MyService Example................14-4...
Page 21 Prestige 652 Series User’s Guide Figure 18-2 Remote Management........................ 18-3 Figure 19-1 Configuring UPnP ........................19-2 Figure 20-1 Log Settings..........................20-2 Figure 20-2 View Logs..........................20-4 Figure 20-3 E-mail Log Example ........................ 20-6 Figure 21-1 Application-based Bandwidth Management Example.............. 21-2 Figure 21-2 Subnet-based Bandwidth Management Example ..............
Page 22 Prestige 652 Series User’s Guide Figure 23-2 Prestige 652HW-31 SMT Menu Overview ................23-3 Figure 23-3 SMT Main Menu........................23-5 Figure 23-4 Menu 23 System Password .......................23-6 Figure 24-1 Menu 1 General Setup.......................24-2 Figure 24-2 Menu 1.1 Configure Dynamic DNS..................24-3 Figure 25-1 Menu 2 WAN Backup Setup .....................25-2 Figure 25-2 Menu 2.1Traffic Redirect Setup ....................25-3...
Page 23 Prestige 652 Series User’s Guide Figure 29-1 Menu 11 Remote Node Setup....................29-2 Figure 29-2 Menu 11.1 Remote Node Profile ....................29-3 Figure 29-3 Menu 11.3 Remote Node Network Layer Options ..............29-6 Figure 29-4 Sample IP Addresses for a TCP/IP LAN-to-LAN Connection ..........29-8 Figure 29-5 Menu 11.5 Remote Node Filter (RFC 1483 or ENET Encapsulation) ........
Page 24 Prestige 652 Series User’s Guide Figure 32-11 NAT Example 1 ........................32-12 Figure 32-12 Menu 4 Internet Access & NAT Example ................32-12 Figure 32-13 NAT Example 2........................32-13 Figure 32-14 Menu 15.2.1 Specifying an Inside Server ................32-13 Figure 32-15 NAT Example 3........................32-14 Figure 32-16 Example 3: Menu 11.3 ......................32-15...
Page 25 Prestige 652 Series User’s Guide Figure 34-16 Menu 21.1.6.1 Sample Filter Rules Summary..............34-18 Figure 34-17 Filtering Ethernet Traffic ...................... 34-19 Figure 34-18 Filtering Remote Node Traffic ..................... 34-20 Figure 35-1 SNMP Management Model ...................... 35-1 Figure 35-2 Menu 22 SNMP Configuration....................35-3 Figure 36-1 Menu 23 System Security......................
Page 26 Prestige 652 Series User’s Guide Figure 38-6 Successful Backup Confirmation Screen ..................38-7 Figure 38-7 Telnet into Menu 24.6 .......................38-8 Figure 38-8 Restore Using FTP Session Example ..................38-9 Figure 38-9 System Maintenance : Restore Configuration................38-9 Figure 38-10 System Maintenance : Starting Xmodem Download Screen...........38-9 Figure 38-11 Restore Configuration Example ....................38-10...
Page 27 Prestige 652 Series User’s Guide Figure 41-7 IP Routing Policy Example ...................... 41-8 Figure 41-8 IP Routing Policy Example ...................... 41-9 Figure 41-9 Applying IP Policies Example ....................41-9 Figure 42-1 Menu 26 Schedule Setup ......................42-1 Figure 42-2 Menu 26.1 Schedule Set Setup....................42-2 Figure 42-3 Applying Schedule Set(s) to a Remote Node (PPPoE).............
Page 28 Prestige 652 Series User’s Guide List of Tables Table 3-1 Wizard Screen 1..........................3-3 Table 3-2 Internet Connection with PPPoE ....................3-7 Table 3-3 Internet Connection with RFC 1483 ....................3-8 Table 3-4 Internet Connection with ENET ENCAP ..................3-9 Table 3-5 Internet Connection with PPPoA....................3-11 Table 3-6 Wizard : LAN Configuration ......................3-13...
Page 29 Prestige 652 Series User’s Guide Table 10-1 Time/Date........................... 10-2 Table 11-1 Common IP Ports ........................11-4 Table 11-2 ICMP Commands That Trigger Alerts..................11-6 Table 11-3 Legal NetBIOS Commands......................11-7 Table 11-4 Legal SMTP Commands ......................11-7 Table 12-1 Attack Alert ..........................12-4 Table 13-1 Firewall Rules Summary: First Screen..................13-5 Table 13-2 Predefined Services........................
Page 30 Prestige 652 Series User’s Guide Table 17-11 Global Setting .........................17-24 Table 17-12 Telecommuter and Headquarters Configuration Example ............17-25 Table 18-1 Remote Management ........................18-3 Table 19-1 Configuring UPnP ........................19-2 Table 20-1 Log Settings..........................20-3 Table 20-2 View Logs...........................20-4 Table 20-3 SMTP Error Messages ........................20-5 Table 21-1 Application and Subnet-based Bandwidth Management Example ..........21-3...
Page 31 Prestige 652 Series User’s Guide Table 25-2 Menu 2.1Traffic Redirect Setup....................25-4 Table 25-3 Menu 2.2 Dial Backup Setup ..................... 25-5 Table 25-4 Menu 2.2.1 Advanced Dial Backup Setup: AT Commands Fields ..........25-6 Table 25-5 Menu 2.2.1 Advanced Dial Backup Setup: Call Control Parameters......... 25-7 Table 25-6 Menu 11.1 Remote Node Profile (Backup ISP) .................
Page 32 Prestige 652 Series User’s Guide Table 34-5 Filter Sets Table ........................34-19 Table 35-1 Menu 22 SNMP Configuration ....................35-3 Table 35-2 SNMP Traps..........................35-4 Table 35-3 Ports and Permanent Virtual Circuits..................35-4 Table 36-1 Menu 23.2 System Security : RADIUS Server................36-2 Table 36-2 Menu 23.4 System Security : IEEE802.1x .................36-4 Table 36-3 Menu 14.1 Edit Dial-in User.......................36-6...
Page 33 Prestige 652 Series User’s Guide List of Charts Chart A-1 Troubleshooting the Start-Up of Your Prestige ................A-1 Chart A-2 Troubleshooting the LAN LED.....................A-1 Chart A-3 Troubleshooting the DSL LED......................A-2 Chart A-4 Troubleshooting the LAN Interface....................A-2 Chart A-5 Troubleshooting the WAN Interface....................A-3 Chart A-6 Troubleshooting Internet Access ....................A-3...
Page 34 Prestige 652 Series User’s Guide Chart J-4 Attack Logs ............................. J-3 Chart J-5 Access Logs ............................ J-4 Chart J-6 TCP Reset Logs..........................J-5 Chart J-7 ICMP Notes............................. J-5 Chart J-8 Sample IKE Key Exchange Logs....................J-8 Chart J-9 Sample IPSec Logs During Packet Transmission ................. J-10 Chart J-10 RFC-2408 ISAKMP Payload Types....................
Page 35: Preface
Help us help you! E-mail all User Guide-related comments, questions or suggestions for improvement to techwriters@zyxel.com.tw or send regular mail to The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 300, Taiwan. Thank you!
Page 36 For brevity’s sake, we will use “e.g.,” as a shorthand for “for instance”, and “i.e.,” for “that is” or “in other words” throughout this manual. • The Prestige 652 series may be referred to as the Prestige in this user’s guide. This refers to both models (ADSL over POTS and ADSL over ISDN) unless specifically identified. •...
Page 37: What Is Dsl
Prestige 652 Series User’s Guide What is DSL? DSL (Digital Subscriber Line) technology enhances the data capacity of the existing twisted-pair wire that runs between the local telephone company switching offices and most homes and offices. While the wire itself can handle higher frequencies, the telephone switching equipment is designed to cut off signals above 4,000 Hz to filter noise off the voice line, but now everybody is searching for ways to get more bandwidth to improve access to the Web - hence DSL technologies.
Page 38: Getting Started
Getting Started Part I: Getting Started This part is structured as a step-by-step guide to help you access your Prestige. It covers key features and applications, accessing the web configurator and configuring the wizard screens for initial setup.
Page 39: Chapter 1 Getting To Know Your Prestige
Prestige 652 Series User’s Guide Chapter 1 Getting To Know Your Prestige This chapter describes the key features and applications of your Prestige Introducing the Prestige 652 Series Your Prestige integrates high-speed 10/100Mbps auto-negotiating LAN interface(s) and a high-speed ADSL port into a single package.
Page 40 Prestige 652 Series User’s Guide • Firewall The Prestige is a stateful inspection firewall with DoS (Denial of Service) protection. By default, when the firewall is activated, all incoming traffic from the WAN to the LAN is blocked unless it is initiated from the LAN.
Page 41: Dynamic Dns Support
Prestige 652 Series User’s Guide Using the standard TCP/IP protocol, the Prestige and other UPnP enabled devices can dynamically join a network, obtain an IP address and convey its capabilities to other devices on the network. • PPPoE Support (RFC2516) PPPoE (Point-to-Point Protocol over Ethernet) emulates a dial-up connection.
Page 42: Protocol Support
Prestige 652 Series User’s Guide Multiple PVC (Permanent Virtual Circuits) Support Your Prestige supports up to 8 PVC’s. ADSL Transmission Rate Standards ♦ Full-Rate (ANSI T1.413, Issue 2; G.dmt (G.992.1) with line rate support of up to 8 Mbps downstream and 832 Kbps upstream.
Page 43 Prestige 652 Series User’s Guide Traditionally, routing is based on the destination address only and the router takes the shortest path to forward a packet. IP Policy Routing (IPPR) provides a mechanism to override the default routing behavior and alter the packet forwarding based on the policy defined by the network administrator.
Page 44: Lan Port
Prestige 652 Series User’s Guide ♦ Supports OAM F4/F5 loop-back, AIS and RDI OAM cells • Other PPPoE Features ♦ PPPoE idle time out ♦ PPPoE Dial on Demand • Diagnostics Capabilities The Prestige can perform self-diagnostic tests. These tests check the integrity of the following circuitry: ♦...
Page 45: Figure 1-1 Prestige Internet Access Application
Prestige 652 Series User’s Guide Figure 1-1 Prestige Internet Access Application Internet Single User Account For a SOHO (Small Office/Home Office) environment, your Prestige offers the Single User Account (SUA) feature that allows multiple users on the LAN (Local Area Network) to access the Internet concurrently for the cost of a single IP address.
Page 46: Figure 1-2 Firewall Application
Prestige 652 Series User’s Guide Figure 1-2 Firewall Application 1.3.3 VPN Application The Prestige’s VPN feature makes it an ideal cost-effective way to connect branch offices and business partners over the Internet without the need (and expense) for leased lines between sites. VPN ensures the privacy and integrity of your data transmissions.
Page 47: Figure 1-3 Vpn Application
Prestige 652 Series User’s Guide Figure 1-3 VPN Application 1.3.4 LAN to LAN Application You can use the Prestige to connect two geogr ly dispersed networks over the ADSL line. A typical aphical LAN-to-LAN application for your Prestige is shown as follows.
Page 48: Figure 1-4 Prestige Lan-To-Lan Application
Prestige 652 Series User’s Guide Figure 1-4 Prestige LAN-to-LAN Application 1-10 Getting To Know Your Prestige...
Page 49: Chapter 2 Introducing The Web Configurator
Prestige 652 Series User’s Guide Chapter 2 Introducing the Web Configurator This chapter describes how to access and navigate the web configurator. Web Configurator Overview The embedded web configurator allows you to manage the Prestige from anywhere through a browser such as Microsoft Internet Explorer or Netscape Navigator.
Page 50: Navigating The Prestige Web Configurator
Prestige 652 Series User’s Guide Figure 2-1 Password Screen Step 6. You should now see the SITE MAP screen. The Prestige automatically times out after five minutes of inactivity. Simply log back into the Prestige if this happens to you.
Page 51: Resetting The Prestige
Prestige 652 Series User’s Guide Wizard Setup Navigation panel Logout Figure 2-2 Web Configurator SITE MAP Screen Click the icon (located in the top right corner of most screens) to view embedded help. Resetting the Prestige If you forget your password or cannot access the SMT menu, you will need to reload the factory-default configuration file or use the RESET button the back of the Prestige.
Page 52: Figure 2-3 Example Xmodem Upload
Prestige 652 Series User’s Guide 2.4.2 Uploading a Configuration File Via Console Port Download the default configuration file from the ZyXEL FTP site, unzip it and save it in a folder. Step 1. Turn off the Prestige, begin a terminal emulation software session and turn on the Prestige again.
Page 53: Chapter 3 Wizard Setup
Prestige 652 Series User’s Guide Chapter 3 Wizard Setup This chapter provides information on the Wizard Setup screens in the web configurator. Wizard Setup Introduction Use the Wizard Setup screens to configure your system for Internet access settings and fill in the fields with the information in the Internet Account Information table of the Compact Guide or Read Me First.
Page 54: Multiplexing
Prestige 652 Series User’s Guide 3.2.4 RFC 1483 RFC 1483 describes two methods for Multiprotocol Encapsulation over ATM Adaptation Layer 5 (AAL5). The first method allows multiplexing of multiple protocols over a single ATM virtual circuit (LLC-based multiplexing) and the second method assumes that each protocol is carried over a separate ATM virtual circuit (VC-based multiplexing).
Page 55 Prestige 652 Series User’s Guide Figure 3-1 Wizard Screen 1 The following table describes the fields in this screen. Table 3-1 Wizard Screen 1 LABEL DESCRIPTION Mode From the Mode drop-down list box, select Routing (default) if your ISP allows multiple computers to share an Internet account.
Page 56: Ip Address And Subnet Mask
Prestige 652 Series User’s Guide Table 3-1 Wizard Screen 1 LABEL DESCRIPTION Next Click this button to go to the next wizard screen. The next wizard screen you see depends on what protocol you chose above. Click on the protocol link to see the next wizard screen for that protocol.
Page 57: Ip Assignment With Pppoa Or Pppoe Encapsulation
Prestige 652 Series User’s Guide 3.7.1 IP Assignment with PPPoA or PPPoE Encapsulation If you have a dynamic IP, then the IP Address and ENET ENCAP Gateway fields are not applicable (N/A). If you have a static IP, then you only need to fill in the IP Address field and not the ENET ENCAP Gateway field.
Page 58: Nailed-Up Connection (Ppp)
Prestige 652 Series User’s Guide Nailed-Up Connection (PPP) A nailed-up connection is a dial-up line where the connection is always up regardless of traffic demand. The Prestige does two things when you specify a nailed-up connection. The first is that idle timeout is disabled.
Page 59: Table 3-2 Internet Connection With Pppoe
Prestige 652 Series User’s Guide The following table describes the fields in this screen. Table 3-2 Internet Connection with PPPoE LABEL DESCRIPTION Service Name Type the name of your PPPoE service here. User Name Enter the user name exactly as your ISP assigned. If assigned a name in the form...
Page 60: Figure 3-3 Internet Connection With Rfc 1483
Prestige 652 Series User’s Guide Figure 3-3 Internet Connection with RFC 1483 The following table describes the fields in this screen. Table 3-3 Internet Connection with RFC 1483 LABEL DESCRIPTION IP Address This field is available if you select Routing in the Mode field.
Page 61: Figure 3-4 Internet Connection With Enet Encap
Prestige 652 Series User’s Guide Figure 3-4 Internet Connection with ENET ENCAP The following table describes the fields in this screen. Table 3-4 Internet Connection with ENET ENCAP LABEL DESCRIPTION IP Address A static IP address is a fixed IP that your ISP gives you. A dynamic IP address is not fixed;...
Page 62: Figure 3-5 Internet Connection With Pppoa
Prestige 652 Series User’s Guide Table 3-4 Internet Connection with ENET ENCAP LABEL DESCRIPTION Network Address Select None, SUA Only or Full Feature from the drop-sown list box. Refer to the NAT Translation chapter for more details. Back Click Back to go back to the first wizard screen.
Page 63: Dhcp Setup
Prestige 652 Series User’s Guide Table 3-5 Internet Connection with PPPoA LABEL DESCRIPTION User Name Enter the login name that your ISP gives you. Password Enter the password associated with the user name above. This option is available if you select Routing in the Mode field.
Page 64: Ip Pool Setup
Prestige 652 Series User’s Guide 3.11.1 IP Pool Setup The Prestige is pre-configured with a pool of 32 IP addresses starting from 192.168.1.33 to 192.168.1.64 for the client machines. This leaves 31 IP addresses, 192.168.1.2 to 192.168.1.32 (excluding the Prestige itself which has a default IP of 192.168.1.1) for other server machines, for example, server for mail, FTP, telnet,...
Page 65: Figure 3-7 Wizard : Lan Configuration
Prestige 652 Series User’s Guide Figure 3-7 Wizard : LAN Configuration The following table describes the fields in this screen. Table 3-6 Wizard : LAN Configuration LABEL DESCRIPTION LAN IP Address Enter the IP address of your Prestige in dotted decimal notation, for example, 192.168.1.1 (factory default).
Page 66: Wizard Setup Configuration: Connection Tests
Prestige 652 Series User’s Guide Table 3-6 Wizard : LAN Configuration LABEL DESCRIPTION Client IP Pool Starting This field specifies the first of the contiguous addresses in the IP address pool. Address Size of Client IP Pool This field specifies the size or count of the IP address pool.
Page 67: Test Your Internet Connection
Prestige 652 Series User’s Guide 3.14 Test Your Internet Connection Launch your web browser and navigate to www.zyxel.com. Internet access is just the beginning. Refer to the rest of this User’s Guide for more detailed information on the complete range of Prestige features. If you cannot access the Internet, open the web configurator again to confirm that the Internet settings you configured in the Wizard Setup are correct.
Page 68: Password, Lan, Wireless Lan And Wan
Password, LAN, Wireless LAN and WAN Part II: Password, LAN, Wireless LAN and WAN This part covers the password, LAN (Local Area Network), wireless LAN and WAN setup.
Page 69: Chapter 4 Password Setup
Prestige 652 Series User’s Guide Chapter 4 Password Setup This chapter provides information on the Password screen. Password Overview It is highly recommended that you change the password for accessing the Prestige. Configuring Password To change your Prestige’s password (recommended), click Password. The screen appears as shown.
Page 70 Prestige 652 Series User’s Guide Table 4-1 Password LABEL DESCRIPTION Retype to Confirm Type the new password again in this field. Click Apply to save your changes back to the Prestige. Apply Cancel Click Cancel to begin configuring this screen afresh.
Page 71: Chapter 5 Lan Setup
Prestige 652 Series User’s Guide Chapter 5 LAN Setup This chapter describes how to configure LAN settings. LAN Overview A Local Area Network (LAN) is a shared communication system to which many computers are attached. A LAN is a computer network limited to the immediate area, usually the same building or floor of a building.
Page 72: Dns Server Address Assignment
Prestige 652 Series User’s Guide ISP gives you the DNS server addresses, enter them in the DNS Server fields in DHCP Setup, otherwise, leave them blank. Some ISP’s choose to pass the DNS servers using the DNS server extensions of PPP IPCP (IP Control Protocol) after the connection is up.
Page 73: Rip Setup
Prestige 652 Series User’s Guide 5.4.2 IP Address and Subnet Mask Refer to the IP Address and Subnet Mask section in the Wizard Setup chapter for this information. 5.4.3 RIP Setup RIP (Routing Information Protocol) allows a router to exchange routing information with other routers. The RIP Direction field controls the sending and receiving of RIP packets.
Page 74: Configuring Lan
Prestige 652 Series User’s Guide Configuring LAN Click LAN to open the following screen. Figure 5-2 LAN The following table describes the fields in this screen. Table 5-1 LAN LABEL DESCRIPTION DHCP LAN Setup...
Page 75 Prestige 652 Series User’s Guide Table 5-1 LAN LABEL DESCRIPTION If set to Server, your Prestige can assign IP addresses, an IP default gateway and DNS servers to Windows 95, Windows NT and other systems that support the DHCP client.
Page 76 Prestige 652 Series User’s Guide Table 5-1 LAN LABEL DESCRIPTION Cancel Click this button to reset the fields in this screen. LAN Setup...
Page 77: Chapter 6 Wireless Lan Setup
Prestige 652 Series User’s Guide Chapter 6 Wireless LAN Setup This chapter discusses how to configure Wireless LAN on the Prestige. This chapter only applies to the Prestige 652H/HW. Wireless LAN Overview This section introduces the wireless LAN and some basic configurations. Wireless LANs can be as simple as...
Page 78: Figure 6-1 Rts/Cts
Prestige 652 Series User’s Guide 6.1.4 RTS/CTS A hidden node occurs when two stations are within range of the same access point, but are not within range of each other. The following figure illustrates a hidden node. Both stations (STA) are within range of the access point (AP) or wireless gateway, but out-of-range of each other, so they cannot “hear”...
Page 79: Fragmentation Threshold
Prestige 652 Series User’s Guide Enabling the RTS Threshold causes redundant network overhead that could negatively affect the throughput performance instead of providing a remedy. 6.1.5 Fragmentation Threshold A Fragmentation Threshold is the maximum data fragment size (between 256 and 2432 bytes) that can be sent in the wireless network before the Prestige will fragment the packet into smaller data frames.
Page 80: Data Encryption With Wep
Prestige 652 Series User’s Guide Data Encryption with WEP WEP encryption scrambles the data transmitted between the wireless stations and the access points to keep network communications private. It encrypts unicast and multicast communications in a network. Both the wireless stations and the access points must use the same WEP key for data encryption and decryption.
Page 81 Prestige 652 Series User’s Guide Figure 6-3 Wireless The following table describes the fields in this screen. Table 6-1 Wireless LABEL DESCRIPTION The ESSID (Extended Service Set Identification) is a unique name to identify the Prestige in the wireless LAN. Wireless stations associating to the Prestige must have the same ESSID.
Page 82: Configuring Mac Filter
Prestige 652 Series User’s Guide Table 6-1 Wireless LABEL DESCRIPTION The RTS (Request To Send) threshold (number of bytes) for enabling RTS/CTS handshake. Data with its frame size larger than this value will perform the RTS/CTS handshake. Setting RTS/CTS this attribute to be larger than the maximum MSDU (MAC service data unit) size turns off the Threshold RTS/CTS handshake.
Page 83: Figure 6-4 Mac Address Filter
Prestige 652 Series User’s Guide To change your Prestige’s MAC filter settings, click Wireless LAN, MAC Filter to open the MAC Filter screen. The screen appears as shown. Figure 6-4 MAC Address Filter The following table describes the fields in this menu.
Page 84: Network Authentication
Prestige 652 Series User’s Guide Table 6-2 MAC Address Filter LABEL DESCRIPTION Active Select Yes from the drop down list box to enable MAC address filtering Action Define the filter action for the list of MAC addresses in the MAC address filter table.
Page 85: Types Of Radius Messages
Prestige 652 Series User’s Guide • Accounting Keeps track of the client’s network activity. RADIUS is a simple package exchange in which your Prestige acts as a message relay between the wireless station and the network RADIUS server. Types of RADIUS Messages...
Page 86: Configuring 802.1X
Prestige 652 Series User’s Guide an EAP-compatible RADIUS server, the access point helps a wireless station and a RADIUS server perform authentication. Figure 6-5 EAP Authentication The details below provide a general description of how IEEE 802.1x EAP authentication works. For an example list of EAP-MD5 authentication steps, see the IEEE 802.1x appendix.
Page 87: Table 6-3 802.1X
Prestige 652 Series User’s Guide Table 6-3 802.1x LABEL DESCRIPTION To control wireless stations access to the wired network, select a control method from the drop-down list box. Choose from No Authentication Required, Authentication Required and No Access Allowed. No Authentication Required allows all wireless stations access to the wired network Wireless Port without entering user names and passwords.
Page 88: Configuring Local User Authentication
Prestige 652 Series User’s Guide Table 6-3 802.1x LABEL DESCRIPTION This field is activated only when you select Authentication Required in the Wireless Port Control field. The authentication database contains wireless station login information. The local user database is the built-in database on the Prestige. The RADIUS is an external server.
Page 89: Figure 6-7 Local User Database
Prestige 652 Series User’s Guide Figure 6-7 Local User Database The following table describes the fields in this screen. Wireless LAN Setup 6-13...
Page 90: Configuring Radius
Prestige 652 Series User’s Guide Table 6-4 Local User Database LABEL DESCRIPTION This is the index number of a local user account. Active Select this check box to enable the user profile. User Name Enter the user name of the user profile.
Page 91: Table 6-5 Radius
Prestige 652 Series User’s Guide The following table describes the fields in this screen. Table 6-5 RADIUS LABEL DESCRIPTION Authentication Server Active Select Yes from the drop-down list box to enable user authentication through an external authentication server. Server IP Address Enter the IP address of the external authentication server in dotted decimal notation.
Page 93: Chapter 7 Wan Setup
Prestige 652 Series User’s Guide Chapter 7 WAN Setup This chapter describes how to configure WAN settings. WAN Overview A WAN (Wide Area Network) is an outside connection to another network or the Internet. See the Wizard Setup chapter for more information on the fields in the WAN screens.
Page 94: Traffic Shaping
Prestige 652 Series User’s Guide For the service provider, PPPoE offers an access and authentication method that works with existing access control systems (for example Radius). PPPoE provides a login and authentication method that the existing Microsoft Dial-Up Networking software can activate, and therefore requires no new learning or procedures for Windows users.
Page 95: Configuring Wan Setup
Prestige 652 Series User’s Guide Figure 7-1 Example of Traffic Shaping Configuring WAN Setup To change your Prestige’s WAN remote node settings, click WAN, WAN Setup. The screen differs by the encapsulation. WAN Setup...
Page 96 Prestige 652 Series User’s Guide Figure 7-2 WAN Setup The following table describes the fields in this screen. WAN Setup...
Page 97 Prestige 652 Series User’s Guide Table 7-1 WAN Setup LABEL DESCRIPTION Name Enter the name of your Internet Service Provider, e.g., MyISP. This information is for identification purposes only. Mode Select Routing (default) from the drop-down list box if your ISP allows multiple computers to share an Internet account.
Page 98 Prestige 652 Series User’s Guide Table 7-1 WAN Setup LABEL DESCRIPTION Maximum Burst Size Maximum Burst Size (MBS) refers to the maximum number of cells that can be sent at the peak rate. Type the MBS, which is less than 65535.
Page 99: Wan Backup
Prestige 652 Series User’s Guide Table 7-1 WAN Setup LABEL DESCRIPTION PPPoE + In addition to the Prestige's built-in PPPoE client, you can enable PPPoE pass through PPPoE_Client_PC to allow up to ten hosts on the LAN to use PPPoE client software on their computers to connect to the ISP via the Prestige.
Page 100: Figure 7-3 Traffic Redirect Setup Example
Prestige 652 Series User’s Guide Figure 7-3 Traffic Redirect Setup Example The following network topology allows you to avoid triangle route security issues when the backup gateway is connected to the LAN. Use IP alias to configure the LAN into two or three logical networks with the Prestige itself as the gateway for each LAN network.
Page 101: Configuring Wan Backup
Prestige 652 Series User’s Guide Configuring WAN Backup To change your Prestige’s WAN backup settings, click WAN, then WAN Backup. The screen appears as shown. Figure 7-5 WAN Backup The following table describes the fields in this screen. Table 7-2 WAN Backup...
Page 102 Prestige 652 Series User’s Guide Table 7-2 WAN Backup LABEL DESCRIPTION Backup Type Select the method that the Prestige uses to check the DSL connection. Select DSL Link to have the Prestige check the DSL connection’s physical layer. Select ICMP to have the Prestige periodically ping the IP addresses configured in the Check WAN IP Address fields.
Page 103: Configuring Advanced Wan Backup
Prestige 652 Series User’s Guide Table 7-2 WAN Backup LABEL DESCRIPTION Dial Backup Active Select this check box to turn on dial backup. Metric This field sets this route's priority among the three routes the Prestige uses (normal, traffic redirect and dial backup). Type a number (1 to 15) to set the priority of the dial backup route for data transmission.
Page 104: Figure 7-6 Advanced Wan Backup
Prestige 652 Series User’s Guide Figure 7-6 Advanced WAN Backup 7-12 WAN Setup...
Page 105: Table 7-3 Advanced Wan Backup
Prestige 652 Series User’s Guide The following table describes the fields in this screen. Advanced WAN Backup Table 7-3 LABEL DESCRIPTION Basic Login Name Type the login name assigned by your ISP. Password Type the password assigned by your ISP.
Page 106 Prestige 652 Series User’s Guide Advanced WAN Backup Table 7-3 LABEL DESCRIPTION Enable SUA Network Address Translation (NAT) allows the translation of an Internet protocol address used within one network to a different IP address known within another network. SUA (Single User Account) is a subset of NAT that supports two types of mapping: Many-to-One and Server.
Page 107: At Command Strings
Prestige 652 Series User’s Guide Advanced WAN Backup Table 7-3 LABEL DESCRIPTION Select CISCO PPP from the drop-down list box if your backup WAN device uses Encapsulation Cisco PPP encapsulation; otherwise select Standard PPP. Compression Select this check box to enable stac compression.
Page 108: Dtr Signal
Prestige 652 Series User’s Guide 7.11 DTR Signal The majority of WAN devices default to hanging up the current call when the DTR (Data Terminal Ready) signal is dropped by the DTE. When the “Drop DTR When Hang Up” check box is selected, the Prestige uses this hardware signal to force the WAN device to hang up, in addition to issuing the drop command “ATH”.
Page 109: Figure 7-7 Advanced Modem Setup
Prestige 652 Series User’s Guide Figure 7-7 Advanced Modem Setup The following table describes the fields in this screen. Table 7-4 Advanced Modem Setup LABEL DESCRIPTION AT Command Strings Dial Type the AT Command string to make a call. Example: atdt Drop Type the AT Command string to drop a call.
Page 110 Prestige 652 Series User’s Guide Table 7-4 Advanced Modem Setup LABEL DESCRIPTION AT Response Strings CLID Type the keyword that precedes the CLID (Calling Line Identification) in the AT response string. This lets the Prestige capture the CLID in the AT response string that comes from the WAN device.
Page 111: Nat, Dynamic Dns And Time Zone
NAT, Dynamic DNS and Time Zone Part III: NAT, Dynamic DNS and Time Zone This part covers NAT (Network Address Translation), dynamic DNS (Domain Name Sever) and Time Zone setup.
Page 113: Nat Overview
Prestige 652 Series User’s Guide Chapter 8 Network Address Translation (NAT) Screens This chapter discusses how to configure NAT on the Prestige. NAT Overview NAT (Network Address Translation - NAT, RFC 1631) is the translation of the IP address of a host in a packet, for example, the source address of an outgoing packet, used within one network to a different IP address known within another network.
Page 114: What Nat Does
Prestige 652 Series User’s Guide NAT never changes the IP address (either local or global) of an outside host. 8.1.2 What NAT Does In the simplest form, NAT changes the source IP address in a packet received from a subscriber (the inside local address) to another (the inside global address) before forwarding the packet to the WAN side.
Page 115: Figure 8-1 How Nat Works
Prestige 652 Series User’s Guide Figure 8-1 How NAT Works 8.1.4 NAT Application The following figure illustrates a possible NAT application, where three inside LANs (logical LANs using IP Alias) behind the Prestige can communicate with three distinct WAN networks. More examples follow at the...
Page 116: Figure 8-2 Nat Application With Ip Alias
Prestige 652 Series User’s Guide Figure 8-2 NAT Application With IP Alias 8.1.5 NAT Mapping Types NAT supports five types of IP/port mapping. They are: 1. One to One: In One-to-One mode, the Prestige maps one local IP address to one global IP address.
Page 117: Sua (Single User Account) Versus Nat
Prestige 652 Series User’s Guide 5. Server: This type allows you to specify inside servers of different services behind the NAT to be accessible to the outside world although, it is highly recommended that you use the DMZ port for these servers instead.
Page 118: Sua Server
Prestige 652 Series User’s Guide 1. Choose SUA Only if you have just one public WAN IP address for your Prestige. 2. Choose Full Feature if you have multiple public WAN IP addresses for your Prestige. SUA Server A SUA server set is a list of inside (behind NAT on the LAN) servers, for example, web or FTP, that you can make visible to the outside world even though SUA makes your whole inside network appear as a single computer to the outside world.
Page 119: Table 8-3 Services And Port Numbers
Prestige 652 Series User’s Guide Many residential broadband ISP accounts do not allow you to run any server processes (such as a Web or FTP server) from your location. Your ISP may periodically check for servers and may suspend your account if it discovers any active services at your location.
Page 120: Selecting The Nat Mode
Prestige 652 Series User’s Guide Figure 8-3 Multiple Servers Behind NAT Example Selecting the NAT Mode You must create a firewall rule in addition to setting up SUA/NAT, to allow traffic from the WAN to be forwarded through the Prestige.
Page 121: Configuring Sua Server
Prestige 652 Series User’s Guide Table 8-4 NAT Mode LABEL DESCRIPTION None Select this radio button to disable NAT. Select this radio button if you have just one public WAN IP address for your Prestige. The SUA Only Prestige uses Address Mapping Set 1 in the NAT - Edit SUA NAT Server Set screen.
Page 122: Figure 8-5 Edit Sua/Nat Server Set
Prestige 652 Series User’s Guide Figure 8-5 Edit SUA/NAT Server Set The following table describes the fields in this screen. Table 8-5 Edit SUA/NAT Server Set LABEL DESCRIPTION Start Port No. Enter a port number in this field. To forward only one port, enter the port number again in the End Port No. field.
Page 123: Configuring Address Mapping
Prestige 652 Series User’s Guide Table 8-5 Edit SUA/NAT Server Set LABEL DESCRIPTION Server IP Enter your server IP address in this field. Address Save Click Save to save your changes back to the Prestige. Cancel Click Cancel to return to the previous configuration.
Page 124: Editing An Address Mapping Rule
Prestige 652 Series User’s Guide The following table describes the fields in this screen. Table 8-6 Address Mapping Rules LABEL DESCRIPTION Local Start IP This is the starting Inside Local IP Address (ILA). Local IP addresses are N/A for Server port mapping.
Page 125: Figure 8-7 Address Mapping Rule Edit
Prestige 652 Series User’s Guide Figure 8-7 Address Mapping Rule Edit The following table describes the fields in this screen. Table 8-7 Address Mapping Rule Edit LABEL DESCRIPTION Type Choose the port mapping type from one of the following. 1. One-to-One: One-to-One mode maps one local IP address to one global IP address.
Page 126 Prestige 652 Series User’s Guide Global Start IP This is the starting global IP address (IGA). Enter 0.0.0.0 here if you have a dynamic IP address from your ISP. Global End IP This is the ending global IP address (IGA). This field is N/A for One-to-One, Many- to-One and Server mapping types.
Page 127: Chapter 9 Dynamic Dns Setup
Prestige 652 Series User’s Guide Chapter 9 Dynamic DNS Setup This chapter discusses how to configure your Prestige to use Dynamic DNS. Dynamic DNS Dynamic DNS allows you to update your current dynamic IP address with one or many dynamic DNS services so that anyone can contact you (in NetMeeting, CU-SeeMe, etc.).
Page 128: Figure 9-1 Ddns
Prestige 652 Series User’s Guide Figure 9-1 DDNS The following table describes the fields in this screen. Table 9-1 DDNS LABEL DESCRIPTION Active Select this check box to use dynamic DNS. Service Provider Select the name of your Dynamic DNS service provider.
Page 129: Chapter 10 Time Zone
Prestige 652 Series User’s Guide Chapter 10 Time Zone This screen is not available on all models. Use this screen to configure the Prestige’s time and date settings. 10.1 Configuring Time Zone To change your Prestige’s time and date, click Time Zone. The screen appears as shown. Use this screen to configure the Prestige’s time based on your local time zone.
Page 130: Table 10-1 Time/Date
Prestige 652 Series User’s Guide The following table describes the fields in this screen. Table 10-1 Time/Date LABEL DESCRIPTION Time Server Use Time Server Select the time service protocol that your time server sends when you turn on the when Bootup Prestige.
Page 131 Prestige 652 Series User’s Guide Table 10-1 Time/Date LABEL DESCRIPTION Current Time This field displays the time of your Prestige. Each time you reload this page, the Prestige synchronizes the time with the time server. New Time This field displays the last updated time from the time server.
Page 132: Firewall And Content Filters
Firewall and Content Filters Part IV: Firewall and Content Filters This part introduces firewalls in general and the Prestige firewall. It also explains customized services and logs and gives example firewall rules and an overview of content filtering.
Page 134: Chapter 11 Firewalls
Prestige 652 Series User’s Guide Chapter 11 Firewalls This chapter gives some background information on firewalls and introduces the Prestige firewall. 11.1 Firewall Overview Originally, the term firewall referred to a construction technique designed to prevent the spread of fire from one room to another.
Page 135: Stateful Inspection Firewalls
Prestige 652 Series User’s Guide Information hiding prevents the names of internal systems from being made known via DNS to outside systems, since the application gateway is the only host whose name must be made known to outside systems. Robust authentication and logging pre-authenticates application traffic before it reaches internal hosts and causes it to be logged more effectively than if it were logged with standard host logging.
Page 136: Denial Of Service
Prestige 652 Series User’s Guide Figure 11-1 Prestige Firewall Application 11.4 Denial of Service Denials of Service (DoS) attacks are aimed at devices and networks with a connection to the Internet. Their goal is not to steal information, but to disable a device or network so users no longer have access to network resources.
Page 137: Types Of Dos Attacks
Prestige 652 Series User’s Guide Table 11-1 Common IP Ports Telnet HTTP SMTP POP3 11.4.2 Types of DoS Attacks There are four types of DoS attacks: 1. Those that exploit bugs in a TCP/IP implementation. 2. Those that exploit weaknesses in the TCP/IP specification.
Page 138: Figure 11-2 Three-Way Handshake
Prestige 652 Series User’s Guide Figure 11-2 Three-Way Handshake Under normal circumstances, the application that initiates a session sends a SYN (synchronize) packet to the receiving server. The receiver sends back an ACK (acknowledgment) packet and its own SYN, and then the initiator responds with an ACK (acknowledgment).
Page 139: Figure 11-4 Smurf Attack
Prestige 652 Series User’s Guide 2-b In a LAND Attack, hackers flood SYN packets into the network with a spoofed source IP address of the targeted system. This makes it appear as if the host computer sent the packets to itself, making the system unavailable while the target system tries to respond to itself.
Page 140: Stateful Inspection
Prestige 652 Series User’s Guide Table 11-3 Legal NetBIOS Commands MESSAGE: REQUEST: POSITIVE: NEGATIVE: RETARGET: KEEPALIVE: All SMTP commands are illegal except for those displayed in the following tables. Table 11-4 Legal SMTP Commands AUTH DATA EHLO ETRN EXPN HELO...
Page 141: Stateful Inspection Process
Prestige 652 Series User’s Guide Denies all sessions originating from the WAN to the LAN. Figure 11-5 Stateful Inspection The previous figure shows the Prestige’s default firewall rules in action as well as demonstrates how stateful inspection works. User A can initiate a Telnet session from within the LAN and responses to this request are allowed.
Page 142: Stateful Inspection And The Prestige
Prestige 652 Series User’s Guide access list entry is designed to permit inbound packets of the same connection as the outbound packet just inspected. 5. The outbound packet is forwarded out through the interface. 6. Later, an inbound packet reaches the interface. This packet is part of the connection previously established with the outbound packet.
Page 143: Tcp Security
Prestige 652 Series User’s Guide 11.5.3 TCP Security The Prestige uses state information embedded in TCP packets. The first packet of any new connection has its SYN flag set and its ACK flag cleared; these are "initiation" packets. All packets that do not have this flag structure are called "subsequent"...
Page 144: Guidelines For Enhancing Security With Your Firewall
Prestige 652 Series User’s Guide work properly, this connection must be allowed to pass through even though a connection from the Internet would normally be rejected. In order to achieve this, the Prestige inspects the application-level FTP data. Specifically, it searches for outgoing "PORT"...
Page 145: Packet Filtering Vs Firewall
Prestige 652 Series User’s Guide 3. Never give out a password or any sensitive information to an unsolicited telephone call or e-mail. 4. Never e-mail sensitive information such as passwords, credit card information, etc., without encrypting the information first. 5. Never submit sensitive information via a web page unless the web site uses secure connections. You can identify a secure connection by looking for a small “key”...
Page 146: When To Use The Firewall
Prestige 652 Series User’s Guide 3. To block/allow both inbound (WAN to LAN) and outbound (LAN to WAN) traffic between the specific inside host/network "A" and outside host/network "B". If the filter blocks the traffic from A to B, it also blocks the traffic from B to A.
Page 148: Chapter 12 Firewall Configuration
Prestige 652 Series User’s Guide Chapter 12 Firewall Configuration This chapter shows you how to enable and configure the Prestige firewall. 12.1 Remote Management and the Firewall When remote management is configured to allow management (see the Remote Management chapter) and the firewall is enabled: •...
Page 149: Threshold Values
Prestige 652 Series User’s Guide 12.3 Attack Alert Attack alerts are real-time reports of DoS attacks. In the Attack Alert screen, shown later, you may choose to generate an alert whenever an attack is detected. For DoS attacks, the Prestige uses thresholds to determine when to drop sessions that do not become fully established.
Page 150: Tcp Maximum Incomplete And Blocking Time
Prestige 652 Series User’s Guide The Prestige measures both the total number of existing half-open sessions and the rate of session establishment attempts. Both TCP and UDP half-open sessions are counted in the total number and rate measurements. Measurements are made once a minute.
Page 151: Figure 12-2 Attack Alert
Prestige 652 Series User’s Guide Figure 12-2 Attack Alert The following table describes the fields in this screen. Table 12-1 Attack Alert LABEL DESCRIPTION Generate alert Select this check box to generate an alert whenever an attack is detected. when attack...
Page 152 Prestige 652 Series User’s Guide Table 12-1 Attack Alert LABEL DESCRIPTION Maximum This is the number of existing half-open sessions (default "80") that causes the Incomplete Low firewall to stop deleting half-open sessions. The Prestige continues to delete half-open requests as necessary, until the number of existing half-open sessions drops below this number.
Page 153: Chapter 13 Creating Custom Rules
Prestige 652 Series User’s Guide Chapter 13 Creating Custom Rules This chapter contains instructions for defining both Local Network and Internet rules. 13.1 Rules Overview Firewall rules are subdivided into “Local Network” and “Internet”. By default, the Prestige’s stateful packet inspection allows all communications to the Internet that originate from the local network, and blocks all traffic to the LAN that originates from the Internet.
Page 154: Security Ramifications
Prestige 652 Series User’s Guide 3. What is the direction connection: from the LAN to the Internet, or from the Internet to the LAN? 4. What IP services will be affected? 5. What computers on the LAN are to be affected (if any)? 6.
Page 155: Source Address
Prestige 652 Series User’s Guide Source Address What is the connection’s source address; is it on the LAN or WAN? Is it a single IP, a range of IPs or a subnet? Destination Address What is the connection’s destination address; is it on the LAN or WAN? Is it a single IP, a range of IPs or a subnet? 13.3 Connection Direction...
Page 156: Logs
Prestige 652 Series User’s Guide Figure 13-2 WAN to LAN Traffic 13.4 Logs A log is a detailed record that you create for packets that either match a rule, don’t match a rule or both when you are creating/editing a firewall rule (see Figure 13-4). You can also choose not to create a log for a rule in this screen.
Page 157: Figure 13-3 Firewall Rules Summary: First Screen
Prestige 652 Series User’s Guide Figure 13-3 Firewall Rules Summary: First Screen The following table describes the fields in this screen. Table 13-1 Firewall Rules Summary: First Screen LABEL DESCRIPTION The default action for Use the drop-down list box to select whether to Block (silently discard) or packets not matching Forward (allow the passage of) packets that do not match the following rules.
Page 158: Predefined Services
Prestige 652 Series User’s Guide Table 13-1 Firewall Rules Summary: First Screen LABEL DESCRIPTION This is your firewall rule number. The ordering of your rules is important as rules are applied in turn. The Move field below allows you to reorder your rules.
Page 159: Table 13-2 Predefined Services
Prestige 652 Series User’s Guide Table 13-2 Predefined Services SERVICE DESCRIPTION AIM(TCP:5190) AOL’s Internet Messenger service, used as a listening port by ICQ. BGP(TCP:179) Border Gateway Protocol. BOOTP_CLIENT(UDP:68) DHCP Client. BOOTP_SERVER(UDP:67) DHCP Server. CU-SEEME(TCP/UDP:7648, A popular videoconferencing solution from White Pines Software.
Page 160 Prestige 652 Series User’s Guide Table 13-2 Predefined Services SERVICE DESCRIPTION NNTP(TCP:119) Network News Transport Protocol is the delivery mechanism for the USENET newsgroup service. PING(ICMP:0) Packet INternet Groper is a protocol that sends out ICMP echo requests to test whether or not a remote host is reachable.
Page 161: Creating/Editing Firewall Rules
Prestige 652 Series User’s Guide Table 13-2 Predefined Services SERVICE DESCRIPTION TACACS(UDP:49) Login Host Protocol used for (Terminal Access Controller Access Control System). TELNET(TCP:23) Telnet is the login and terminal emulation protocol common on the Internet and in UNIX environments. It operates over TCP/IP networks.
Page 162: Figure 13-4 Creating/Editing A Firewall Rule
Prestige 652 Series User’s Guide Figure 13-4 Creating/Editing A Firewall Rule The following table describes the fields in this screen. Table 13-3 Creating/Editing A Firewall Rule LABEL DESCRIPTION Click SrcAdd to add a new address, SrcEdit to edit an existing one or SrcDelete Source Address to delete one.
Page 163 Prestige 652 Series User’s Guide Table 13-3 Creating/Editing A Firewall Rule LABEL DESCRIPTION Destination Click DestAdd to add a new address, DestEdit to edit an existing one or Address DestDelete to delete one. Services Select a service in the Available Services box on the left, then click >> to select.
Page 164: Timeout
Prestige 652 Series User’s Guide Figure 13-5 Adding/Editing Source and Destination Addresses The following table describes the fields in this screen. Table 13-4 Adding/Editing Source and Destination Addresses LABEL DESCRIPTION Address Type Do you want your rule to apply to packets with a particular (single) IP address, a range of IP addresses (e.g., 192.168.1.10 to 192.169.1.50), a subnet or any IP...
Page 165: Figure 13-6 Timeout
Prestige 652 Series User’s Guide 13.8.1 Factors Influencing Choices for Timeout Values The factors influencing choices for timeout values are the same as the factors influencing choices for threshold values – see section 12.3.2. Click Timeout for either Local Network or Internet.
Page 166 Prestige 652 Series User’s Guide Table 13-5 Timeout LABEL DESCRIPTION Back Click Back to return to the previous screen. Click Apply to save your customized settings and exit this screen. Apply Cancel Click Cancel to return to the previous configuration.
Page 167: Chapter 14 Customized Services
Prestige 652 Series User’s Guide Chapter 14 Customized Services This chapter covers creating, viewing and editing custom services. 14.1 Introduction to Customized Services Configure customized services and port numbers not predefined by the Prestige (see Figure 13-4). For a comprehensive list of port numbers and services, visit the IANA (Internet Assigned Number Authority) website.
Page 168: Creating/Editing A Customized Service
Prestige 652 Series User’s Guide Table 14-1 Customized Services LABEL DESCRIPTION Customized Services This is the number of your customized port. Click a rule’s number of a service to go to the Firewall Customized Services Config screen to configure or edit a customized service.
Page 169: Example Custom Service Firewall Rule
Prestige 652 Series User’s Guide Table 14-2 Creating/Editing A Customized Service LABEL DESCRIPTION Service Name Type a unique name for your custom port. Service Type Choose the IP port (TCP, UDP or TCP/UDP) that defines your customized port from the drop down list box.
Page 170: Figure 14-3 Configure Source Ip Example
Prestige 652 Series User’s Guide Figure 14-3 Configure Source IP Example Step 5. Click Edit Available Service in the Edit rule screen and then click a rule number to bring up the Firewall Customized Services Config screen. Configure as follows.
Page 171: Figure 14-5 Syslog Rule Configuration Example
Prestige 652 Series User’s Guide Step 6. Follow the procedures outlined earlier in this chapter to configure all your rules. Configure the rule configuration screen like the one below and apply it. This is the address range of the MyService computers.
Page 172: Figure 14-6 Rule Summary Example
Prestige 652 Series User’s Guide Step 7. On completing the configuration procedure for these Internet firewall rules, the Rule Summary screen should look like the following. Don’t forget to click Apply when you have finished configuring your rule(s) to save your settings back to the Prestige.
Page 173: Chapter 15 Content Filtering Screens
Prestige 652 Series User’s Guide Chapter 15 Content Filtering Screens This chapter covers how to configure content filtering. 15.1 Content Filtering Overview Internet content filtering allows you to create and enforce Internet access policies tailored to your needs. Content filtering gives you the ability to block web sites that contain key words (that you specify) in the URL.
Page 174: Figure 15-1 Content Filter: Keyword
Prestige 652 Series User’s Guide Figure 15-1 Content Filter: Keyword The following table describes the fields in this screen. Table 15-1 Content Filter: Keyword LABEL DESCRIPTION Enable Keyword Blocking Select this check box to enable this feature. Block Websites that...
Page 175: Configuring The Schedule
Prestige 652 Series User’s Guide Table 15-1 Content Filter: Keyword LABEL DESCRIPTION Add Keyword Click Add Keyword after you have typed a keyword. Repeat this procedure to add other keywords. Up to 64 keywords are allowed. When you try to access a web page containing a keyword, you will get a message telling you that the content filter is blocking this request.
Page 176: Configuring Trusted Computers
Prestige 652 Series User’s Guide Table 15-2 Content Filter: Schedule LABEL DESCRIPTION Days to Block: Select a check box to configure which days of the week (or everyday) you want the content filtering to be active. Time of Day to...
Page 177 Prestige 652 Series User’s Guide Table 15-3 Content Filter: Trusted LABEL DESCRIPTION Type the ending IP address of a specific range of users on your LAN that you want to exclude from content filtering. Leave this field blank if you want to exclude an individual computer.
Page 178: Vpn/Ipsec
VPN/IPSec Part V: VPN/IPSec This part provides information about configuring VPN/IPSec for secure communications.
Page 179: Chapter 16 Introduction To Ipsec
Prestige 652 Series User’s Guide Chapter 16 Introduction to IPSec This chapter introduces the basics of IPSec VPNs. 16.1 VPN Overview A VPN (Virtual Private Network) provides secure communications between sites without the expense of leased site-to-site lines. A secure VPN is a combination of tunneling, encryption, authentication, access control and auditing technologies/services used to transport traffic over the Internet or any insecure network that uses the TCP/IP protocol suite for communication.
Page 180: Figure 16-1 Encryption And Decryption
Prestige 652 Series User’s Guide Figure 16-1 Encryption and Decryption Data Confidentiality The IPSec sender can encrypt packets before transmitting them across a network. Data Integrity The IPSec receiver can validate packets sent by the IPSec sender to ensure that the data has not been altered during transmission.
Page 181: Ipsec Architecture
Prestige 652 Series User’s Guide Figure 16-2 VPN Application 16.2 IPSec Architecture The overall IPSec architecture is shown as follows. Introduction to IPSec 16-3...
Page 182: Figure 16-3 Ipsec Architecture
Prestige 652 Series User’s Guide Figure 16-3 IPSec Architecture 16.2.1 IPSec Algorithms The ESP (Encapsulating Security Payload) Protocol (RFC 2406) and AH (Authentication Header) protocol (RFC 2402) describe the packet formats and the default standards for packet structure (including implementation algorithms).
Page 183: Encapsulation
Prestige 652 Series User’s Guide 16.3 Encapsulation The two modes of operation for IPSec VPNs are Transport mode and Tunnel mode. Figure 16-4 Transport and Tunnel Mode IPSec Encapsulation 16.3.1 Transport Mode Transport mode is used to protect upper layer protocols and only affects the data in the IP packet. In Transport mode, the IP packet contains the security protocol (AH or ESP) located after the original IP header and options, but before any upper layer protocols contained in the packet (such as TCP and UDP).
Page 184: Table 16-1 Vpn And Nat
Prestige 652 Series User’s Guide A NAT device in between the IPSec endpoints will rewrite either the source or destination address with one of its own choosing. The VPN device at the receiving end will verify the integrity of the incoming packet by computing its own hash value, and complain that the hash value appended to the received packet doesn't match.
Page 185: Chapter 17 Vpn Screens
Prestige 652 Series User’s Guide Chapter 17 VPN Screens This chapter introduces the VPN screens. See the Logs chapter for information on viewing logs and the Reference Guide for IPSec log descriptions. 17.1 VPN/IPSec Overview Use the screens documented in this chapter to configure rules for VPN connections and manage VPN connections.
Page 186: My Ip Address
Prestige 652 Series User’s Guide Table 17-1 AH and ESP Select DES for minimal security and 3DES for maximum. Select MD5 for minimal security and SHA-1 for Select NULL to set up a tunnel without encryption. maximum security. DES (default)
Page 187: Vpn Summary Screen
Prestige 652 Series User’s Guide for telecommuters initiating a VPN tunnel to the company network. See section 17.16 for configuration examples. The Secure Gateway IP Address may be configured as 0.0.0.0 only when using IKE key management and not Manual key management.
Page 188: Figure 17-2 Vpn Summary
Prestige 652 Series User’s Guide Figure 17-2 VPN Summary The following table describes the fields in this screen. Table 17-2 VPN Summary LABEL DESCRIPTION This is the VPN policy index number. Click a number to edit VPN policies. Name This field displays the identification name for this VPN policy.
Page 189: Keep Alive
Prestige 652 Series User’s Guide Table 17-2 VPN Summary LABEL DESCRIPTION Secure Gateway This is the IP address of the remote IPSec router. This must be a fixed, public IP address for traffic going through the Internet. Back Click Back to return to the previous screen.
Page 190: Table 17-3 Local Id Type And Content Fields
Prestige 652 Series User’s Guide Table 17-3 Local ID Type and Content Fields LOCAL ID TYPE= CONTENT= Type the IP address of your computer or leave the field blank to have the Prestige automatically use its own IP address. Type a domain name (up to 31 characters) by which to identify this Prestige.
Page 191: Pre-Shared Key
Prestige 652 Series User’s Guide The two Prestiges in this example cannot complete their negotiation because Prestige B’s Local ID type is IP, but Prestige A’s Peer ID type is set to E-mail. An “ID mismatched” message displays in the IPSEC LOG.
Page 192: Figure 17-3 Vpn Ike
Prestige 652 Series User’s Guide Figure 17-3 VPN IKE 17-8 VPN Screens...
Page 193: Table 17-7 Vpn Ike
Prestige 652 Series User’s Guide The following table describes the fields in this screen. Table 17-7 VPN IKE LABEL DESCRIPTION IPSec Setup Active Select this check box to activate this VPN policy. Select either Yes or No from the drop-down list box.
Page 194 Prestige 652 Series User’s Guide Table 17-7 VPN IKE LABEL DESCRIPTION When the Local Address Type field is configured to Single, enter the IP address in the IP Address Start field again here. When the Local Address Type field is...
Page 195 Prestige 652 Series User’s Guide Table 17-7 VPN IKE LABEL DESCRIPTION When you select IP in the Local ID Type field, type the IP address of your computer or leave the field blank to have the Prestige automatically use its own IP address.
Page 196 Prestige 652 Series User’s Guide Table 17-7 VPN IKE LABEL DESCRIPTION Security Protocol Select ESP if you want to use ESP (Encapsulation Security Payload). The ESP protocol (RFC 2406) provides encryption as well as some of the services offered VPN Protocol by AH.
Page 197: Ike Phases
Prestige 652 Series User’s Guide 17.10 IKE Phases There are two phases to every IKE (Internet Key Exchange) negotiation – phase 1 (Authentication) and phase 2 (Key Exchange). A phase 1 exchange establishes an IKE SA and the second one uses that SA to negotiate SAs for IPSec.
Page 198: Negotiation Mode
Prestige 652 Series User’s Guide 17.10.1 Negotiation Mode The phase 1 Negotiation Mode you select determines how the Security Association (SA) will be established for each connection through IKE negotiations. Main Mode ensures the highest level of security when the communicating parties are negotiating authentication (phase 1).
Page 199: Figure 17-5 Vpn Ike: Advanced
Prestige 652 Series User’s Guide Figure 17-5 VPN IKE: Advanced The following table describes the fields in this screen. Table 17-8 VPN IKE: Advanced LABEL DESCRIPTION VPN - IKE Enter 1 for ICMP, 6 for TCP, 17 for UDP, etc. 0 is the default and signifies any Protocol protocol.
Page 200 Prestige 652 Series User’s Guide Table 17-8 VPN IKE: Advanced LABEL DESCRIPTION As a VPN setup is processing intensive, the system is vulnerable to Denial of Enable Replay Service (DoS) attacks The IPSec receiver can detect and reject old or duplicate packets to protect against replay attacks.
Page 201 Prestige 652 Series User’s Guide Table 17-8 VPN IKE: Advanced LABEL DESCRIPTION Select DES or 3DES from the drop-down list box. When DES is used for data communications, both sender and receiver must know the same secret key, which can be used to encrypt and decrypt the message or to Encryption Algorithm generate and verify a message authentication code.
Page 202: Manual Key Setup
Prestige 652 Series User’s Guide Table 17-8 VPN IKE: Advanced LABEL DESCRIPTION Select SHA1 or MD5 from the drop-down list box. MD5 (Message Digest 5) and Authentication SHA1 (Secure Hash Algorithm) are hash algorithms used to authenticate packet Algorithm data. The SHA1 algorithm is generally considered stronger than MD5, but is slower.
Page 203: Configuring Manual Key
Prestige 652 Series User’s Guide Current ZyXEL implementation assumes identical outgoing and incoming SPIs. 17.13 Configuring Manual Key You only configure VPN Manual Key when you select Manual in the Key Management field on the VPN IKE screen. This is the VPN Manual Key screen as shown next.
Page 204: Table 17-9 Vpn Manual Setup
Prestige 652 Series User’s Guide Table 17-9 VPN Manual Setup LABEL DESCRIPTION Active Select this check box to activate this VPN policy. Type up to 32 characters to identify this VPN policy. You may use any character, Name including spaces, but the Prestige drops trailing spaces.
Page 205 Prestige 652 Series User’s Guide Table 17-9 VPN Manual Setup LABEL DESCRIPTION Use the drop-down menu to choose Single, Range, or Subnet. Select Single with a Remote Address single IP address. Select Range for a specific range of IP addresses. Select Subnet to Type specify IP addresses on a network by their subnet mask.
Page 206: Viewing Sa Monitor
Prestige 652 Series User’s Guide Table 17-9 VPN Manual Setup LABEL DESCRIPTION Select DES, 3DES or NULL from the drop-down list box. When DES is used for data communications, both sender and receiver must know the same secret key, which can be used to encrypt and decrypt the message or to Encapsulation generate and verify a message authentication code.
Page 207: Figure 17-7 Sa Monitor
Prestige 652 Series User’s Guide When there is outbound traffic but no inbound traffic, the SA times out automatically after two minutes. A tunnel with no outbound or inbound traffic is "idle" and does not timeout until the SA lifetime period expires. See section 17.6 on keep alive to have the Prestige renegotiate an IPSec SA when the SA lifetime expires, even if there is no traffic.
Page 208: Configuring Global Setting
Prestige 652 Series User’s Guide Table 17-10 SA Monitor LABEL DESCRIPTION Refresh Click Refresh to display the current active VPN connection(s). 17.15 Configuring Global Setting To change your Prestige’s global settings, click VPN and then Global Setting. The screen appears as shown.
Page 209: Telecommuters Sharing One Vpn Rule Example
Prestige 652 Series User’s Guide 17.16 Telecommuter VPN/IPSec Examples The following examples show how multiple telecommuters can make VPN connections to a single Prestige at headquarters from remote IPSec routers that use dynamic WAN IP addresses. 17.16.1 Telecommuters Sharing One VPN Rule Example Multiple telecommuters can use one VPN rule to simultaneously access a Prestige at headquarters.
Page 210: Figure 17-9 Telecommuters Sharing One Vpn Rule Example
Prestige 652 Series User’s Guide Figure 17-9 Telecommuters Sharing One VPN Rule Example 17.16.2 Telecommuters Using Unique VPN Rules Example With aggressive negotiation mode (see section 17.10.1), the Prestige can use the ID types and contents to distinguish between VPN rules. Telecommuters can each use a separate VPN rule to simultaneously access a Prestige at headquarters.
Page 211: Vpn And Remote Management
Prestige 652 Series User’s Guide Figure 17-10 Telecommuters Using Unique VPN Rules Example 17.17 VPN and Remote Management If a VPN tunnel uses a remote management service port (Telnet, FTP, WWW SNMP, DNS or ICMP) and terminates at the Prestige’s LAN or WAN port, configure remote management to allow access for that service.
Page 212: Remote Management, Upnp And Logs
Remote Management, UPnP and Logs Part VI: Remote Management, UPnP and Logs This part contains information on how to configure the Prestige for remote management, setting up Universal Plug and Play (UPnP) and setting up and displaying logs.
Page 213: Chapter 18 Remote Management Configuration
Prestige 652 Series User’s Guide Chapter 18 Remote Management Configuration This chapter provides information on configuring remote management. 18.1 Remote Management Overview Remote management allows you to determine which services/protocols can access which Prestige interface (if any) from which computers.
Page 214: Telnet
Prestige 652 Series User’s Guide 6. There is a web remote management session running with a Telnet session. A Telnet session will be disconnected if you begin a web session; it will not begin if there already is a web session.
Page 215: Web
Prestige 652 Series User’s Guide 18.4 Web You can use the Prestige’s embedded web configurator for configuration and file management. See the online help for details. 18.5 Configuring Remote Management Click Remote Management to open the following screen. Figure 18-2 Remote Management The following table describes the fields in this screen.
Page 216 Prestige 652 Series User’s Guide Table 18-1 Remote Management LABEL DESCRIPTION Cancel Click Cancel to begin configuring this screen afresh. 18-4 Remote Management Configuration...
Page 217: Chapter 19 Universal Plug-And-Play (Upnp)
Prestige 652 Series User’s Guide Chapter 19 Universal Plug-and-Play (UPnP) This chapter introduces the UPnP feature in the web configurator. 19.1 Introducing Universal Plug and Play Universal Plug and Play (UPnP) is a distributed, open networking standard that uses TCP/IP for simple peer- to-peer network connectivity between devices.
Page 218: Upnp And Zyxel
Prestige 652 Series User’s Guide All UPnP-enabled devices may communicate freely with each other without additional configuration. Disable UPnP if this is not your intention. 19.2 UPnP and ZyXEL ZyXEL has achieved UPnP certification from the Universal Plug and Play Forum Creates UPnP™...
Page 219: Installing Upnp In Windows Example
Prestige 652 Series User’s Guide Table 19-1 Configuring UPnP LABEL DESCRIPTION Allow users to make Select this check box to allow UPnP-enabled applications to automatically configuration changes configure the Prestige so that they can communicate through the Prestige, for through UPnP...
Page 220 Prestige 652 Series User’s Guide Step 3. In the Communications window, select the Universal Plug and Play check box in the Components selection box. Step 4. Click OK to go back to the Add/Remove Programs Properties window and click Next.
Page 221: Using Upnp In Windows Xp Example
Prestige 652 Series User’s Guide Step 5. In the Networking Services window, select the Universal Plug and Play check box. Step 6. Click OK to go back to the Windows Optional Networking Component Wizard window and click Next. 19.4 Using UPnP in Windows XP Example This section shows you how to use the UPnP feature in Windows XP.
Page 222 Prestige 652 Series User’s Guide Step 3. In the Internet Connection Properties Step 4. You may edit or delete the port window, click Settings to see the port mappings or click Add to mappings there were automatically created. manually add port mappings.
Page 223 Prestige 652 Series User’s Guide Step 6. Double-click on the icon to display your current Internet connection status. Web Configurator Easy Access With UPnP, you can access the web-based configurator on the Prestige without finding out the IP address of the Prestige first.
Page 224 Prestige 652 Series User’s Guide Step 4. An icon with the description for each UPnP-enabled device displays under Local Network. Step 5. Right-click on the icon for your Prestige and select Invoke. The web configurator login screen displays. Step 6.
Page 225: Chapter 20 Logs Screens
Prestige 652 Series User’s Guide Chapter 20 Logs Screens This chapter contains information about configuring general log settings and viewing the Prestige’s logs. Refer to the appendices for example log message explanations. 20.1 Logs Overview The web configurator allows you to choose which categories of events and/or alerts to have the Prestige log and then display the logs or have the Prestige send them to an administrator (as e-mail) or to a syslog server.
Page 226: Figure 20-1 Log Settings
Prestige 652 Series User’s Guide Figure 20-1 Log Settings The following table describes the fields in this screen. 20-2 Logs Screens...
Page 227: Table 20-1 Log Settings
Prestige 652 Series User’s Guide Table 20-1 Log Settings LABEL DESCRIPTION Address Info Mail Server Enter the server name or the IP address of the mail server for the e-mail addresses specified below. If this field is left blank, logs and alert messages will not be sent via e-mail.
Page 228: Displaying The Logs
Prestige 652 Series User’s Guide Table 20-1 Log Settings LABEL DESCRIPTION Select the categories of logs that you want to record. Logs include alerts. Send Immediate Alert Select the categories of alerts for which you want the Prestige to instantly e-mail alerts to the e-mail address specified in the Send Alerts To field.
Page 229: Smtp Error Messages
Prestige 652 Series User’s Guide Table 20-2 View Logs LABEL DESCRIPTION Message This field states the reason for the log. Source This field lists the source IP address and the port number of the incoming packet. Destination This field lists the destination IP address and the port number of the incoming packet.
Page 230: Figure 20-3 E-Mail Log Example
Prestige 652 Series User’s Guide 20.4.1 Example E-mail Log An "End of Log" message displays for each mail in which a complete log has been sent. The following is an example of a log sent by e-mail. Subject: You may edit the...
Page 231: Bandwidth Management
Bandwidth Management Part VII: Bandwidth Management This part provides information on the functions and configuration of Bandwidth Management.
Page 233: Chapter 21 Bandwidth Management
Prestige 652 Series User’s Guide Chapter 21 Bandwidth Management This chapter describes the functions and configuration of bandwidth management. This chapter only applies to the Prestige P652H/HW. 21.1 Bandwidth Management Overview Bandwidth management allows you to allocate an interface’s outgoing capacity to specific types of traffic. It can also help you make sure that the Prestige forwards certain types of traffic (especially real-time applications) with minimum delay.
Page 234: Proportional Bandwidth Allocation
Prestige 652 Series User’s Guide The total of the configured bandwidth budgets for child-classes cannot exceed the configured bandwidth budget speed of the parent class. 21.3 Proportional Bandwidth Allocation Bandwidth management allows you to define how much bandwidth each class gets; however, the actual bandwidth allotted to each class decreases or increases in proportion to actual available bandwidth.
Page 235: Figure 21-2 Subnet-Based Bandwidth Management Example
Prestige 652 Series User’s Guide Figure 21-2 Subnet-based Bandwidth Management Example 21.4.3 Application and Subnet-based Bandwidth Management Example The following example uses bandwidth classes based on LAN subnets and applications (specific applications in each subnet are allotted bandwidth). Table 21-1 Application and Subnet-based Bandwidth Management Example...
Page 236: Scheduler
Prestige 652 Series User’s Guide Figure 21-3 Application and Subnet-based Bandwidth Management Example 21.5 Scheduler The scheduler divides up an interface’s bandwidth among the bandwidth classes. The Prestige has two types of scheduler: fairness-based and priority-based. 21.5.1 Priority-based Scheduler With the priority-based scheduler, the Prestige forwards traffic from bandwidth classes according to the priorities that you assign to the bandwidth classes.
Page 237: Maximize Bandwidth Usage Example
Prestige 652 Series User’s Guide and on their priority levels. When only one class requires more bandwidth, the Prestige gives extra bandwidth to that class. When multiple classes require more bandwidth, the Prestige gives the highest priority classes the available bandwidth first (as much as they require, if there is enough available bandwidth), and then to lower priority classes if there is still bandwidth available.
Page 238: Figure 21-5 Maximize Bandwidth Usage Example
Prestige 652 Series User’s Guide The following figure shows the bandwidth usage with the maximize bandwidth usage option enabled. The Prestige divides up the unbudgeted 2 Mbps among the classes that require more bandwidth. If the administration department only uses 1 Mbps of the budgeted 2 Mbps, the Prestige also divides the remaining 1 Mbps among the classes that require more bandwidth.
Page 239: Bandwidth Borrowing
Prestige 652 Series User’s Guide 21.7 Bandwidth Borrowing Bandwidth borrowing allows a child-class to borrow unused bandwidth from its parent class, whereas maximize bandwidth usage allows bandwidth classes to borrow any unused or unbudgeted bandwidth on the whole interface. Enable bandwidth borrowing on a child-class to allow the child-class to use its parent class’s unused bandwidth.
Page 240: Figure 21-6 Bandwidth Borrowing Example
Prestige 652 Series User’s Guide Figure 21-6 Bandwidth Borrowing Example The Bill class can borrow unused bandwidth from the Sales USA class because the Bill class has bandwidth borrowing enabled. The Bill class can also borrow unused bandwidth from the Sales class because the Sales USA class also has bandwidth borrowing enabled.
Page 241: Maximize Bandwidth Usage With Bandwidth Borrowing
Prestige 652 Series User’s Guide The Bill class cannot borrow unused bandwidth from the Root class because the Sales class has bandwidth borrowing disabled. The Amy class cannot borrow unused bandwidth from the Sales USA class because the Amy class has bandwidth borrowing disabled.
Page 242: Figure 21-7 Bandwidth Manager: Summary
Prestige 652 Series User’s Guide Figure 21-7 Bandwidth Manager: Summary The following table describes the labels in this screen. Table 21-2 Bandwidth Manager: Summary LABEL DESCRIPTION These read-only labels represent the physical interfaces. WLAN Active Select an interface’s check box to enable bandwidth management on that interface.
Page 243: Configuring Class Setup
Prestige 652 Series User’s Guide Table 21-2 Bandwidth Manager: Summary LABEL DESCRIPTION Scheduler Select either Priority-Based or Fairness-Based from the drop-down menu to control the traffic flow. Select Priority-Based to give preference to bandwidth classes with higher priorities. Select Fairness-Based to treat all bandwidth classes equally. See section 21.5.
Page 244: Figure 21-8 Bandwidth Manager: Class Setup
Prestige 652 Series User’s Guide Figure 21-8 Bandwidth Manager: Class Setup The following table describes the labels in this screen. Table 21-3 Bandwidth Manager: Class Setup LABEL DESCRIPTION Interface Select an interface from the drop-down list box for which you wish to set up classes.
Page 245 Prestige 652 Series User’s Guide Table 21-3 Bandwidth Manager: Class Setup LABEL DESCRIPTION Statistics Click Statistics to display the status of the selected class. 21.9.1 Bandwidth Manager Class Configuration Configure a bandwidth management class in the Class Configuration screen. You must use the Bandwidth Manager - Summary screen to enable bandwidth management on an interface before you can configure classes for that interface.
Page 246: Figure 21-9 Bandwidth Manager: Class Configuration
Prestige 652 Series User’s Guide Figure 21-9 Bandwidth Manager: Class Configuration The following table describes the labels in this screen. Table 21-4 Bandwidth Manager: Class Configuration LABEL DESCRIPTION Class Name Use the auto-generated name or enter a descriptive name of up to 20 alphanumeric characters, including spaces.
Page 247 Prestige 652 Series User’s Guide Table 21-4 Bandwidth Manager: Class Configuration LABEL DESCRIPTION BW Budget (kbps) Specify the maximum bandwidth allowed for the class in kbps. The recommendation is a setting between 20 kbps and 20000 kbps for an individual class.
Page 248: Table 21-5 Services And Port Numbers
Prestige 652 Series User’s Guide Table 21-4 Bandwidth Manager: Class Configuration LABEL DESCRIPTION Source IP Address Enter the source IP address. A blank source IP address means any source IP address. Source Subnet Mask Enter the source subnet mask. This field is N/A if you do not specify a Source IP Address.
Page 249: Figure 21-10 Bandwidth Management Statistics
Prestige 652 Series User’s Guide 21.9.2 Bandwidth Management Statistics Use the Bandwidth Management Statistics screen to view network performance information. Click the Statistics button in the Class Setup screen to open the Statistics screen. Figure 21-10 Bandwidth Management Statistics The following table describes the labels in this screen.
Page 250: Configuring Monitor
Prestige 652 Series User’s Guide Table 21-6 Bandwidth Management Statistics LABEL DESCRIPTION Set Interval Click Set Interval to apply the new update period you entered in the Update Period field above. Stop Update Click Stop Update to stop the browser from refreshing bandwidth management statistics.
Page 251 Prestige 652 Series User’s Guide Table 21-7 Bandwidth Manager Monitor LABEL DESCRIPTION Back Click Back to go to the main BW Manager screen. Refresh Click Refresh to update the page. Bandwidth Management 21-19...
Page 252: Maintenance
Maintenance Part VIII: Maintenance This part covers the maintenance screens. VIII...
Page 253: Chapter 22 Maintenance
Prestige 652 Series User’s Guide Chapter 22 Maintenance This chapter displays system information such as ZyNOS firmware, port IP addresses and port traffic statistics. 22.1 Maintenance Overview The maintenance screens can help you view system information, upload new firmware, manage configuration and restart your Prestige.
Page 254: Figure 22-1 System Status
Prestige 652 Series User’s Guide Figure 22-1 System Status 22-2 Maintenance...
Page 255: Table 22-1 System Status
Prestige 652 Series User’s Guide The following table describes the fields in this screen. Table 22-1 System Status LABEL DESCRIPTION System Status System Name This is the name of your Prestige. It is for identification purposes. ZyNOS Firmware This is the ZyNOS firmware version and the date created. ZyNOS is ZyXEL's Version proprietary Network Operating System design.
Page 256: Figure 22-2 System Status: Show Statistics
Prestige 652 Series User’s Guide Table 22-1 System Status LABEL DESCRIPTION Show Statistics Click Show Statistics to see router performance statistics such as number of packets sent and number of packets received for each port. 22.2.1 System Statistics Click Show Statistics in the System Status screen to open the following screen. Read-only information here includes port status and packet specific statistics.
Page 257: Table 22-2 System Status: Show Statistics
Prestige 652 Series User’s Guide The following table describes the fields in this screen. Table 22-2 System Status: Show Statistics LABEL DESCRIPTION System up Time This is the elapsed time the system has been up. CPU Load This field specifies the percentage of CPU utilization.
Page 258: Dhcp Table Screen
Prestige 652 Series User’s Guide Table 22-2 System Status: Show Statistics LABEL DESCRIPTION Collisions This is the number of collisions on this port. Poll Interval(s) Type the time interval for the browser to refresh system statistics. Set Interval Click this button to apply the new poll interval you entered in the Poll Interval field above.
Page 259: Wireless Screens
Prestige 652 Series User’s Guide The following table describes the fields in this screen. Table 22-3 DHCP Table LABEL DESCRIPTION Host Name This is the name of the host computer. IP Address This field displays the IP address relative to the Host Name field.
Page 260: Table 22-4 Association List
Prestige 652 Series User’s Guide The following table describes the fields in this screen. Table 22-4 Association List LABEL DESCRIPTION This is the index number of an associated wireless client. This field displays the MAC (Media Access Control) address of an associated wireless client.
Page 261: Diagnostic Screens
Prestige 652 Series User’s Guide Figure 22-5 Channel Usage Table The following table describes the fields in this screen. Table 22-5 Channel Usage Table LABEL DESCRIPTION Channel This is the index number of the channel. Activity This field displays Yes if another AP or Ad-hoc network is using the channel within the Prestige’s transmission range.
Page 262: Figure 22-6 Diagnostic General
Prestige 652 Series User’s Guide Figure 22-6 Diagnostic General The following table describes the fields in this screen. Table 22-6 Diagnostic General LABEL DESCRIPTION TCP/IP Type the IP address of a computer that you want to ping in order to test a connection.
Page 263: Figure 22-7 Diagnostic Dsl Line
Prestige 652 Series User’s Guide 22.5.2 Diagnostic DSL Line Screen Click Diagnostic and then DSL Line to open the screen shown next. Figure 22-7 Diagnostic DSL Line The following table describes the fields in this screen. Table 22-7 Diagnostic DSL Line...
Page 264: Firmware Screen
Prestige 652 Series User’s Guide Table 22-7 Diagnostic DSL Line LABEL DESCRIPTION ATM Loopback Click this button to start the ATM loopback test. Make sure you have configured at least Test one PVC with proper VPIs/VCIs before you begin this test. The Prestige sends an OAM F5 packet to the DSLAM/ATM switch and then returns it (loops it back) to the Prestige.
Page 265: Figure 22-8 Firmware Upgrade
Prestige 652 Series User’s Guide Figure 22-8 Firmware Upgrade The following table describes the fields in this screen. Table 22-8 Firmware Upgrade LABEL DESCRIPTION File Path Type in the location of the file you want to upload in this field or click Browse ... to find it.
Page 266: Figure 22-9 Network Temporarily Disconnected
Prestige 652 Series User’s Guide Figure 22-9 Network Temporarily Disconnected After two minutes, log in again and check your new firmware version in the System Status screen. If the upload was not successful, the following screen will appear. Click Back to go back to the Firmware screen.
Page 267: Smt General Configuration
SMT General Configuration Part IX: SMT General Configuration This part covers System Management Terminal configuration for general setup, WAN backup, LAN setup, wireless LAN setup, Internet access, remote node, static route, NAT and enabling the firewall. See the web configurator parts of this guide for background information on features configurable by web configurator and SMT.
Page 269: Chapter 23 Introducing The Smt
Prestige 652 Series User’s Guide Chapter 23 Introducing the SMT This chapter explains how to access and navigate the System Management Terminal and gives an overview of its menus. 23.1 SMT Introduction The Prestige’s SMT (System Management Terminal) is a menu-driven interface that you can access from a terminal emulator through the console port or over a telnet connection.
Page 270: Figure 23-1 Login Screen
Prestige 652 Series User’s Guide Please note that if there is no activity for longer than five minutes after you log in, your Prestige will automatically log you out. Enter Password : **** Figure 23-1 Login Screen 23.1.4 Prestige SMT Menu Overview We use the Prestige 652HW-31 SMT menus in this guide as an example.
Page 271: Navigating The Smt Interface
Prestige 652 Series User’s Guide Prestige 652HW Main Menu Menu 2 Menu 3 Menu 4 Menu 12 Menu 14 Menu 1 Menu 11 Menu 15 WAN Backup Setup General Setup LAN Setup Internet Access Static Routing Setup Dial-in User Setup...
Page 272: Table 23-1 Main Menu Commands
Prestige 652 Series User’s Guide Table 23-1 Main Menu Commands OPERATION KEYSTROKE DESCRIPTION Move down to [ENTER] To move forward to a submenu, type in the number of the desired another menu submenu and press [ENTER]. Move up to a [ESC] Press [ESC] to move back to the previous menu.
Page 273: Figure 23-3 Smt Main Menu
Prestige 652 Series User’s Guide After you enter the password, the SMT displays the main menu, as shown next. Copyright (c) 1994 - 2003 ZyXEL Communications Corp. Prestige 652HW-31 Main Menu Getting Started Advanced Management 1. General Setup 21. Filter and Firewall Setup 2, WAN Backup Setup 22.
Page 274: Changing The System Password
Prestige 652 Series User’s Guide Table 23-2 Main Menu Summary MENU TITLE DESCRIPTION System Security Use this menu to set up wireless security (Prestige 652H/HW only) and change your password. System Maintenance This menu provides system status, diagnostics, software upload, etc.
Page 275: Chapter 24 Menu 1 General Setup
Prestige 652 Series User’s Guide Chapter 24 Menu 1 General Setup Menu 1 - General Setup contains administrative and system-related information. 24.1 General Setup Menu 1 — General Setup contains administrative and system-related information (shown next). The System Name field is for identification purposes. However, because some ISPs check this name you should enter your computer's "Computer Name".
Page 276: Figure 24-1 Menu 1 General Setup
Prestige 652 Series User’s Guide Menu 1 - General Setup System Name= ? Location= Contact Person's Name= Domain Name= Edit Dynamic DNS= No Route IP= Yes Bridge= No Press ENTER to Confirm or ESC to Cancel: Figure 24-1 Menu 1 General Setup Step 2.
Page 277: Figure 24-2 Menu 1.1 Configure Dynamic Dns
Prestige 652 Series User’s Guide 24.2.1 Procedure to Configure Dynamic DNS If you have a private WAN IP address, then you cannot use Dynamic DNS. Step 1. To configure Dynamic DNS, go to Menu 1 — General Setup and select Yes in the Edit Dynamic DNS field.
Page 279: Chapter 25 Menu 2 Wan Backup Setup
Prestige 652 Series User’s Guide Chapter 25 Menu 2 WAN Backup Setup This chapter describes how to configure traffic redirect and dial-backup using menu 2, 2.1, 2.2 and 2.2.1. 25.1 Introduction to WAN Backup Setup This chapter explains how to configure the Prestige for traffic redirect and dial backup connections.
Page 280: Figure 25-1 Menu 2 Wan Backup Setup
Prestige 652 Series User’s Guide Menu 2 - Wan Backup Setup Check Mechanism = DSL Link Check WAN IP Address1 = 0.0.0.0 Check WAN IP Address2 = 0.0.0.0 Check WAN IP Address3 = 0.0.0.0 KeepAlive Fail Tolerance = 0 Recovery Interval(sec) = 0...
Page 281: Figure 25-2 Menu 2.1Traffic Redirect Setup
Prestige 652 Series User’s Guide Table 25-1 Menu 2 WAN Backup Setup FIELD DESCRIPTION Recovery When the Prestige is using a lower priority connection (usually a WAN backup Interval(sec) connection), it periodically checks to whether or not it can use a higher priority connection.
Page 282: Configuring Dial Backup Setup
Prestige 652 Series User’s Guide The following table describes the fields in this menu. Table 25-2 Menu 2.1Traffic Redirect Setup FIELD DESCRIPTION Active Press [SPACE BAR] and select Yes (to enable) or No (to disable) traffic redirect setup. The default is No.
Page 283: Figure 25-3 Menu 2.2 Dial Backup Setup
Prestige 652 Series User’s Guide Menu 2.2 - Dial Backup Setup Dial-Backup: Active= No Port Speed= 115200 AT Command String: Init= at&fs0=0 Edit Advanced Setup= No Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle. Figure 25-3 Menu 2.2 Dial Backup Setup The following table describes the fields in this menu.
Page 284: Advanced Dial Backup Setup
Prestige 652 Series User’s Guide 25.5 Advanced Dial Backup Setup Consult the manual of your WAN device connected to your Dial Backup port for specific AT commands. To edit the advanced setup for the dial backup port, move the cursor to the Edit Advanced Setup field in Menu 2.2 Dial Backup Setup, press the [SPACE BAR] to select Yes and then press [ENTER].
Page 285: Table 25-5 Menu 2.2.1 Advanced Dial Backup Setup: Call Control Parameters
Prestige 652 Series User’s Guide Table 25-4 Menu 2.2.1 Advanced Dial Backup Setup: AT Commands Fields FIELD DESCRIPTION EXAMPLE Drop DTR When Hang Press the [SPACE BAR] to choose either Yes or No. When Yes is selected (the default), the DTR (Data Terminal Ready) signal is dropped after the “AT Command String: Drop”...
Page 286: Remote Node Profile (Backup Isp)
Prestige 652 Series User’s Guide 25.6 Remote Node Profile (Backup ISP) Enter 8 in Menu 11 Remote Node Setup to open Menu 11.1 Remote Node Profile (Backup ISP) (shown below) and configure the setup for your dial backup port connection.
Page 287 Prestige 652 Series User’s Guide Table 25-6 Menu 11.1 Remote Node Profile (Backup ISP) FIELD DESCRIPTION EXAMPLE Authen This field sets the authentication protocol used for outgoing calls. CHAP/PAP Options for this field are: CHAP/PAP - Your Prestige will accept either CHAP or PAP when requested by this remote node.
Page 288: Editing Ppp Options
Prestige 652 Series User’s Guide Table 25-6 Menu 11.1 Remote Node Profile (Backup ISP) FIELD DESCRIPTION EXAMPLE Nailed-Up Press [SPACE BAR] to select Yes to set this connection to always be on, regardless of whether or not there is any traffic. Select No to have...
Page 289: Editing Tcp/Ip Options
Prestige 652 Series User’s Guide Figure 25-7 Menu 11.2 Remote Node PPP Options FIELD DESCRIPTION EXAMPLE Encapsulation Press [SPACE BAR] and then [ENTER] to select CISCO PPP if Standard PPP your Dial Backup WAN device uses Cisco PPP encapsulation, (default) otherwise select Standard PPP.
Page 290 Prestige 652 Series User’s Guide Table 25-7 Menu 11.3 Remote Node Network Layer Options FIELD DESCRIPTION EXAMPLE Rem IP Leave this field set to 0.0.0.0 to have the ISP or other remote router 0.0.0.0 Subnet dynamically send its subnet mask if you do not know it. Enter the remote...
Page 291: Editing Login Script
Prestige 652 Series User’s Guide 25.9 Editing Login Script For some remote gateways, text login is required before PPP negotiation is started. The Prestige provides a script facility for this purpose. The script has six programmable sets; each set is composed of an ‘Expect’...
Page 292: Remote Node Filter
Prestige 652 Series User’s Guide Menu 11.4 - Remote Node Script Active= No Set 1: Set 5: Expect= Expect= Send= Send= Set 2: Set 6: Expect= Expect= Send= Send= Set 3: Expect= Send= Set 4: Expect= Send= Enter here to CONFIRM or ESC to CANCEL: Figure 25-9 Menu 11.4 Remote Node Setup Script...
Page 293: Figure 25-10 Menu 11.1 Remote Node Profile (Backup Isp)
Prestige 652 Series User’s Guide Menu 11.1 - Remote Node Profile (Backup ISP) Rem Node Name= ? Edit PPP Options= No Active= Yes Rem IP Addr= ? Edit IP= No Outgoing: Edit Script Options= No My Login= My Password= ********...
Page 295: Chapter 26 Menu 3 Lan Setup
Prestige 652 Series User’s Guide Chapter 26 Menu 3 LAN Setup This chapter covers how to configure your wired Local Area Network (LAN) settings. 26.1 LAN Setup This section describes how to configure the Ethernet using Menu 3 — LAN Setup. From the main menu, enter 3 to display menu 3.
Page 296: Protocol Dependent Ethernet Setup
Prestige 652 Series User’s Guide 26.2 Protocol Dependent Ethernet Setup Depending on the protocols for your applications, you need to configure the respective Ethernet Setup, as outlined below. For TCP/IP Ethernet setup refer to the Internet Access Application chapter. For bridging Ethernet setup refer to the Bridging Setup chapter.
Page 297: Table 26-1 Dhcp Ethernet Setup Menu Fields
Prestige 652 Series User’s Guide Table 26-1 DHCP Ethernet Setup Menu Fields FIELD DESCRIPTION EXAMPLE DHCP Setup DHCP If set to Server, your Prestige can assign IP addresses, an IP default gateway and DNS servers to Windows 95, Windows NT and Server other systems that support the DHCP client.
Page 298 Prestige 652 Series User’s Guide Table 26-2 TCP/IP Ethernet Setup Menu Fields FIELD DESCRIPTION EXAMPLE Multicast IGMP (Internet Group Multicast Protocol) is a network-layer protocol None used to establish membership in a Multicast group. The Prestige (default) supports both IGMP version 1 (IGMP-v1) and version 2 (IGMP-v2).
Page 299: Chapter 27 Wireless Lan Setup
Prestige 652 Series User’s Guide Chapter 27 Wireless LAN Setup This chapter covers how to configure wireless LAN settings in SMT menu 3.5. This chapter only applies to the Prestige 652H/HW. 27.1 Wireless LAN Overview Refer to the chapter on the wireless LAN screens for wireless LAN background information.
Page 300: Figure 27-1 Menu 3.5 - Wireless Lan Setup
Prestige 652 Series User’s Guide Menu 3.5- Wireless LAN Setup ESSID= Wireless Hide ESSIS = No Channel ID= CH01 2412MHz RTS Threshold= 2432 Frag. Threshold= 2432 WEP= Disable Default Key= N/A Key1= N/A Key2= N/A Key3= N/A Key4= N/A Edit MAC Address Filter= No Press ENTER to Confirm or ESC to Cancel: Figure 27-1 Menu 3.5 - Wireless LAN Setup...
Page 301: Wireless Lan Mac Address Filter
Prestige 652 Series User’s Guide Table 27-1 Menu 3.5 - Wireless LAN Setup FIELD DESCRIPTION EXAMPLE WEP (Wired Equivalent Privacy) provides data encryption to prevent wireless Disable stations from accessing data transmitted over the wireless network. Select Disable allows wireless stations to communicate with the access points without any data encryption.
Page 302: Figure 27-2 Menu 3.5.1 Wlan Mac Address Filtering
Prestige 652 Series User’s Guide Menu 3.5.1 - WLAN MAC Address Filter Active= No Filter Action= Allowed Association ------------------------------------------------------------------------------ 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00 00:00:00:00:00:00...
Page 303: Chapter 28 Internet Access
Prestige 652 Series User’s Guide Chapter 28 Internet Access This chapter shows you how to configure the LAN and WAN of your Prestige for Internet access 28.1 Internet Access Overview Refer to the chapters on the web configurator’s wizard, LAN and WAN screens for more background information on fields in the SMT screens covered in this chapter.
Page 304: Ip Alias Setup
Prestige 652 Series User’s Guide Figure 28-1 Physical Network Figure 28-2 Partitioned Logical Networks Use menu 3.2.1 to configure IP Alias on your Prestige. 28.4 IP Alias Setup Use menu 3.2 to configure the first network. Move the cursor to Edit IP Alias field and press [SPACEBAR] to choose Yes and press [ENTER] to configure the second and third network.
Page 305: Figure 28-3 Menu 3.2 Tcp/Ip And Dhcp Setup
Prestige 652 Series User’s Guide Menu 3.2 - TCP/IP and DHCP Setup DHCP Setup: DHCP= Server Client IP Pool Starting Addres= 192.168.1.33 Size of Client IP Pool= 32 Primary DNS Server= 0.0.0.0 Secondary DNS Server= 0.0.0.0 Remote DHCP Server= N/A TCP/IP Setup: IP Address= 192.168.1.1...
Page 306: Route Ip Setup
Prestige 652 Series User’s Guide Table 28-1 Menu 3.2.1 IP Alias Setup FIELD DESCRIPTION EXAMPLE IP Alias Choose Yes to configure the LAN network for the Prestige. IP Address Enter the IP address of your Prestige in dotted decimal notation 192.168.2.1...
Page 307: Internet Access Configuration
Prestige 652 Series User’s Guide 28.6 Internet Access Configuration Menu 4 allows you to enter the Internet Access information in one screen. Menu 4 is actually a simplified setup for one of the remote nodes that you can access in menu 11. Before you configure your Prestige for Internet access, you need to collect your Internet account information.
Page 308 Prestige 652 Series User’s Guide Table 28-2 Menu 4 Internet Access Setup FIELD DESCRIPTION EXAMPLE Multiplexing SPACE BAR LLC-based Press [ ] to select the method of multiplexing used by your ISP. Choices are VC-based or LLC-based. VPI # Enter the Virtual Path Identifier (VPI) assigned to you.
Page 309 Prestige 652 Series User’s Guide Table 28-2 Menu 4 Internet Access Setup FIELD DESCRIPTION EXAMPLE Network Address SPACE BAR SUA Only Press [ ] to select None, SUA Only or Full Translation Feature. Please see the NAT Chapter for more details on the SUA (Single User Account) feature.
Page 311: Chapter 29 Remote Node Configuration
Prestige 652 Series User’s Guide Chapter 29 Remote Node Configuration This chapter covers remote node configuration. 29.1 Remote Node Setup Overview This section describes the protocol-independent parameters for a remote node. A remote node is required for placing calls to a remote gateway. A remote node represents both the remote gateway and the network behind it across a WAN connection.
Page 312: Figure 29-1 Menu 11 Remote Node Setup
Prestige 652 Series User’s Guide Menu 11 - Remote Node Setup 1. My ISP (ISP, SUA) 2. ________ 3. ________ 4. ________ 5. ________ 6. ________ 7. ________ 8. ________ Enter Node # to Edit: Figure 29-1 Menu 11 Remote Node Setup 29.2.2 Encapsulation and Multiplexing Scenarios...
Page 313: Figure 29-2 Menu 11.1 Remote Node Profile
Prestige 652 Series User’s Guide Menu 11.1 - Remote Node Profile Edit IP/Bridge Options Rem Node Name= ChangeMe Route= IP in menu 11.3. Active= Yes Bridge= No Encapsulation= ENET ENCAP Edit IP/Bridge= No Multiplexing= LLC-based Edit ATM Options= No Edit ATM Options in...
Page 314 Prestige 652 Series User’s Guide Table 29-1 Menu 11.1 Remote Node Profile FIELD DESCRIPTION EXAMPLE Rem Login Type the login name that this remote node will use to call your Prestige. The login name and the Rem Password will be used to authenticate this node.
Page 315: Outgoing Authentication Protocol
Prestige 652 Series User’s Guide Table 29-1 Menu 11.1 Remote Node Profile FIELD DESCRIPTION EXAMPLE Allocated Budget This sets a ceiling for outgoing call time for this remote node. The (min) default for this field is 0 meaning no budget control.
Page 316: Remote Node Network Layer Options
Prestige 652 Series User’s Guide 29.3 Remote Node Network Layer Options For the TCP/IP parameters, perform the following steps to edit Menu 11.3 – Remote Node Network Layer Options as shown next. Step 1. In menu 11.1, make sure IP is among the protocols in the Route field.
Page 317 Prestige 652 Series User’s Guide Table 29-2 Menu 11.3 Remote Node Network Layer Options FIELD DESCRIPTION EXAMPLE My WAN Some implementations, especially UNIX derivatives, require separate IP Addr network numbers for the WAN and LAN links and each end to have a unique address within the WAN network number.
Page 318: Remote Node Filter
Prestige 652 Series User’s Guide Table 29-2 Menu 11.3 Remote Node Network Layer Options FIELD DESCRIPTION EXAMPLE When you have completed this menu, press [ENTER] at the prompt “Press ENTER to confirm or ESC to cancel” to save your configuration or press [ESC] to cancel and go back to the previous screen.
Page 319: Editing Atm Layer Options
Prestige 652 Series User’s Guide Use Menu 11.5 – Remote Node Filter to specify the filter set(s) to apply to the incoming and outgoing traffic between this remote node and the Prestige and also to prevent certain packets from triggering calls.
Page 320: Figure 29-7 Menu 11.6 For Vc-Based Multiplexing
Prestige 652 Series User’s Guide There are two versions of menu 11.6 for the Prestige, depending on whether you chose VC-based/LLC- based multiplexing and PPP encapsulation in menu 11.1. 29.5.1 VC-based Multiplexing (non-PPP Encapsulation) For VC-based multiplexing, by prior agreement, a protocol is assigned a specific virtual circuit, for example, VC1 will carry IP.
Page 321: Figure 29-9 Menu 11.1 Remote Node Profile
Prestige 652 Series User’s Guide In this case, only one set of VPI and VCI numbers need be specified for all protocols. The valid range for the VPI is 0 to 255 and for the VCI is 32 to 65535 (1 to 31 is reserved for local management of ATM traffic).
Page 322: Table 29-3 Menu 11.8 Advance Setup Options
Prestige 652 Series User’s Guide Table 29-3 Menu 11.8 Advance Setup Options FIELD DESCRIPTION PPPoE+ Press [SPACE BAR] to select Yes and press [ENTER] to enable PPPoE pass PPPoE_Client_PC through. In addition to the Prestige's built-in PPPoE client, you can enable PPPoE pass through to allow up to ten hosts on the LAN to use PPPoE client software on their computers to connect to the ISP via the Prestige.
Page 323: Chapter 30 Static Route Setup
Prestige 652 Series User’s Guide Chapter 30 Static Route Setup This chapter shows how to setup IP static routes. 30.1 IP Static Route Overview Static routes tell the Prestige routing information that it cannot learn automatically through other means. This can arise in cases where RIP is disabled on the LAN or a remote network is beyond the one that is directly connected to a remote node.
Page 324: Configuration
Prestige 652 Series User’s Guide 30.2 Configuration Step 1. To configure an IP static route, use Menu 12 – Static Route Setup (shown next). Menu 12 - Static Route Setup 1. IP Static Route 3. Bridge Static Route Please enter selection: Figure 30-2 Menu 12 Static Route Setup Step 2.
Page 325: Figure 30-4 Menu12.1.1 Edit Ip Static Route
Prestige 652 Series User’s Guide Menu 12.1.1 - Edit IP Static Route Route #: 1 Route Name= ? Active= No Destination IP Address= ? IP Subnet Mask= ? Gateway IP Address= ? Metric= 2 Private= No Press ENTER to Confirm or ESC to Cancel: Figure 30-4 Menu12.1.1 Edit IP Static Route...
Page 326 Prestige 652 Series User’s Guide Table 30-1 Menu12.1.1 Edit IP Static Route FIELD DESCRIPTION Private This parameter determines if the Prestige will include the route to this remote node in its RIP broadcasts. If set to Yes, this route is kept private and is not included in RIP broadcasts.
Page 327: Chapter 31 Bridging Setup
Prestige 652 Series User’s Guide Chapter 31 Bridging Setup This chapter shows you how to configure the bridging parameters of your Prestige. 31.1 Bridging in General Bridging bases the forwarding decision on the MAC (Media Access Control), or hardware address, while routing does it on the network layer (IP) address.
Page 328: Figure 31-1 Menu 11.1 Remote Node Profile
Prestige 652 Series User’s Guide Menu 11.1 - Remote Node Profile Rem Node Name= ? Route= IP Bridge= Yes Active= Yes Edit IP/Bridge= No Encapsulation= ENET ENCAP Multiplexing= VC-based Edit ATM Options= No Service Name= N/A Incoming: Telco Option: Rem Login= N/A...
Page 329: Figure 31-3 Menu 12.3.1 Edit Bridge Static Route
Prestige 652 Series User’s Guide Table 31-1 Remote Node Network Layer Options : Bridge Fields FIELD DESCRIPTION Bridge (menu 11.1) Make sure this field is set to Yes. Edit IP/Bridge (menu Press [SPACE BAR] to select Yes and press [ENTER] to display menu 11.3.
Page 330 Prestige 652 Series User’s Guide FIELD DESCRIPTION Active Indicates whether the static route is active (Yes) or not (No). Ether Address Type the MAC address of the destination computer that you want to bridge the packets to. IP Address If available, type the IP address of the destination computer that you want to bridge the packets to.
Page 331: Chapter 32 Network Address Translation (Nat)
Prestige 652 Series User’s Guide Chapter 32 Network Address Translation (NAT) This chapter discusses how to configure NAT on the Prestige. 32.1 Using NAT You must create a firewall rule in addition to setting up SUA/NAT, to allow traffic from the WAN to be forwarded through the Prestige.
Page 332: Figure 32-1 Menu 4 Applying Nat For Internet Access
Prestige 652 Series User’s Guide Menu 4 - Internet Access Setup ISP's Name= MyISP Encapsulation= RFC 1483 Multiplexing= LLC-based VPI #= 8 VCI #= 35 ATM QoS Type= UBR Peak Cell Rate (PCR)= 0 Sustain Cell Rate (SCR)= 0 Maximum Burst Size (MBS)= 0...
Page 333: Nat Setup
Prestige 652 Series User’s Guide Menu 11.3 - Remote Node Network Layer Options IP Options: Bridge Options: IP Address Assignment = Dynamic Ethernet Addr Timeout(min)= N/A Rem IP Addr = 0.0.0.0 Rem Subnet Mask= 0.0.0.0 My WAN Addr= N/A NAT= SUA Only...
Page 334: Figure 32-3 Menu 15 Nat Setup
Prestige 652 Series User’s Guide The server set is a list of LAN and DMZ servers mapped to external ports. To use this set, a server rule must be set up inside the NAT address mapping set. Please see the section on port forwarding in the chapter on NAT web configurator screens for further information on these menus.
Page 335: Figure 32-5 Menu 15.1.255 Sua Address Mapping Rules
Prestige 652 Series User’s Guide Menu 15.1.255 - Address Mapping Rules Set Name= Local Start IP Local End IP Global Start IP Global End IP Type --------------- --------------- --------------- --------------- ------ 0.0.0.0 255.255.255.255 0.0.0.0 0.0.0.0 Server Press ENTER to Confirm or ESC to Cancel: Figure 32-5 Menu 15.1.255 SUA Address Mapping Rules...
Page 336: Figure 32-6 Menu 15.1.1 First Set
Prestige 652 Series User’s Guide Table 32-2 SUA Address Mapping Rules FIELD DESCRIPTION EXAMPLE When you have completed this menu, press [ENTER] at the prompt “Press ENTER to confirm or ESC to cancel” to save your configuration or press [ESC] to cancel and go back to the previous screen.
Page 337: Table 32-3 Menu 15.1.1 First Set
Prestige 652 Series User’s Guide up by that number of empty rules. For example, if you have already configured rules 1 to 6 in your current set and now you configure rule number 9. In the set summary screen, the new rule will be rule 7, not 9.
Page 338: Figure 32-7 Menu 15.1.1.1 Editing/Configuring An Individual Rule In A Set
Prestige 652 Series User’s Guide Menu 15.1.1.1 Address Mapping Rule Type= One-to-One Local IP: Start= = N/A Global IP: Start= = N/A Server Mapping Set= N/A Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle. Figure 32-7 Menu 15.1.1.1 Editing/Configuring an Individual Rule in a Set The following table explains the fields in this menu.
Page 339: Configuring A Server Behind Nat
Prestige 652 Series User’s Guide Table 32-4 Menu 15.1.1.1 Editing/Configuring an Individual Rule in a Set FIELD DESCRIPTION EXAMPLE Server Only available when Type is set to Server. Type a number from 1 to 10 to Mapping Set choose a server set from menu 15.2.
Page 340: Figure 32-9 Menu 15.2.1 Nat Server Setup
Prestige 652 Series User’s Guide Menu 15.2.1 - NAT Server Setup Rule Start Port No. End Port No. IP Address --------------------------------------------------- Default Default 0.0.0.0 192.168.1.33 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 Press ENTER to Confirm or ESC to Cancel: Figure 32-9 Menu 15.2.1 NAT Server Setup...
Page 341: General Nat Examples
Prestige 652 Series User’s Guide Figure 32-10 Multiple Servers Behind NAT Example 32.5 General NAT Examples The following are some examples of NAT configuration. 32.5.1 Example 1: Internet Access Only In the following Internet access example, you only need one rule where your ILAs (Inside Local addresses) all map to one dynamic IGA (Inside Global Address) assigned by your ISP.
Page 342: Figure 32-11 Nat Example 1
Prestige 652 Series User’s Guide Figure 32-11 NAT Example 1 Menu 4 - Internet Access Setup ISP's Name= MyISP Encapsulation= RFC 1483 Multiplexing= LLC-based VPI #= 8 VCI #= 35 ATM QoS Type= UBR Peak Cell Rate (PCR)= 0 Sustain Cell Rate (SCR)= 0...
Page 343: Figure 32-14 Menu 15.2.1 Specifying An Inside Server
Prestige 652 Series User’s Guide 32.5.2 Example 2: Internet Access with an Inside Server Figure 32-13 NAT Example 2 In this case, you do exactly as above (use the convenient pre-configured SUA Only set) and also go to menu 15.2 to specify the Inside Server behind the NAT as shown in the next figure.
Page 344 Prestige 652 Series User’s Guide 32.5.3 Example 3: Multiple Public IP Addresses With Inside Servers In this example, there are 3 IGAs from our ISP. There are many departments but two have their own FTP server. All departments share the same router. The example will reserve one IGA for each department with an FTP server and all departments use the other IGA.
Page 345: Figure 32-16 Example 3: Menu 11.3
Prestige 652 Series User’s Guide Step 1. In this case you need to configure Address Mapping Set 1 from Menu 15.1 - Address Mapping Sets. Therefore you must choose the Full Feature option from the Network Address Translation field (in menu 4 or menu 11.3) in Figure 32-16.
Page 346: Figure 32-17 Example 3: Menu
Prestige 652 Series User’s Guide Menu 15.1.1.1 Address Mapping Rule Type= One-to-One Local IP: Start= 192.168.1.10 = N/A Global IP: Start= 10.132.50.1 = N/A Server Mapping Set= N/A Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle.
Page 347 Prestige 652 Series User’s Guide Menu 15.2.1 - NAT Server Setup Rule Start Port No. End Port No. IP Address --------------------------------------------------- Default Default 0.0.0.0 192.168.1.21 192.168.1.20 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 Press ENTER to Confirm or ESC to Cancel: Example 3: Menu 15.2.1...
Page 348: Figure 32-20 Example 4: Menu 15.1.1.1 Address Mapping Rule
Prestige 652 Series User’s Guide Other applications such as some gaming programs are NAT unfriendly because they embed addressing information in the data stream. These applications won’t work through NAT even when using One-to-One and Many-to-Many No Overload mapping types.
Page 349: Chapter 33 Enabling The Firewall
Prestige 652 Series User’s Guide Chapter 33 Enabling the Firewall This chapter shows you how to get started with the Prestige firewall. 33.1 Remote Management and the Firewall When SMT menu 24.11 is configured to allow management (see the Remote Management chapter) and the firewall is enabled: •...
Page 350: Figure 33-1 Menu 21.2 Firewall Setup
Prestige 652 Series User’s Guide Menu 21.2 - Firewall Setup The firewall protects against Denial of Service (DOS) attacks when it is active. The default Policy sets 1. allow all sessions originating from the LAN to the WAN and 2. deny all sessions originating from the WAN to the LAN...
Page 351: Smt Advanced Management
SMT Advanced Management Part X: SMT Advanced Management This part discusses filtering setup, SNMP, system security, system information and diagnosis, firmware and configuration file maintenance, system maintenance, remote management, IP Policy Routing and call scheduling. See the web configurator parts of this guide for background information on features configurable by web configurator and SMT.
Page 353: Chapter 34 Filter Configuration
Prestige 652 Series User’s Guide Chapter 34 Filter Configuration This chapter shows you how to create and apply filters. 34.1 About Filtering Your Prestige uses filters to decide whether or not to allow passage of a data packet and/or to make a call.
Page 354: Figure 34-1 Outgoing Packet Filtering Process
Prestige 652 Series User’s Guide Call Filtering Active Data match Built-in User-defined match match Outgoing Initiate call default Call Filters Data Packet if line not up Call Filters (if applicable) Send packet and reset Idle Timer Match Match Match Drop...
Page 355: Figure 34-2 Filter Rule Process
Prestige 652 Series User’s Guide Start Packet intoFilter Fetch First Filter Set Filter Set Fetch Next Fetch First Filter Set Filter Rule Fetch Next Filter Rule Next filter Next Filter Set Rule Active? Available? Available? Execute Filter Rule Check Next...
Page 356: Configuring A Filter Set For The Prestige 652H/Hw
Prestige 652 Series User’s Guide For incoming packets, your Prestige applies data filters only. Packets are processed depending on whether a match is found. The following sections describe how to configure filter sets. The Filter Structure of the Prestige A filter set consists of one or more filter rules. Usually, you would group related rules, for example, all the rules for NetBIOS, into a single set and give it a descriptive name.
Page 357: Figure 34-4 Netbios_Wan Filter Rules Summary (P652H/Hw)
Prestige 652 Series User’s Guide Menu 21.1.2 - Filter Rules Summary # A Type Filter Rules M m n - - ---- --------------------------------------------------------------- - - - 1 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=137 N D N 2 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=138...
Page 358: Configuring A Filter Set For The Prestige 652
Prestige 652 Series User’s Guide 34.3 Configuring a Filter Set for the Prestige 652 To configure a filter set, follow the steps shown next. Step 1. Enter 21 in the main menu to display Menu 21 – Filter and Firewall Setup.
Page 359: Filter Rules Summary Menus
Prestige 652 Series User’s Guide Menu 21.1.4 - Filter Rules Summary # A Type Filter Rules M m n - - ---- --------------------------------------------------------------- - - - 1 Y Gen Off=12, Len=2, Mask=ffff, Value=8863 N F N 2 Y Gen Off=12, Len=2, Mask=ffff, Value=8864...
Page 360: Configuring A Filter Rule
Prestige 652 Series User’s Guide Table 34-1 Abbreviations Used in the Filter Rules Summary Menu FIELD DESCRIPTION More. “Y” means there are more rules to check which form a rule chain with the present rule. An action cannot be taken until the rule chain is complete.
Page 361: Figure 34-10 Menu 21.1.X.1 Tcp/Ip Filter Rule
Prestige 652 Series User’s Guide There are two types of filter rules: TCP/IP and Generic. Depending on the type of rule, the parameters for each type will be different. Use [SPACE BAR] to select the type of rule that you want to create in the Filter Type field and press [ENTER] to open the respective menu.
Page 362: Table 34-3 Menu 21.1.X.1 Tcp/Ip Filter Rule
Prestige 652 Series User’s Guide Table 34-3 Menu 21.1.x.1 TCP/IP Filter Rule FIELD DESCRIPTION EXAMPLE Filter # This is the filter set, filter rule coordinates, for instance, 2, 3 refers to the second filter set and the third filter rule of that set.
Page 363 Prestige 652 Series User’s Guide Table 34-3 Menu 21.1.x.1 TCP/IP Filter Rule FIELD DESCRIPTION EXAMPLE TCP Estab This applies only when the IP Protocol field is 6, TCP. If Yes, the rule matches packets that want to establish TCP (default) connection(s) (SYN=1 and ACK=0);...
Page 364: Figure 34-11 Executing An Ip Filter
Prestige 652 Series User’s Guide Packet into IP Filter Filter Active? Apply SrcAddrMask to Src Addr Check Src Not Matched IP Addr Matched Apply DestAddrMask to Dest Addr Check Dest Not Matched IP Addr Matched Check Not Matched IP Protocol Matched Check Src &...
Page 365: Figure 34-12 Menu 21.1.5.1 Generic Filter Rule
Prestige 652 Series User’s Guide 34.5.2 Generic Filter Rule This section shows you how to configure a generic filter rule. The purpose of generic rules is to allow you to filter non-IP packets. For IP, it is generally easier to use the IP rules directly.
Page 366: Table 34-4 Menu 21.1.5.1 Generic Filter Rule
Prestige 652 Series User’s Guide Table 34-4 Menu 21.1.5.1 Generic Filter Rule FIELD DESCRIPTION EXAMPLE Filter # This is the filter set, filter rule coordinates, for instance, 2, 3 refers to the second filter set and the third rule of that set.
Page 367: Filter Types And Nat
Prestige 652 Series User’s Guide 34.6 Filter Types and NAT There are two classes of filter rules, Generic Filter Device rules and Protocol Filter (TCP/IP) rules. Generic Filter rules act on the raw data from/to LAN and WAN. Protocol Filter rules act on IP packets.
Page 368: Figure 34-14 Sample Telnet Filter
Prestige 652 Series User’s Guide Figure 34-14 Sample Telnet Filter Step 1. Enter 1 in the menu 21 to display Menu 21.1 — Filter Set Configuration. Step 2. Enter the index number of the filter set you want to configure (in this case 6) Step 3.
Page 369: Figure 34-15 Menu 21.1.6.1 Sample Filter
Prestige 652 Series User’s Guide Step 4. Press [ENTER] at the message Press [ENTER] to confirm or [ESC] to cancel” to open Menu “ 21.1.6 — Filter Rules Summary. Step 5. Type 1 to configure the first filter rule. Make the entries in this menu as shown next.
Page 370: Applying Filters And Factory Defaults
Prestige 652 Series User’s Guide Menu 21.1.6 - Filter Rules Summary # A Type Filter Rules M m n - - ---- --------------------------------------------------------------- - - - 1 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=23 N D F Enter Filter Rule Number (1-6) to Configure: 1 This shows you that you have M = N means an action can be taken immediately.
Page 371: Remote Node Filters
Prestige 652 Series User’s Guide Table 34-5 Filter Sets Table FILTER SETS DESCRIPTION Input Filter Sets: Apply filters for incoming traffic. You may apply protocol or device filter rules. See earlier in this chapter for information on filters. Output Filter Sets: Apply filters for traffic leaving the Prestige.
Page 372: Figure 34-18 Filtering Remote Node Traffic
Prestige 652 Series User’s Guide Apply filter 6 to block Menu 11.5 - Remote Node Filter Tel, FTP and Web Input Filter Sets: protocol filters= 6 traffic from the WAN. device filters= Output Filter Sets: protocol filters= 2 device filters=...
Page 373: Chapter 35 Snmp Configuration
Prestige 652 Series User’s Guide Chapter 35 SNMP Configuration This chapter explains SNMP Configuration menu 22. 35.1 About SNMP Simple Network Management Protocol is a protocol used for exchanging management information between network devices. SNMP is a member of the TCP/IP protocol suite. Your Prestige supports SNMP agent functionality, which allows a manager station to manage and monitor the Prestige through the network.
Page 374: Supported Mibs
Prestige 652 Series User’s Guide An agent is a management software module that resides in a managed device (the Prestige). An agent translates the local management information from the managed device into a form compatible with SNMP. The manager is the console through which network administrators perform network management functions.
Page 375: Figure 35-2 Menu 22 Snmp Configuration
Prestige 652 Series User’s Guide Menu 22 - SNMP Configuration SNMP: Get Community= public Set Community= public Trusted Host= 0.0.0.0 Trap: Community= public Destination= 0.0.0.0 Press ENTER to Confirm or ESC to Cancel: Figure 35-2 Menu 22 SNMP Configuration The following table describes the SNMP configuration parameters.
Page 376: Snmp Traps
Prestige 652 Series User’s Guide 35.4 SNMP Traps The Prestige will send traps to the SNMP manager when any one of the following events occurs: Table 35-2 SNMP Traps TRAP # TRAP NAME DESCRIPTION coldStart (defined in RFC-1215) A trap is sent after booting (power on).
Page 377: Chapter 36 System Security
Prestige 652 Series User’s Guide Chapter 36 System Security This chapter describes how to configure the system security on the Prestige. This chapter only applies to the P652H/HW. 36.1 System Security You can configure the system password, an external RADIUS server and IEEE802.1x in menu 23.
Page 378: Figure 36-3 Menu 23.2 System Security : Radius Server
Prestige 652 Series User’s Guide Menu 23.2 - System Security - RADIUS Server Authentication Server: Active= No Server Address= 10.11.12.13 Port #= 1812 Shared Secret= ******** Accounting Server: Active= No Server Address= 10.11.12.13 Port #= 1813 Shared Secret= ******** Press ENTER to Confirm or ESC to Cancel: Figure 36-3 Menu 23.2 System Security : RADIUS Server...
Page 379: Figure 36-4 Menu 23 System Security
Prestige 652 Series User’s Guide Table 36-1 Menu 23.2 System Security : RADIUS Server FIELD DESCRIPTION EXAMPLE Port The default port of the RADIUS server for accounting is 1813. 1813 You need not change this value unless your network administrator instructs you to do so with additional information.
Page 380: Figure 36-5 Menu 23.4 System Security : Ieee802.1X
Prestige 652 Series User’s Guide Menu 23.4 - System Security - IEEE802.1x Wireless Port Control= Authentication Required ReAuthentication Timer (in second)= 1800 Idle Timeout (in second)= 3600 Authentication Databases= Local User Database Only Press ENTER to Confirm or ESC to Cancel: Figure 36-5 Menu 23.4 System Security : IEEE802.1x...
Page 381: Creating User Accounts On The Prestige
Prestige 652 Series User’s Guide Table 36-2 Menu 23.4 System Security : IEEE802.1x FIELD DESCRIPTION Authentication This field is activated only when you select Authentication Required in the Wireless Port Control field. Databases The authentication database contains wireless station login information. The local user database is the built-in database on the Prestige.
Page 382: Figure 36-6 Menu 14 Dial-In User Setup
Prestige 652 Series User’s Guide Menu 14 - Dial-in User Setup 1. ________ ________ 17. ________ 25. ________ 2. ________ 10. ________ 18. ________ 26. ________ 3. ________ 11. ________ 19. ________ 27. ________ 4. ________ 12. ________ 20. ________ 28.
Page 383: Chapter 37 System Information And Diagnosis
Prestige 652 Series User’s Guide Chapter 37 System Information and Diagnosis This chapter covers the information and diagnostic tools in SMT menus 24.1 to 24.4. These tools include updates on system status, port status, log and trace capabilities and upgrades for the system software.
Page 384: Figure 37-2 Menu 24.1 System Maintenance : Status
Prestige 652 Series User’s Guide Menu 24.1 - System Maintenance – Status hh:mm:ss Sat. Jan. 01, 2000 Up Time Node-Lnk Status TxPkts RxPkts Errors Tx B/s Rx B/s 1-ENET 0:26:20 0:00:00 0:00:00 0:00:00 0:00:00 0:00:00 0:00:00 0:00:00 My WAN IP (from ISP) :...
Page 385: System Information
Prestige 652 Series User’s Guide Table 37-1 Menu 24.1 System Maintenance : Status FIELD DESCRIPTION Status This shows the current status of the LAN. Tx Pkts This is the number of transmitted packets to the LAN. Rx Pkts This is the number of received packets from the LAN.
Page 386: Figure 37-4 Menu 24.2.1 System Maintenance : Information
Refers to the routing protocol used. ZyNOS F/W Version Refers to the ZyNOS (ZyXEL Network Operating System) system firmware version. ZyNOS is a registered trademark of ZyXEL Communications Corporation. ADSL Chipset Vendor Displays the vendor of the ADSL chipset and DSL version.
Page 387: Log And Trace
Prestige 652 Series User’s Guide 37.2.2 Console Port Speed You can set up different port speeds for the console port through Menu 24.2.2 – System Maintenance – Console Port Speed. Your Prestige supports 9600 (default), 19200, 38400, 57600 and 115200 bps. Press [SPACE BAR] and then [ENTER] to select the desired speed in menu 24.2.2, as shown in the following...
Page 388: Figure 37-7 Sample Error And Information Messages
Prestige 652 Series User’s Guide Step 3. Enter 1 from Menu 24.3 — System Maintenance — Log and Trace to display the error log in the system. After the Prestige finishes displaying the error log, you will have the option to clear it. Samples of typical error and information messages are presented in the next figure.
Page 389: Table 37-3 Menu 24.3.2 System Maintenance : Syslog And Accounting
Prestige 652 Series User’s Guide Table 37-3 Menu 24.3.2 System Maintenance : Syslog and Accounting PARAMETER DESCRIPTION UNIX Syslog: Active Use [SPACE BAR] and then [ENTER] to turn syslog on or off. Syslog IP Address Type the IP address of your syslog server.
Page 390 Prestige 652 Series User’s Guide Jul 19 11:28:56 192.168.102.2 ZYXEL: Packet Trigger: Protocol=1, Data=4500002c1b0140001f06b50ec0a86614ca849a7b0427001700195b3e00000000600220008cd40000020405b4 Jul 19 11:29:06 192.168.102.2 ZYXEL: Packet Trigger: Protocol=1, Data=45000028240140001f06ac12c0a86614ca849a7b0427001700195b451d1430135004000077600000 3 - Filter Log SdcmdSyslogSend (SYSLOG_FILLOG, SYSLOG_NOTICE, String); String = IP[Src=xx.xx.xx.xx Dst=xx.xx.xx.xx prot spo=xxxx dpo=xxxx] S04>R01mD IP[…] is the packet header and S04>R01mD means filter set 4 (S) and rule 1 (R), match (m), drop (D).
Page 391: Diagnostic
Prestige 652 Series User’s Guide IP Frame: ENET0-RECV Size: Time: 17:02:44.262 Frame Type: IP Header: IP Version Header Length = 20 Type of Service = 0x00 (0) Total Length = 0x002C (44) Identification = 0x0002 (2) Flags = 0x00 Fragment Offset...
Page 392: Figure 37-10 Menu 24.4 System Maintenance : Diagnostic
Prestige 652 Series User’s Guide Step 2. From this menu, type 4. Diagnostic to open Menu 24.4 – System Maintenance – Diagnostic. Menu 24.4 - System Maintenance – Diagnostic xDSL System Reset xDSL 21. Reboot System 22. Command Mode TCP/IP 12.
Page 393: Chapter 38 Firmware And Configuration File Maintenance
Prestige 652 Series User’s Guide Chapter 38 Firmware and Configuration File Maintenance This chapter tells you how to backup and restore your configuration file as well as upload new firmware and configuration files. 38.1 Filename Conventions The configuration file (often called the romfile or rom-0) contains the factory default settings in the menus such as password, DHCP Setup, TCP/IP Setup, etc.
Page 394: Backup Configuration
Prestige 652 Series User’s Guide Table 38-1 Filename Conventions FILE TYPE INTERNAL NAME EXTERNAL NAME DESCRIPTION Configuration Rom-0 This is the configuration filename on the *.rom File Prestige. Uploading the rom-0 file replaces the entire ROM file system, including your...
Page 395: Using The Ftp Command From The Command Line
Prestige 652 Series User’s Guide 38.2.1 Backup Configuration Follow the instructions as shown in the next screen. Menu 24.5 - System Maintenance - Backup Configuration To transfer the configuration file to your workstation, follow the procedure below: 1. Launch the FTP client on your workstation.
Page 396: Figure 38-2 Ftp Session Example
Prestige 652 Series User’s Guide 331 Enter PASS command Password: 230 Logged in ftp> bin 200 Type I OK ftp> get rom-0 zyxel.rom 200 Port command okay 150 Opening data connection for STOR ras 226 File received OK ftp: 16384 bytes sent in 1.10Seconds 297.89Kbytes/sec.
Page 397: Backup Configuration Using Tftp
Prestige 652 Series User’s Guide 3. The IP address in the Secured Client IP field in menu 24.11 does not match the client IP. If it does not match, the Prestige will disconnect the Telnet session immediately. 4. You have an SMT console session running.
Page 398: Figure 38-3 Menu 24.5 System Maintenance : Backup Configuration
Prestige 652 Series User’s Guide 38.2.8 GUI-based TFTP Clients The following table describes some of the fields that you may see in GUI-based TFTP clients. Table 38-3 General Commands for GUI-based TFTP Clients COMMAND DESCRIPTION Host Enter the IP address of the Prestige. 192.168.1.1 is the Prestige’s default IP address when shipped.
Page 399: Restore Configuration
Prestige 652 Series User’s Guide Step 3. Run the HyperTerminal program by clicking Transfer, then Receive File as shown in the following screen. Type a location for storing the configuration file or click Browse to look for one. Choose the Xmodem protocol.
Page 400: Restore Using Ftp
Prestige 652 Series User’s Guide WARNING! DO NOT INTERRUPT THE FILE TRANSFER PROCESS AS THIS MAY PERMANENTLY DAMAGE YOUR PRESTIGE. 38.3.1 Restore Using FTP For details about backup using (T)FTP please refer to earlier sections on FTP and TFTP file upload in this chapter.
Page 401: Figure 38-8 Restore Using Ftp Session Example
Prestige 652 Series User’s Guide 38.3.2 Restore Using FTP Session Example ftp> put config.rom rom-0 200 Port command okay 150 Opening data connection for STOR rom-0 226 File received OK 221 Goodbye for writing flash ftp: 16384 bytes sent in 0.06Seconds 273.07Kbytes/sec.
Page 402: Uploading Firmware And Configuration Files
Prestige 652 Series User’s Guide Type the configuration file’s location, or click Browse to search for it. Choose the Xmodem protocol. Then click Send. Figure 38-11 Restore Configuration Example Step 4. After a successful restoration you will see the following screen. Press any key to restart the Prestige and return to the SMT menu.
Page 403: Configuration File Upload
Prestige 652 Series User’s Guide Menu 24.7.1 - System Maintenance - Upload System Firmware To upload the system firmware, follow the procedure below: 1. Launch the FTP client on your workstation. 2. Type "open" and the IP address of your system. Then type "root" and SMT password as requested.
Page 404: Ftp File Upload Command From The Dos Prompt Example
Prestige 652 Series User’s Guide 38.4.3 FTP File Upload Command from the DOS Prompt Example Step 1. Launch the FTP client on your computer. Step 2. Enter “open”, followed by a space and the IP address of your Prestige. Step 3.
Page 405: Tftp Upload Command Example
Prestige 652 Series User’s Guide To use TFTP, your computer must have both telnet and TFTP clients. To transfer the firmware and the configuration file, follow the procedure shown next. Step 1. Use telnet from your computer to connect to the Prestige and log in. Because TFTP does not have any security checks, the Prestige records the IP address of the telnet client and accepts TFTP requests only from this address.
Page 406: Figure 38-16 Menu 24.7.1 As Seen Using The Console Port
Prestige 652 Series User’s Guide 38.4.8 Uploading Firmware File Via Console Port Step 1. Select 1 from Menu 24.7 – System Maintenance – Upload Firmware to display Menu 24.7.1 – System Maintenance – Upload System Firmware, then follow the instructions as shown in the following screen.
Page 407: Figure 38-18 Menu 24.7.2 As Seen Using The Console Port
Prestige 652 Series User’s Guide 38.4.10 Uploading Configuration File Via Console Port Step 1. Select 2 from Menu 24.7 – System Maintenance – Upload Firmware to display Menu 24.7.2 – System Maintenance – Upload System Configuration File. Follow the instructions as shown in the next screen.
Page 408: Figure 38-19 Example Xmodem Upload
Prestige 652 Series User’s Guide Type the configuration file’s location, or click Browse to search for it. Choose the Xmodem protocol. Then click Send. Figure 38-19 Example Xmodem Upload After the configuration upload process has completed, restart the Prestige by entering “atgo”.
Page 409: Chapter 39 System Maintenance
Prestige 652 Series User’s Guide Chapter 39 System Maintenance This chapter leads you through SMT menus 24.8 to 24.10. 39.1 Command Interpreter Mode The Command Interpreter (CI) is a part of the main system firmware. The CI provides much of the same functionality as the SMT, while adding some low-level setup and diagnostic functions.
Page 410: Call Control Support
Prestige 652 Series User’s Guide Copyright (c) 1994 - 2003 ZyXEL Communications Corp. ras> ? Valid commands are: exit device ether config bridge hdap show ras> Figure 39-2 Valid Commands 39.2 Call Control Support Call Control Support is only applicable when Encapsulation is set to PPPoE in menu 4 or menu 11.1.
Page 411: Figure 39-4 Menu 24.9.1 System Maintenance : Budget Management
Prestige 652 Series User’s Guide Menu 24.9.1 - System Maintenance - Budget Management Remote Node Connection Time/Total Budget Elapsed Time/Total Period 1.ChangeMe No Budget No Budget 2.-------- 3.-------- 4.-------- 5.-------- 6.-------- 7.-------- 8.-------- Reset Node (0 to update screen): Figure 39-4 Menu 24.9.1 System Maintenance : Budget Management The total budget is the time limit on the accumulated time for outgoing calls to a remote node.
Page 412: Time And Date Setting
Prestige 652 Series User’s Guide 39.3 Time and Date Setting The Prestige keeps track of the time and date. There is also a software mechanism to set the time manually or get the current time and date from an external server when you turn on your Prestige. Menu 24.10 allows you to update the time and date settings of your Prestige.
Page 413: Resetting The Time
Prestige 652 Series User’s Guide Table 39-2 Menu 24.10 System Maintenance: Time and Date Setting FIELD DESCRIPTION Use Time Server Enter the time service protocol that your time server sends when you turn on the when Bootup Prestige. Not all time servers support all protocols, so you may have to check with your ISP/network administrator or use trial and error to find a protocol that works.
Page 415: Chapter 40 Remote Management
Prestige 652 Series User’s Guide Chapter 40 Remote Management This chapter covers remote management (SMT menu 24.11). 40.1 Remote Management Overview Remote management allows you to determine which services/protocols can access which Prestige interface (if any) from which computers. When you configure remote management to allow management from the WAN, you still need to configure a firewall rule to allow access.
Page 416: Figure 40-1 Menu 24.11 Remote Management Control
Prestige 652 Series User’s Guide Enter 11, from menu 24, to display Menu 24.11 — Remote Management Control (shown next). Menu 24.11 - Remote Management Control TELNET Server: Server Port = 23 Server Access = LAN only Secured Client IP = 0.0.0.0...
Page 417: Remote Management And Nat
Prestige 652 Series User’s Guide 40.2.2 Remote Management Limitations Remote management over LAN or WAN will not work when: 1. A filter in menu 3.1 (LAN) or in menu 11.5 (WAN) is applied to block a Telnet, FTP or Web service.
Page 419: Chapter 41 Ip Policy Routing
Prestige 652 Series User’s Guide Chapter 41 IP Policy Routing This chapter covers setting and applying policies used for IP routing. 41.1 IP Policy Routing Overview Traditionally, routing is based on the destination address only and the IAD takes the shortest path to forward a packet.
Page 420: Ip Routing Policy Setup
Prestige 652 Series User’s Guide IPPR follows the existing packet filtering facility of RAS in style and in implementation. The policies are divided into sets, where related policies are grouped together. A user defines the policies before applying them to an interface or a remote node, in the same fashion as the filters. There are 12 policy sets with six policies in each set.
Page 421: Figure 41-2 Menu 25.1 Ip Routing Policy Setup
Prestige 652 Series User’s Guide Menu 25.1 - IP Routing Policy Setup Criteria/Action - - -------------------------------------------------------------------------- 1 Y SA=1.1.1.1-1.1.1.1,DA=2.2.2.2-2.2.2.5 SP=20-25,DP=20-25,P=6,T=NM,PR=0 |GW=192.168.1.1,T=MT,PR=0 2 N __________________________________________________________________________ __________________________________________________________________________ 3 N __________________________________________________________________________ __________________________________________________________________________ 4 N __________________________________________________________________________ __________________________________________________________________________ 5 N __________________________________________________________________________ __________________________________________________________________________ 6 N __________________________________________________________________________...
Page 422: Figure 41-3 Menu 25.1.1 Ip Routing Policy
Prestige 652 Series User’s Guide Type a number from 1 to 6 to display Menu 25.1.1 – IP Routing Policy (see the next figure). This menu allows you to configure a policy rule. Menu 25.1.1 - IP Routing Policy Policy Set Name= test...
Page 423: Applying An Ip Policy
Prestige 652 Series User’s Guide Table 41-2 Menu 25.1.1 IP Routing Policy FIELD DESCRIPTION Len Comp Press [SPACE BAR] and then [ENTER] to choose from Equal, Not Equal, Less, Greater, Less or Equal or Greater or Equal. Source: addr start / end Source IP address range from start to end.
Page 424: Figure 41-4 Menu 3.2 Tcp/Ip And Dhcp Ethernet Setup
Prestige 652 Series User’s Guide Menu 3.2 - TCP/IP and DHCP Ethernet Setup DHCP Setup: DHCP= None Client IP Pool Starting Address= N/A Size of Client IP Pool= N/A Primary DNS Server= N/A Secondary DNS Server= N/A Remote DHCP Server= N/A...
Page 425: Ip Policy Routing Example
Prestige 652 Series User’s Guide 41.6 IP Policy Routing Example If a network has both Internet and remote node connections, you can route Web packets to the Internet using one policy and route FTP packets to a remote network using another policy. See the next figure.
Page 426: Figure 41-7 Ip Routing Policy Example
Prestige 652 Series User’s Guide Step 1. Create a routing policy set in menu 25. Step 2. Create a rule for this set in Menu 25.1.1 — IP Routing Policy as shown next. Menu 25.1.1 - IP Routing Policy Policy Set Name= set1...
Page 427: Figure 41-8 Ip Routing Policy Example
Prestige 652 Series User’s Guide Menu 25.1.1 - IP Routing Policy Policy Set Name= set2 Active= Yes Criteria: IP Protocol Type of Service= Don't Care Packet length= 10 Precedence = Don't Care Len Comp= N/A Source: addr start= 0.0.0.0 end= N/A...
Page 429: Chapter 42 Call Scheduling
Prestige 652 Series User’s Guide Chapter 42 Call Scheduling Call scheduling (applicable for PPPoA or PPPoE encapsulation only) allows you to dictate when a remote node should be called and for how long. 42.1 Introduction The call scheduling feature allows the Prestige to manage a remote node and dictate when a remote node should be called and for how long.
Page 430: Figure 42-2 Menu 26.1 Schedule Set Setup
Prestige 652 Series User’s Guide To delete a schedule set, enter the set number and press [SPACE BAR] and then [ENTER] (or delete) in the Edit Name field. To setup a schedule set, select the schedule set you want to setup from menu 26 (1-12) and press [ENTER] to see Menu 26.1 —...
Page 431 Prestige 652 Series User’s Guide Table 42-1 Menu 26.1 Schedule Set Setup FIELD DESCRIPTION EXAMPLE Should this schedule set recur weekly or be used just once Once Often only? Press the [SPACE BAR] and then [ENTER] to select Once or Weekly. Both these options are mutually exclusive.
Page 432: Figure 42-3 Applying Schedule Set(S) To A Remote Node (Pppoe)
Prestige 652 Series User’s Guide Menu 11.1 - Remote Node Profile Rem Node Name= ChangeMe Route= IP Active= Yes Bridge= No Encapsulation= PPPoE Edit IP/Bridge= No Multiplexing=VC-based Edit ATM Options= No Service Name= Telco Option: Incoming Allocated Budget(min)= 0 Rem Login=...
Page 433: Appendices And Index
Part XII: Appendices and Index This part contains additional background information and an index or key terms.
Page 435: Appendix A Troubleshooting
Prestige 652 Series User’s Guide Appendix A Troubleshooting This chapter covers potential problems and the corresponding remedies. Problems Starting Up the Prestige Chart A-1 Troubleshooting the Start-Up of Your Prestige PROBLEM CORRECTIVE ACTION None of the Make sure that the Prestige’s power adaptor is connected to the Prestige and plugged in to LEDs turn on an appropriate power source.
Page 436 Prestige 652 Series User’s Guide Chart A-3 Troubleshooting the DSL LED PROBLEM CORRECTIVE ACTION The xDSL LED is off. Check the telephone wire and connections between the Prestige DSL port and the wall jack. Make sure that the telephone company has checked your phone line and set it up for DSL service.
Page 437: Problems With Internet Access
Prestige 652 Series User’s Guide Problems with the WAN Interface Chart A-5 Troubleshooting the WAN Interface PROBLEM CORRECTIVE ACTION I cannot get a WAN The ISP provides the WAN IP address after authenticating you. Authentication may IP address from the be through the user name and password, the MAC address or the host name.
Page 438 Prestige 652 Series User’s Guide Problems with the Password Chart A-7 Troubleshooting the Password PROBLEM CORRECTIVE ACTION I cannot access the The username is “admin”. The default password is “1234”. The Password and Prestige. Username fields are case-sensitive. Make sure that you enter the correct password and username using the proper casing.
Page 439 Prestige 652 Series User’s Guide Problems with Remote Management Chart A-9 Troubleshooting Remote Management PROBLEM CORRECTIVE ACTION I cannot remotely Refer to the Remote Management Limitations section in the Firmware and manage the Configuration File Management chapter (SMT) for scenarios when remote Prestige from the management may not be possible.
Page 441 Prestige 652 Series User’s Guide Appendix B IP Subnetting IP Addressing Routers “route” based on the network number. The router that delivers the data packet to the correct destination host uses the host ID. IP Classes An IP address is made up of four octets (eight bits), written in dotted decimal notation, for example, 192.168.1.1.
Page 442 Prestige 652 Series User’s Guide A class “A” address (24 host bits) can have 2 –2 hosts (approximately 16 million hosts). Since the first octet of a class “A” IP address must contain a “0”, the first octet of a class “A” address can have a value of 0 to 127.
Page 443: Appendix B Ip Subnetting
Prestige 652 Series User’s Guide of ones beginning from the left most bit of the mask, followed by a continuous sequence of zeros, for a total number of 32 bits. Since the mask is always a continuous number of ones beginning from the left, followed by a continuous number of zeros for the remainder of the 32 bit mask, you can simply specify the number of ones instead of writing the value of each octet.
Page 444 Prestige 652 Series User’s Guide Divide the network 192.168.1.0 into two separate subnets by converting one of the host ID bits of the IP address to a network number bit. The “borrowed” host ID bit can be either “0” or “1” thus giving two subnets;...
Page 445 Prestige 652 Series User’s Guide actual host for the first subnet is 192.168.1.1 and the highest is 192.168.1.126. Similarly the host ID range for the second subnet is 192.168.1.129 to 192.168.1.254. Example: Four Subnets The above example illustrated using a 25-bit subnet mask to divide a class “C” address space into two subnets.
Page 446 Prestige 652 Series User’s Guide Chart B-10 Subnet 4 NETWORK NUMBER LAST OCTET BIT VALUE IP Address 192.168.1. IP Address (Binary) 11000000.10101000.00000001. 11000000 Subnet Mask (Binary) 11111111.11111111.11111111. 11000000 Subnet Address: 192.168.1.192 Lowest Host ID: 192.168.1.193 Broadcast Address: 192.168.1.255 Highest Host ID: 192.168.1.254 Example Eight Subnets Similarly use a 27-bit mask to create 8 subnets (001, 010, 011, 100, 101, 110).
Page 447 Prestige 652 Series User’s Guide Chart B-12 Class C Subnet Planning NO. “BORROWED” HOST BITS SUBNET MASK NO. SUBNETS NO. HOSTS PER SUBNET 255.255.255.128 (/25) 255.255.255.192 (/26) 255.255.255.224 (/27) 255.255.255.240 (/28) 255.255.255.248 (/29) 255.255.255.252 (/30) 255.255.255.254 (/31) Subnetting With Class A and Class B Networks.
Page 448 Prestige 652 Series User’s Guide Chart B-13 Class B Subnet Planning NO. “BORROWED” HOST BITS SUBNET MASK NO. SUBNETS NO. HOSTS PER SUBNET (/25) 255.255.255.192 1024 (/26) 255.255.255.224 2048 (/27) 255.255.255.240 4096 (/28) 255.255.255.248 8192 (/29) 255.255.255.252 16384 (/30) 255.255.255.254...
Page 449 Prestige 652 Series User’s Guide Appendix C Wireless LAN and IEEE 802.11 A wireless LAN (WLAN) provides a flexible data communications system that you can use to access various services (navigating the Internet, email, printer services, etc.) without the any expensive network-cabling infrastructure.
Page 450: Infrastructure Wireless Lan Configuration
Prestige 652 Series User’s Guide Ad-hoc Wireless LAN Configuration The simplest WLAN configuration is an independent (Ad-hoc) WLAN that connects a set of computers with wireless nodes or stations (STA), which is called a Basic Service Set (BSS). In the most basic form, a wireless LAN connects a set of computers with wireless adapters.
Page 451 Prestige 652 Series User’s Guide Diagram C-2 ESS Provides Campus-Wide Coverage Wireless LAN and IEEE 802.11...
Page 453: Appendix Dpppoe
Prestige 652 Series User’s Guide Appendix D PPPoE PPPoE in Action An ADSL modem bridges a PPP session over Ethernet (PPP over Ethernet, RFC 2516) from your PC to an ATM PVC (Permanent Virtual Circuit) that connects to a xDSL Access Concentrator where the PPP session terminates (see the next figure).
Page 454 Prestige 652 Series User’s Guide How PPPoE Works The PPPoE driver makes the Ethernet appear as a serial link to the PC and the PC runs PPP over it, while the modem bridges the Ethernet frames to the Access Concentrator (AC). Between the AC and an ISP, the AC is acting as a L2TP (Layer 2 Tunneling Protocol) LAC (L2TP Access Concentrator) and tunnels the PPP frames to the ISP.
Page 455: Appendix E Virtual Circuit Topology
Prestige 652 Series User’s Guide Appendix E Virtual Circuit Topology ATM is a connection-oriented technology, meaning that it sets up virtual circuits over which end systems communicate. The terminology for virtual circuits is as follows: • Virtual Channel Logical connections between ATM switches •...
Page 457: Appendix F Power Adaptor Specifications
Prestige 652 Series User’s Guide Appendix F Power Adaptor Specifications Prestige 652R-11; Prestige 652R-13 NORTH AMERICAN PLUG STANDARDS AC Power Adapter Model DV-1215A Input Power AC120Volts/60Hz/30W Output Power AC12Volts/1.25A Power Consumption 11 W Safety Standards UL, CUL, CSA (UL 1310, CSA C22.2 No.223)
Page 458 Prestige 652 Series User’s Guide Prestige 652H-31/-33/-37; Prestige 652H/HW-31/-33/-37 NORTH AMERICAN PLUG STANDARDS AC Power Adapter Model DV-1215A Input Power AC120Volts/60Hz/30W Output Power AC12Volts/1.25A Power Consumption 14 W Safety Standards UL, CUL, CSA (UL 1310, CSA C22.2 No.223) NORTH AMERICAN PLUG STANDARDS...
Page 459: Appendix G Example Internal Sptgen Screens
Prestige 652 Series User’s Guide Appendix G Example Internal SPTGEN Screens This appendix covers Prestige Internal SPTGEN screens. Abbreviations Used in the Example Internal SPTGEN Screens Table ABBREVIATION MEANING Field Identification Number (not seen in SMT screens) Field Name Parameter Values Allowed...
Page 460 Prestige 652 Series User’s Guide / MENU 3.1 GENERAL ETHERNET SETUP (SMT MENU 3.1) INPUT 30100001 = Input Protocol filters Set 1 30100002 = Input Protocol filters Set 2 = 256 30100003 = Input Protocol filters Set 3 = 256...
Page 461 Prestige 652 Series User’s Guide 30200008 = IP Address = 172.21.2.200 30200009 = IP Subnet Mask = 16 This 30200010 = RIP Direction <0(None) | 1(Both) | value 2(In Only) | 3(Out must be Only)> between 0-32. 30200011 = Version <0(Rip-1) | 1(Rip-2B)
Page 462 Prestige 652 Series User’s Guide 30201010 = IP Alias #1 Outgoing protocol filters = 256 Set 1 30201011 = IP Alias #1 Outgoing protocol filters = 256 Set 2 30201012 = IP Alias #1 Outgoing protocol filters = 256 Set 3...
Page 463 Prestige 652 Series User’s Guide 30500002 = Hide ESSID <0(No) | 1(Yes)> 30500003 = Channel ID <1|2|3|4|5|6|7|8|9|10| 11|12|13> 30500004 = RTS Threshold <0 ~ 2432> = 2432 30500005 = FRAG. Threshold <256 ~ 2432> = 2432 30500006 = <0(DISABLE) | 1(64- bit WEP) | 2(128-bit WEP)>...
Page 464 Prestige 652 Series User’s Guide 40000005 = Multiplexing <1(LLC-based) | This 2(VC-based) value 40000006 = VPI # must be between 40000007 = VCI # = 35 0-32. 40000008 = Service Name <Str> = any This value 40000009 = My Login <Str>...
Page 465 Prestige 652 Series User’s Guide 40000031= RIP Direction <0(None) | 1(Both) | 2(In Only) | 3(Out Only)> 40000032= RIP Version <0(Rip-1) | 1(Rip-2B) |2(Rip-2M)> 40000033= Nailed-up Connection <0(No) |1(Yes)> / MENU 12.1.1 IP STATIC ROUTE SETUP (SMT MENU 12.1.1) INPUT...
Page 466 Prestige 652 Series User’s Guide 120103002 = IP Static Route set #3, Active <0(No) |1(Yes)> 120103003 = IP Static Route set #3, Destination IP = 0.0.0.0 address 120103004 = IP Static Route set #3, Destination IP subnetmask 120103005 = IP Static Route set #3, Gateway = 0.0.0.0...
Page 467 Prestige 652 Series User’s Guide / MENU 12.1.6 IP STATIC ROUTE SETUP (SMT MENU 12.1.6) INPUT 120106001 = IP Static Route set #6, Name <Str> 120106002 = IP Static Route set #6, Active <0(No) |1(Yes)> 120106003 = IP Static Route set #6, Destination IP = 0.0.0.0...
Page 468 Prestige 652 Series User’s Guide 120108005 = IP Static Route set #8, Gateway = 0.0.0.0 120108006 = IP Static Route set #8, Metric 120108007 = IP Static Route set #8, Private <0(No) |1(Yes)> */ MENU 12.1.9 IP STATIC ROUTE SETUP (SMT MENU 12.1.9)
Page 469 Prestige 652 Series User’s Guide 120111003 = IP Static Route set #11, Destination = 0.0.0.0 IP address 120111004 = IP Static Route set #11, Destination IP subnetmask 120111005 = IP Static Route set #11, Gateway = 0.0.0.0 120111006 = IP Static Route set #11, Metric...
Page 470 Prestige 652 Series User’s Guide INPUT 120114001 = IP Static Route set #14, Name <Str> 120114002 = IP Static Route set #14, Active <0(No) |1(Yes)> 120114003 = IP Static Route set #14, Destination = 0.0.0.0 IP address 120114004 = IP Static Route set #14, Destination...
Page 471 Prestige 652 Series User’s Guide 120116006 = IP Static Route set #16, Metric 120116007 = IP Static Route set #16, Private <0(No) |1(Yes)> / MENU 15 SUA SERVER SETUP (SMT MENU 15) INPUT 150000001 = SUA Server IP address for default = 0.0.0.0...
Page 472 Prestige 652 Series User’s Guide 150000021 = SUA Server #5 Local IP address = 0.0.0.0 150000022 = SUA Server #6 Active <0(No) | 1(Yes)> = 0 150000023 = SUA Server #6 Protocol <0(All)|6(TCP)|17(U DP)> 150000024 = SUA Server #6 Port Start...
Page 473 Prestige 652 Series User’s Guide 150000046 = SUA Server #10 Local IP address = 0.0.0.0 150000047 = SUA Server #11 Active <0(No) | 1(Yes)> 150000048 = SUA Server #11 Protocol <0(All)|6(TCP)|17(U DP)> 150000049 = SUA Server #11 Port Start 150000050 =...
Page 474 Prestige 652 Series User’s Guide 210101009 = IP Filter Set 1,Rule 1 Src Subnet Mask 210101010 = IP Filter Set 1,Rule 1 Src Port 210101011 = IP Filter Set 1,Rule 1 Src Port Comp <0(none)|1(equal)|2( equal)|3(less)|4(great er)> 210101013 = IP Filter Set 1,Rule 1 Act Match <1(check...
Page 475 Prestige 652 Series User’s Guide 210102013 = IP Filter Set 1,Rule 2 Act Match <1(check next)|2(forward)|3(dr op)> 210102014 = IP Filter Set 1,Rule 2 Act Not Match <1(check next)|2(forward)|3(dr op)> / MENU 21.1.1.3 SET #1, RULE #3 (SMT MENU 21.1.1.3)
Page 476 Prestige 652 Series User’s Guide INPUT 210104001 = IP Filter Set 1,Rule 4 Type <2(TCP/IP)> 210104002 = IP Filter Set 1,Rule 4 Active <0(No)|1(Yes)> 210104003 = IP Filter Set 1,Rule 4 Protocol = 17 210104004 = IP Filter Set 1,Rule 4 Dest IP address = 0.0.0.0...
Page 477 Prestige 652 Series User’s Guide 210105006 = IP Filter Set 1,Rule 5 Dest Port = 138 210105007 = IP Filter Set 1,Rule 5 Dest Port Comp <0(none)|1(equal)|2( equal)|3(less)|4(great er)> 210105008 = IP Filter Set 1,Rule 5 Src IP Address = 0.0.0.0...
Page 478 Prestige 652 Series User’s Guide 210106010 = IP Filter Set 1,Rule 6 Src Port 210106011 = IP Filter Set 1,Rule 6 Src Port Comp <0(none)|1(equal)|2( equal)|3(less)|4(great er)> 210106013 = IP Filter Set 1,Rule 6 Act Match <1(check next)|2(forward)|3(dr op)> 210106014 = IP Filter Set 1,Rule 6 Act Not Match <1(check...
Page 479 Prestige 652 Series User’s Guide 210201011 = IP Filter Set 2, Rule 1 Src Port Comp <0(none)|1(equal)|2( equal)|3(less)|4(great er)> 210201013 = IP Filter Set 2, Rule 1 Act Match <1(check next)|2(forward)|3(dr op)> 210201014 = IP Filter Set 2, Rule 1 Act Not Match <1(check...
Page 480 Prestige 652 Series User’s Guide 210202014 = IP Filter Set 2, Rule 2 Act Not Match <1(check next)|2(forward)|3(dr op)> / MENU 21.1.2.3 FILTER SET #2, RULE #3 (SMT MENU 21.1.2.3) INPUT 210203001 = IP Filter Set 2, Rule 3 Type <0(none)|2(TCP/IP)>...
Page 481 Prestige 652 Series User’s Guide 210204002 = IP Filter Set 2, Rule 4 Active <0(No)|1(Yes)> = 1 210204003 = IP Filter Set 2, Rule 4 Protocol = 17 210204004 = IP Filter Set 2, Rule 4 Dest IP = 0.0.0.0...
Page 482 Prestige 652 Series User’s Guide 210205006 = IP Filter Set 2, Rule 5 Dest Port = 138 210205007 = IP Filter Set 2, Rule 5 Dest Port <0(none)|1(equal)|2( Comp equal)|3(less)|4(great er)> 210205008 = IP Filter Set 2, Rule 5 Src IP address = 0.0.0.0...
Page 483 Prestige 652 Series User’s Guide 210206009 = IP Filter Set 2, Rule 6 Src Subnet Mask 210206010 = IP Filter Set 2, Rule 6 Src Port 210206011 = IP Filter Set 2, Rule 6 Src Port Comp <0(none)|1(equal)|2( equal)|3(less)|4(great er)>...
Page 484: Command Examples
Prestige 652 Series User’s Guide 230400003 = Idle Timeout (in second) = 999 230400004 = Authentication Databases <0(Local User Database Only) |1(RADIUS Only) |2(Local,RADIUS) |3(RADIUS,Local)> / MENU 24.11 REMOTE MANAGEMENT CONTROL (SMT MENU 24.11) INPUT These 241100001 = TELNET Server Port...
Page 485: Appendix H Setting Up Your Computer's Ip Address
Prestige 652 Series User’s Guide Appendix H Setting up Your Computer’s IP Address All computers must have a 10M or 100M Ethernet adapter card and TCP/IP installed. Windows 95/98/Me/NT/2000/XP, Macintosh OS 7 and later operating systems and all versions of UNIX/LINUX include the software components you need to install and use TCP/IP on your computer.
Page 486 Prestige 652 Series User’s Guide Installing Components The Network window Configuration tab displays a list of installed components. You need a network adapter, the TCP/IP protocol and Client for Microsoft Networks. If you need the adapter: In the Network window, click Add.
Page 487 Prestige 652 Series User’s Guide Click the IP Address tab. -If your IP address is dynamic, select Obtain an IP address automatically. -If you have a static IP address, select Specify an IP address and type your information into the IP Address and Subnet Mask fields.
Page 488: Verifying Settings
Prestige 652 Series User’s Guide Click the Gateway tab. -If you do not know your gateway’s IP address, remove previously installed gateways. -If you have a gateway IP address, type it in the New gateway field and click Add. Click OK to save and close the TCP/IP Properties window.
Page 489 Prestige 652 Series User’s Guide Windows 2000/NT/XP For Windows XP, click start, Control Panel. In Windows 2000/NT, click Start, Settings, Control Panel. For Windows XP, click Network Right-click Local Area Connection and Connections. For Windows 2000/NT, click then click Properties.
Page 490 Prestige 652 Series User’s Guide Select Internet Protocol (TCP/IP) (under the General tab in Win XP) and click Properties. The Internet Protocol TCP/IP Properties window opens (the General tab in Windows XP). -If you have a dynamic IP address click Obtain an IP address automatically.
Page 491 Prestige 652 Series User’s Guide -If you do not know your gateway's IP address, remove any previously installed gateways in the IP Settings tab and click OK. Do one or more of the following if you want to configure additional IP addresses: -In the IP Settings tab, in IP addresses, click Add.
Page 492 Prestige 652 Series User’s Guide In the Internet Protocol TCP/IP Properties window (the General tab in Windows XP): -Click Obtain DNS server address automatically if you do not know your DNS server IP address(es). -If you know your DNS server IP address(es),...
Page 493 Prestige 652 Series User’s Guide Macintosh OS 8/9 Click the Apple menu, Control Panel and double-click TCP/IP to open the TCP/IP Control Panel. Select Ethernet built-in from the Connect via list. Setting up Your Computer’s IP Address...
Page 494 Prestige 652 Series User’s Guide For dynamically assigned settings, select Using DHCP Server from the Configure: list. For statically assigned settings, do the following: -From the Configure box, select Manually. -Type your IP address in the IP Address box. -Type your subnet mask in the Subnet mask box.
Page 495 Prestige 652 Series User’s Guide Click Network in the icon bar. - Select Automatic from the Location list. - Select Built-in Ethernet from the Show list. - Click the TCP/IP tab. For dynamically assigned settings, select Using DHCP from the Configure list.
Page 497: Appendix I Splitters And Microfilters
Prestige 652 Series User’s Guide Appendix I Splitters and Microfilters This appendix tells you how to install a POTS splitter or a telephone microfilter. Connecting a POTS Splitter When you use the Full Rate (G.dmt) ADSL standard, you can use a POTS (Plain Old Telephone Service) splitter to separate the telephone and ADSL signals.
Page 498 Prestige 652 Series User’s Guide Step 2. Connect a cable from the double jack end of the Y-Connector to the “wall side” of the microfilter. Step 3. Connect another cable from the double jack end of the Y-Connector to the Prestige.
Page 499: Appendix J Log Descriptions
Prestige 652 Series User’s Guide Appendix J Log Descriptions This appendix provides descriptions of example log messages Chart J-1 System Maintenance Logs LOG MESSAGE DESCRIPTION Time calibration is The router has adjusted its time based on information from the time server.
Page 500 Prestige 652 Series User’s Guide Chart J-2 UPnP Logs LOG MESSAGE DESCRIPTION UPnP pass through UPnP packets can pass through the firewall. Firewall For the content filtering logs “(Destination)” means the destination IP address or domain name. Chart J-3 Content Filtering Logs...
Page 501: Chart J-4 Attack Logs
Prestige 652 Series User’s Guide Chart J-4 Attack Logs LOG MESSAGE DESCRIPTION attack (Protocol) The firewall detected an attack. The log may also display the protocol (for example TCP or UDP). land Protocol) The firewall detected a land attack. The log may also display the protocol (for example TCP or UDP).
Page 502: Chart J-5 Access Logs
Prestige 652 Series User’s Guide Chart J-5 Access Logs LOG MESSAGE DESCRIPTION Firewall default Access matched the default policy and the Prestige blocked or forwarded it according to the configuration of the default firewall policy (Protocol, policy. Direction) Firewall rule match Access matched a firewall rule and the Prestige blocked or forwarded it according to the rule’s configuration.
Page 503: Chart J-6 Tcp Reset Logs
Prestige 652 Series User’s Guide Chart J-5 Access Logs LOG MESSAGE DESCRIPTION Out of order TCP The router blocked a TCP handshake packet that came out of the proper order handshake packet blocked (Protocol) Unsupported/out-of- The Prestige generates this log after it drops an ICMP packet due to...
Page 504: Chart J-7 Icmp Notes
Prestige 652 Series User’s Guide Chart J-7 ICMP Notes TYPE CODE DESCRIPTION A packet that needed fragmentation was dropped because it was set to Don't Fragment (DF) Source route failed Source Quench A gateway may discard internet datagrams if it does not have the buffer space needed to queue the datagrams for output to the next network on the route to the destination network.
Page 505 Prestige 652 Series User’s Guide Chart J-7 ICMP Notes TYPE CODE DESCRIPTION Information reply message VPN/IPSec logs To view the IPSec and IKE connection log, type 3 in menu 27 and press [ENTER] to display the IPSec log as shown next. The following figure shows a typical log from the initiator of a VPN connection.
Page 506: Chart J-8 Sample Ike Key Exchange Logs
Prestige 652 Series User’s Guide Index: Date/Time: Log: ------------------------------------------------------------ 01 Jan 08:08:07 Recv Main Mode request from <192.168.100.100> 01 Jan 08:08:07 Recv:<SA> 01 Jan 08:08:08 Send:<SA> 01 Jan 08:08:08 Recv:<KE><NONCE> 01 Jan 08:08:10 Send:<KE><NONCE> 01 Jan 08:08:10 Recv:<ID><HASH> 01 Jan 08:08:10 Send:<ID><HASH>...
Page 507 Prestige 652 Series User’s Guide Chart J-8 Sample IKE Key Exchange Logs LOG MESSAGE DESCRIPTION Start Phase 2: Quick Mode Phase 2 negotiation is begins by using Quick Mode. !! IKE Negotiation is in process The Prestige has begun negotiation with the peer for the connection already, but the IKE key exchange has not finished yet.
Page 508: Chart J-9 Sample Ipsec Logs During Packet Transmission
Prestige 652 Series User’s Guide Chart J-8 Sample IKE Key Exchange Logs LOG MESSAGE DESCRIPTION !! Too many errors! Deleting SA The Prestige deletes an SA when too many errors occur. !! ID type mismatch The ID type of an incoming packet does not match the local's peer ID type.
Page 509: Chart J-10 Rfc-2408 Isakmp Payload Types
Prestige 652 Series User’s Guide Chart J-9 Sample IPSec Logs During Packet Transmission LOG MESSAGE DESCRIPTION !! Discard REPLAY packet If the Prestige receives a packet with the wrong sequence number it will discard it. !! Inbound packet The authentication configuration settings are incorrect. Please authentication failed check them.
Page 511 Prestige 652 Series User’s Guide Appendix K Index Bandwidth Manager Class Setup ....21-11 Action for Matched Packets ......13-11 Bandwidth Manager Monitor....... 21-18 Active..........25-8, 25-11 Bandwidth Manager Summary ...... 21-9 Address Assignment ........5-2 Basic Service Set ..........C-2 Ad-hoc Configuration ........
Page 512 Prestige 652 Series User’s Guide Maximum Number of Schedule Sets..42-1 Introduction..........14-1 PPPoE............42-3 Customer Support..........v Precedence..........42-1 Customized Services ........14-2 Precedence Example....See precedence Call-Trigerring Packet ........37-8 Data encryption ..........6-4 CDR............... 37-7 Data Filtering..........34-1 CDR (Call Detail Record)......37-6 Default Policy Log .........13-5...
Page 513 Prestige 652 Series User’s Guide DSLAM ..See Digital Subscriber Line Access Multiplexer Factory LAN Defaults ........5-2 DSSS..See Direct Sequence Spread Spectrum Fairness-based Scheduler....... 21-4 DTR ............7-16, 25-7 FCC..............iii Dynamic DNS........1-3, 9-1, 24-2 FHSS...See Frequency-Hopping Spread Spectrum DYNDNS Wildcard .........
Page 514 Prestige 652 Series User’s Guide Filter Set Configuration ......34-4, 34-6 When To Use ...........11-13 Filtering ..........34-1, 34-9 Firmware File Filtering Process Maintenance ..........22-12 Outgoing Packets........34-2 Fragment Threshold........27-2 Finger............... 8-7 Fragmentation Threshold........6-3 Firewall Frame Relay .............1-6 Access Methods......... 33-1 Frequency-Hopping Spread Spectrum.....
Page 515 Prestige 652 Series User’s Guide IBSS ....See Independent Basic Service Set IP Address Assignment........3-4 ICMP echo ............. 11-6 ENET ENCAP..........3-5 Idle Timeout..........25-10 PPPoA or PPPoE ......... 3-5 IEEE 802.11............ C-1 RFC 1483 ............ 3-5 IEEE 802.11b........... 1-2 IP Addressing ..........B-1...
Page 516 Prestige 652 Series User’s Guide IP Static Route ..........30-1 MAC Address Filter Action ....6-8, 27-4 IP Static Route Setup ........30-2 MAC Address Filtering ........6-6 IP Subnet Mask..........25-12 Main Menu .............23-5 Remote ............ 25-12 Management Information Base (MIB) ...35-2 IPSec standard ..........
Page 517 Prestige 652 Series User’s Guide Examples ..........32-11 Ping.............. 37-10 How NAT Works......... 8-2 Ping of Death ..........11-4 Mapping Types ..........8-4 Point-to-Point..........xxxvii Non NAT Friendly Application Programs32-17 Point-to-Point Tunneling Protocol....8-7 Ordering Rules........... 32-6 policy-based routing ........41-1 Server Sets ...........
Page 518 Prestige 652 Series User’s Guide RADIUS Message Types......... 6-9 RFC-2364 ..........29-2, 29-3 RAS ............37-4, 41-2 RIP..25-12, 26-3, 29-7. See Routing Information Protocol Rate Root Class ............21-11 Receiving........... 37-2 Routing Information Protocol......5-3 Transmission ..........37-2 Direction............5-3 Read Me First ..........xxxv Version ............5-3...
Page 519 Prestige 652 Series User’s Guide script............. 25-13 Prestige ............11-9 Security Association ........44-1 Process............11-8 Security In General ........11-11 Static Route Setup.......... 30-1 Security Ramifications........13-2 Static Routing Topology........ 30-1 Server , 10-2, 32-4, 32-5, 32-8, 32-9, 32-10, 32- SUA ...........1-7, 8-6, 8-7...
Page 520 Prestige 652 Series User’s Guide System Maintenance 20-4, 37-1, 37-3, 38-2, 38-5, TOS (Type of Service) ........41-1 38-13, 38-14, 39-1, 39-2, 39-4, 39-5 Trace Records..........37-5 System Management Terminal ...... 23-3 Traceroute............11-7 System Parameter Table Generator ....45-1 Traffic Redirect ........7-7, 7-8 System Status..........
Page 521 Prestige 652 Series User’s Guide Web Configurator2-1, 2-2, 2-3, 11-2, 11-11, 13-2, 33-2 XMODEM protocol........38-2 WEP ..............6-4 WEP Encryption ..........27-3 ZyNOS..........38-1, 38-2 Wireless LAN ........C-1, 27-1 ZyNOS F/W Version ........38-1 Benefits............C-1 ZyXEL Limited Warranty Wireless LAN Setup ........
